TEXA AXONE NEMO PLUS Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
AXONE NEMO
PLUS
Rev.
02

Advertisement

loading
Need help?

Need help?

Do you have a question about the AXONE NEMO PLUS and is the answer not in the manual?

Questions and answers

Related Manuals for TEXA AXONE NEMO PLUS

Summary of Contents for TEXA AXONE NEMO PLUS

  • Page 1 AXONE NEMO PLUS Rev.
  • Page 2 ENGLISH..............5...
  • Page 4 4.5 Display Unit Safety..................12 4.6 Use in Difficult Environmental Conditions............13 5 ENVIRONMENTAL INFORMATION............14 6 OPERATION OF THE RADIO DEVICES...........15 7 REGULATORY INFORMATION ...............16 8 AXONE NEMO PLUS.................22 9 DESCRIPTION...................24 10 TECHNICAL FEATURES ................25 11 POWER SUPPLY..................27 11.1 Power Supply from the Mains...............28 12 POWER ON/OFF..................29...
  • Page 5 14 CONNECTIVITY ..................36 14.1 USB......................36 14.2 Bluetooth......................37 14.3 WiFi.......................38 15 ADDITIONAL FEATURES................39 15.1 Cameras and Flashlight................39 15.2 Touchscreen....................39 15.3 On-Screen Keyboard..................39 16 DIAGNOSTIC SOFTWARE..............40 16.1 Connection with the Peripheral Diagnostic Devices........42 16.2 Update......................43 17 MINIDOKING USB...................44 17.1 Description....................44 17.2 Technical Features..................45 17.3 Installation.....................46 18 OPTIONAL ACCESSORIES..............48 19 BLINK CODES..................49...
  • Page 6 AXONE NEMO PLUS TECHNICAL MANUAL 1 REVISION OF THE MANUAL This document is the technical manual for the product: AXONE NEMO PLUS Document Review Number: 02 Date of Issue: 25/03/2024 Read this manual before using the product. Read the documents carefully whenever the General Risk...
  • Page 7 TEXA S.p.A. tool has been used based on the information within this manual. Any additions to this manual, useful in describing the new versions of the program and new functions associated to it, may be sent to you through our TEXA technical bulletin service.
  • Page 8 3 LEGEND OF THE SYMBOLS USED Toxic material hazard Floor level obstacle warning Explosive material hazard Laser beam hazard Electric shock hazard Low temperature danger - freezing Electromagnetic field hazard General Risk Flammable material hazard Obligation to read the instructions Hot surface hazard Safety glasses required Corrosive substance hazard...
  • Page 9 This is not a safety symbol. It indicates important information.
  • Page 10 The personnel in charge of using the diagnostic tools are required to follow the general safety rules, use the AXONE NEMO PLUS display units for their intended use only, and carry out the maintenance as described in this manual.
  • Page 11 4.3 General Rules The operator must have carefully read and fully understood all the information and instructions in the technical documents provided with the display unit.If the operator cannot read this manual, it is responsibility of the owner of the tool/employer/person in charge of the safety to illustrate the contents of this document and adequately train the operator in relation to the operating instructions and safety measures for a proper use of the tool.
  • Page 12 4.4 Operator Safety The display unit and portable devices that contain WAN wireless modems in general, use radio signals and it is not possible to guarantee a connection to a mobile network in all conditions. Remember that in order to make or receive calls, the display unit or portable devices containing the WAN wireless modem must be switched on in an area within the signal's range.
  • Page 13 Safety Measures: • Always respect the laws and regulations in force with respect to the use of mobile devices. • Do not input nor check written data while driving. • Enter the destination information before starting to drive. • Do not enter navigation information while driving. •...
  • Page 14 Nevertheless, if malfunctions occur you should contact the vehicle's dealer. 4.6 Use in Difficult Environmental Conditions The AXONE NEMO PLUS display units have been designed and built for use in difficult environmental conditions. Nevertheless, use in such conditions is considered extraordinary and not comparable to normal product use.
  • Page 15 5 ENVIRONMENTAL INFORMATION Do not dispose of this product with other undifferentiated solid waste. For information regarding the disposal of this product please see the pamphlet supplied.
  • Page 16 The Bluetooth and WiFi interfaces look for compatible electronic devices according to the radio signal they emit and establish a connection between them. TEXA tools select and only prompt you with compatible TEXA devices. This does not exclude the presence of other sources of communication or disturbance.
  • Page 17 7 REGULATORY INFORMATION The manufacturer, TEXA S.p.A., declares that the radio equipment type AXONE NEMO PLUS is compliant with the following directives: • RED 2014/53/EU • RoHS 2011/65/EU and Delegated Directive 2015/863/EU The complete text of the EU declaration of conformity is available at the following Internet address http://www.texa.it/download.
  • Page 18 Les changements ou modifications non expressément approuvés par la partie responsable de la conformité peuvent annuler le droit de l'utilisateur à utiliser l'équipement. Labeling information Device model: AXONE NEMO PLUS • Contains FCC ID: PD9AX210NG • Contains IC: 1000M-AX210NG FCC Compliance This device complies with part 15 of the FCC Rules.
  • Page 19 Cet appareil est conforme à la partie 15 des règlements de la FCC. L'utilisation est soumise aux deux conditions suivantes: (1) l’appareil ne doit pas produire de brouillage, et (2) l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.
  • Page 20 ISED compliance This device contains license-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s license exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device.
  • Page 21 RF Radiation Exposure statement This product complies with FCC and ISED radiation exposure limits set forth for an uncontrolled environment. The antenna should be installed and operated with minimum distance of 20 cm between the radiator and your body. This device complies with Health Canada's Safety Code. The installer of this device should ensure that RF radiation is not emitted in excess of the Health Canada's requirement.
  • Page 22 Certificação ANATEL “Este produto está homologado pela ANATEL, de acordo com os procedimentos regulamentados pela Resolução 715/2019, e atende aos requisitos técnicos aplicados”. Para maiores informações, consulte o site da ANATEL www.anatel.gov.br 06711-24-10401 Este equipamento não tem direito à proteção contra interferência prejudicial e não pode causar interferência em sistemas devidamente autorizados.
  • Page 23 8 AXONE NEMO PLUS AXONE NEMO PLUS is the TEXA display unit designed and created for easy use during diagnostic activities, in any working condition. The device's body in magnesium guarantees: robustness, rigidity, lightness and excellent heat dissipation. The device has a rear camera complete with: autofocus, flash and flashlight mode, useful in order to create detailed customer reports and send images of technical details to the assistance department.
  • Page 25 9 DESCRIPTION 1. Protective case 2. Touchscreen 3. Red LED 4. Green LED 5. POWER button 6. Speaker 7. Power supply connector 8. Speaker 9. Camera 10.Flash / flashlight 11.Connector expansion modules 12.Magnet 13.Dual-band WiFi / BT antenna 14.Sensors 15.Threaded inserts 16.Dual-band WiFi / BT antenna...
  • Page 26 10 TECHNICAL FEATURES Manufacturer: TEXA S.p.A. Model: AXONE NEMO PLUS Processor: Intel N100 RAM memory: 16 GB DDR5 Hard Disk: 250 GB SSD PCle Bios: 64 Mbit Flash ROM, AMI BIOS Windows™ 11 IoT Enterprise Operating system: Trusted Platform Mobile 2.0 High-contrast ultra-wide viewing angle 11.6"...
  • Page 27 Dimensions [mm]: Weight: 1850 g RED 2014/53/EU Directives: RoHS 2011/65/EU and Delegated Directive 2015/863/ Radio Equipment Regulation 2017 No. 1206 Regulations: Regulation 2012 No. 3032 EN 62368-1 Electrical Safety: MIL-STD-810G TRANSIT DROP TEST EN 301 489-1 EN 301 489-17 Electromagnetic Compatibility: EN 301 893 EN 300 328 EN 62479...
  • Page 28 11 POWER SUPPLY The display unit is powered by an internal rechargeable battery that allows it to be used without a mains power supply. The autonomy supplied by the battery allows you to use the display unit for the duration of a normal working day.
  • Page 29 11.1 Power Supply from the Mains The display unit can be powered directly from the mains. 1. Display unit 2. Power adapter 3. Power cable Proceed as follows: 1. Connect the power adapter to the display unit. 2. Connect the power supply cable to thepower adaptor. 3.
  • Page 30 12 POWER ON/OFF The POWER button allows sending various commands to the display unit. In particular: • ignition • sleep (standby) • forced system shutdown (soft reset) • hard reset The duration of the key press determines the type of command sent. Each type of command corresponds to specific signalling via LEDs.
  • Page 31 To get the display unit out of the sleep (standby) status, press the POWER button until the green LED lights up. The display unit can be put to sleep (standby) manually. Proceed as follows: 1. Press and hold the POWER button until the display turns off. 2.
  • Page 32 12.4 Forced System Shutdown (Soft Reset) If needed, you can force the display unit's shutdown. Using this procedure may cause the loss of data that has not been stored. Proceed as follows: 1. Press and hold the POWER button for approximately 6 seconds. The display will turn off.
  • Page 33 7. Now the display unit can be reconnected to the power supply.
  • Page 34 13 PRELIMINARY OPERATIONS In the following the preliminary operations necessary to make the display unit completely operational are described. The operations are divided into the following phases: 1. MINIDOCKING USB module installation. 2. Internal battery charge. 3. First operating system configuration. 4.
  • Page 35 2. Accept the terms of the EULA - End-User License Agreement. 3. The system may restart a few times: wait for the operations to complete without turning off the display unit. The first operating system configuration is carried out as established by the operating system's manufacturer.
  • Page 36 5. Follow the instructions indicated in the software's Setup Manual. The setup of the diagnostic environment and the updated versions can be downloaded through the Download Manager application. For further information see the software's Operating Manual.
  • Page 37 14 CONNECTIVITY The display unit has several communication modes thanks to specific inbuilt modules. Each type of communication is dedicated to a specific use: Communication dedicated to connecting with peripheral devices. * BLUETOOTH Communication dedicated to connecting with peripheral devices. Communication dedicated to connecting to the Internet through a WiFi smartphone, a router or an access point.
  • Page 38 14.2 Bluetooth The Bluetooth module built into the display unit allows it to connect to various peripheral devices in the workshop. Do not connect external Bluetooth adapters to the display unit. The Bluetooth module also allows connecting to special wireless headphones equipped with a microphone.
  • Page 39 14.3 WiFi The Wi-Fi module built into the display unit allows accessing the Internet through an access point and communicating with Wi-Fi devices in the workshop. The Internet connection allows you to use particular software functions that require connecting to the WEB. Thanks to the Wi-Fi module it is possible to the connect the display unit to a smartphone.
  • Page 40 15 ADDITIONAL FEATURES 15.1 Cameras and Flashlight The display unit has a front camera, a rear camera and a flash / flashlight. The cameras are useful, for example, for photographing components that must be replaced and for which the spare part must be ordered. The camera application and the storage of images in appropriate directories are managed through the software.
  • Page 41 This way the technicians will learn how to make the best use of TEXA S.p.A. products. For further information regarding the training courses offered by TEXA S.p.A. visit the website www.texa.it.
  • Page 42 For further information regarding the installation of the software and its use, see the Setup Manual and Operating Manual.
  • Page 43 16.1 Connection with the Peripheral Diagnostic Devices In order to carry out the tests, you must install the provided diagnostic software and then use the specific software functions to perform the guided communication configuration procedure. You can connect the desired peripheral device to the display unit the following ways: •...
  • Page 44 16.2 Update The update of the diagnostic software can be performed the following ways: • via WiFi, through an appropriate router / access point or a smartphone, • via an external DVD player* connected to the display unit through the USB 3.0 module •...
  • Page 45 17 MINIDOKING USB The MINIDOCKING USB is a practical accessory supplied with the display unit. The module is equipped with: • 4 USB 3.0 ports • Magnets for the connection to the display unit without having to be fastened • Screws for fastening it to the display unit Using the module allows you to: •...
  • Page 46 17.2 Technical Features Manufacturer: TEXA S.p.A. Model: MINIDOKING USB Communication connector: proprietary connector Connectors for peripheral 4 USB 3.0 devices: • per port: 5 Vdc; 900 mAdc max Maximum current suppliable: • overall: 1,2 A Operating temperature: 0 ÷ 40 °C Storage temperature: - 20 ÷...
  • Page 47 17.3 Installation The module can be connected to the display unit in two ways: It allows you to connect / disconnect the module Only through magnetic contact quickly, without having to remove the peripheral devices connected to it. It allows you to fix the module to the display unit Magnetic contact and fixing screws firmly.
  • Page 48 3. Connect the module to the display unit as shown in the image. 4. Secure the module using the specific screws, paying attention to insert the washers indicated in the figure between the module and the display unit. * (*) Skip this step if you chose for the connection only through magnetic contact.
  • Page 49 18 OPTIONAL ACCESSORIES The display unit can be equipped with a comfortable and practical handle that allows moving it, positioning it on support bases and hooking it securely to the steering wheel. If positioning it on support bases, make sure the display unit is stable and cannot fall.
  • Page 50 19 BLINK CODES NORMAL OPERATION Visual warning Display Unit Powered ON Green Slow blink Sleep (standby) Power supply connected Powered ON Charging in progress Display unit starting phase and battery Blink charging < 10% With power supply connected: charging ended Without power supply connected: charging >...
  • Page 51 • only use original spare parts or spare parts approved by the manufacturer; • contact your retailer for extraordinary maintenance operations; For further help, contact your retailer or the technical assistance service. You can see the list of authorised retailers at the following address:https://www.texa.com/sales-network...
  • Page 52 21 TROUBLESHOOTING Contact your supplier / retailer for any technical problem that cannot be solved by following the instructions below. POSSIBLE PROBLEM PROBABLE CAUSE SOLUTION Switch on the The Bluetooth peripheral device is switched Bluetooth peripheral off. device. Place the Bluetooth peripheral device within range of the The Bluetooth peripheral device is not within...
  • Page 53 PROBABLE PROBLEM POSSIBLE SOLUTION CAUSE The display unit is Use an external mouse and keyboard. software not responding to procedure touchscreen Force the shutdown. blocked. commands. internal Recharge the display unit. batteries are low. The display unit The CPU and / or the will not switch on.
  • Page 54 22 LEGAL NOTICES TEXA S.p.A. Via 1 Maggio, 9 - 31050 Monastier di Treviso - ITALY Tax Code - Company Register of Treviso ID No. - VAT No.: 02413550266 Single-shareholder company subject to the direction and coordination activities of Opera Holding S.r.l.
