  • Page 1 TXR ID TECHNICAL MANUAL Rev.
  • Page 2 ENGLISH..............5...

  • Page 4: Table Of Contents

    SUMMARY 1 REVISION OF THE MANUAL..............5 2 INTRODUCTION..................6 3 LEGEND OF THE SYMBOLS USED............7 4 SAFETY RULES..................9 4.1 Intended Use....................9 4.2 Glossary......................9 4.3 General Rules....................10 4.4 Operator Safety....................11 4.5 Tool Safety......................13 5 OPERATION OF THE RADIO DEVICES...........15 6 ENVIRONMENTAL INFORMATION............16 7 NORMATIVE INFORMATION..............17 8 TXRiD......................18 9 DESCRIPTION...................19...
  • Page 5 18.2 Battery Replacement..................43 18.3 Replacing the Flexible Hose - Oil Separator Filter........46 18.4 General Cleaning of the Tool................47 19 SOLUTIONS TO PROBLEMS..............48 20 LEGAL NOTICES..................49...

  • Page 6: Revision Of The Manual

    D TECHNICAL MANUAL 1 REVISION OF THE MANUAL This document is the technical manual for the product: TXRiD Document Review Number: 02 Date of Issue: 07/06/2024 This manual is an essential part of the product and accompanies it from its birth up to its discontinuation. Read this manual before using the product.

  • Page 7: Introduction

    TEXA S.p.A. tool has been used based on the information within this manual. Any additions to this manual, useful in describing the new versions of the program and new functions associated to it, may be sent to you through our TEXA technical bulletin service.

  • Page 8: Legend Of The Symbols Used

    3 LEGEND OF THE SYMBOLS USED Some of the symbols indicated below may not be used in the manual. Toxic material hazard Laser beam hazard Explosive material hazard Low temperature danger - freezing Electric shock hazard General Risk Electromagnetic field hazard Obligation to read the instructions Flammable material hazard Safety glasses required...
  • Page 9 This is not a safety symbol. It indicates a hazardous situation which, if not avoided, may result in material damage. This is not a safety symbol. It indicates important information.

  • Page 10: Safety Rules

    4 SAFETY RULES The technology used for the design and manufacturing control of TXRiD makes it a reliable, simple and safe device to use. The personnel in charge of using the tools are required to follow the general safety rules, to use the TXRiDdevices for their intended use only and to carry out the maintenance correctly as described in this manual.

  • Page 11: General Rules

    4.3 General Rules The operator must have carefully read and fully understood all the information and instructions in the technical documents provided with the tool.If the operator cannot read this manual, it is responsibility of the owner of the equipment/employer/person in charge of the safety to illustrate the contents of this document and adequately train the operator in relation to the operating instructions and safety measures for a proper use of the tool.

  • Page 12: Operator Safety

    4.4 Operator Safety Using and handling refrigerant fluid may pose serious risks for your health. Inhaling refrigerant fluid is harmful to health. If the fluid comes into contact with the eyes, it may cause even serious visual disturbances. Due to the low boiling temperature (approximately -30 °C) of the refrigerant fluid, it can cause cold burns when it comes into contact with the operator's skin.
  • Page 13 The tool was designed and manufacturer for the specific intended use indicated in this Manual. The tool must be used in compliance with this Manual, the documentation and any other instructions provided by the manufacturer. Any use not compliant with these provisions expose the operator to the risk of damages and/or injuries.

  • Page 14: Tool Safety

    4.5 Tool Safety The tool was designed to be used in specific environmental conditions. Using the tool in environments with temperature and humidity values that differ from those specified may impair its efficiency. Safety Measures: • Place the tool in a dry place. •...
  • Page 15 Using the tool not in compliance with the indications provided in this manual may alter its manufacturing technical and safety features. Any contamination with refrigerant fluids that are different from the ones indicated in this manual may severely damage the A/C system in the vehicle and the tool itself. Safety Measures: •...

  • Page 16: Operation Of The Radio Devices

    The Bluetooth, WiFi and 2G / 3G / 4G interfaces look for compatible electronic devices according to the radio signal they emit and establish a connection between them. TEXA tools select and only prompt you with compatible TEXA devices. This does not exclude the presence of other sources of communication or disturbance.

  • Page 17: Environmental Information

    6 ENVIRONMENTAL INFORMATION Do not dispose of this product with other undifferentiated solid waste. For information regarding the disposal of this product please see the pamphlet supplied.

  • Page 18: Normative Information

    7 NORMATIVE INFORMATION The manufacturer, TEXA S.p.A., declares that the radio equipment type TXRiD is compliant with the following directives: • RED 2014/53/EU • RoHS 2011/65/EU and Delegated Directive 2015/863/EU The complete text of the EU declaration of conformity is available at the following Internet address http://www.texa.it/download.

  • Page 19: Txrid

    8 TXRiD TXRiD is a portable tool that identifies the type and purity of the refrigerant fluids contained in cylinders and inside the vehicle's A/C system. A fluid that is NOT pure may cause corrosion in the components and even serious faults in the vehicle's A/C system.

  • Page 20: Description

    9 DESCRIPTION TOOL 1. ON/OFF button 2. Touch display 3. USB connector 4. Handle 5. Air filter 6. GAS IN 7. GAS OUT 8. Handle 9. Connector for external power adapter 10. Data plate 11. Battery compartment 12. Printer compartment...
  • Page 21 POWER ADAPTER 13. External power adapter 14. Plug for external power adapter SAMPLE HOSE 15. GAS IN fitting 16. Hose 17. Oil separator filter 18. Pressure damper 19. LP coupler ) The thermal printer is an accessory that can be purchased separately. ) The power adapter is supplied with a set of interchangeable plugs.

  • Page 22: Technical Features

    10 TECHNICAL FEATURES Manufacturer: TEXA S.p.A. Product name: TXRiD Power supply: 12 V External power adapter: • Model: SMI24-12-V-P5-C3 • Input: 100 - 240 V~; 50 - 60 Hz; 0.58 A Charger: • Output: 12 V ; 2 A ; 24 W •...
  • Page 23 • Use:internal • Altitude (up to): 2000 m • Supply voltage fluctuations: ± 10% Environmental • Overvoltage category: II conditions: • Power adapter pollution degree: 2 • Tool pollution degree: 3 • Maximum relative humidity 80% for temperatures up to 31 °C, linearly decreasing to 50% at 50 °C RED 2014/53/EU Directives:...

  • Page 24: Power Supply

    11 POWER SUPPLY The tool can be powered: • from the mains using an external power adapter; • by internal batteries. The presence of power supply is indicated in the display through a specific icon. 11.1 Power supply from the Mains It is possible to power the tool by connecting it to the mains via a specific power adapter provided with the tool.
  • Page 25 Proceed as follows: 1. Insert the plug in the specific housing on the power adapter. 2. Connect the jack connector on the power adapter [1] to the connector for powering the tool [2]. 3. Connect the plug on the power adapter [3] to the mains socket [4].

  • Page 26: Power Supply From Battery

    11.2 Power supply from battery The tool is powered by an internal rechargeable battery. The battery power supply allows powering the tool without the use of cables, making it therefore easy to move the tool from one work area to another. The battery power supply allows continuous use of the tool for approximately 5 hours.

  • Page 27: Battery Recharge

    11.2.1 Battery recharge It is possible to charge the tool by connecting it directly to the mains via a specific external power adapter. The tool is able to work normally while being recharged. The battery can be charged with the tool switched on or off. The charge status is indicated by a specific icon.

  • Page 28: Power On/Off

    12 POWER ON/OFF The tool's activation and deactivation is commanded pressing the ON/OFF button. The button is back lit by a green LED through which the tool provides indications on its status. Button Tool status Notes The tool is operational. Short period of inactivity.

  • Page 29: Power On

    12.1 Power on To turn on the tool proceed as follows: 1. Keep the ON/OFF button pressed until the green LED lights up. 2. Wait for the software to start. 3. The tool is ready for use when the HOME screen appears.

  • Page 30: Shutdown And Standby

    12.2 Shutdown and Standby Turning off in other ways rather than the ones indicated may damage the tool. Do not turn off the tool by disconnecting it from the mains. To turn off the tool proceed as follows: 1. Keep the ON/OFF button pressed until the shutdown screen is displayed. 2.

  • Page 31: Forced Shutdown

    12.3 Forced Shutdown In case of need (ex.: the software does not respond to the commands), the tool can be forced to shutdown. The shutdown causes the interruption of any activity in progress and the non-stored data is lost. Proceed as follows: 1.

  • Page 32: Communication

    13 COMMUNICATION The Wi-Fi module installed in the tool makes it able to: • connect to the Internet, to receive updates for the installed software; • print the fluid identification reports on the network printer. To be able to use the identification functions, you must have carried out the software activation procedure.

  • Page 33: Preparing For Use

    14 PREPARING FOR USE Do not place the tool on hot surfaces. Avoid prolonged exposure to external chemical agents. Position the tool as close as possible to the vehicle or the cylinder, being careful to place it stably on the resting surface.

  • Page 34: Use

    15 USE The software provides on-screen indications required in order to carry out the various operations and warns if errors occur during the phases. Inserting into the tool's analysis chamber refrigerant in a liquid status may compromise the analysis capability and functionality.

  • Page 35: Update

    16 UPDATE The software in the tool updates automatically. The tool must be connected to a Wi-Fi network that can access Internet to check if updates are available and eventually download them. It is important to guarantee that the download and installation of the update can be completed without interruptions.
  • Page 36 No analyses or other operations can be carried out with the tool during the installation. In some cases the software restarts the tool automatically at the end of the installation.

  • Page 37: Accessories

    17 ACCESSORIES 17.1 Printer The thermal printer is an accessory that can be purchased separately. Following is the procedure for the installation. Installing the printer requires accessing the inside of the tool. During the installation, be careful to not damage the cables needed to connect the printer or any other tool component.
  • Page 38 4. Remove the screw that fastens the battery compartment's cover. 5. Remove the battery compartment cover as indicated. 6. Disconnect the tool's power wiring from the battery.
  • Page 39 7. Connect the wiring as indicated in the image. 8. Reconnect the power wiring as indicated. 9. Place the battery and printer in their related compartments. 10. Lift the printer's flap and secure it to the tool using the two screws removed previously.
  • Page 40 11. Remount the battery compartment's cover and secure it using the screw removed previously. The printer is automatically on-line when the tool is switched on.

  • Page 41: Maintenance

    Only use spare parts and accessories that are approved by the manufacturer. Contact you retailer for any maintenance operation that is not described below. You can see the list of authorised retailers at the following address:https://www.texa.com/ sales-network...

  • Page 42: Replacing The Air Filter

    18.1 Replacing the Air Filter The air filter must be replaced when indicated by the software and in any case once a year. Icon Description The degree of the air filter wear is indicated by the percentage value displayed by the software beside the icon.
  • Page 43 2. Screw in the new filter manually being careful not to tighten it excessively. 3. Turn on the tool. 4. Access the filter counter reset function:SETTINGS>FILTER RESET 5. Follow the instructions that appear on screen. For further information see the software's Operating Manual.

  • Page 44: Battery Replacement

    18.2 Battery Replacement The battery must be replaced when the complete charge no longer allows normal use of the tool. Proceed as follows: 1. Unscrew the screw that blocks the battery compartment's cover. 2. Remove the compartment's cover.
  • Page 45 3. Delicately extract the battery from its housing being careful not to damage the wiring it is connected to. 4. Disconnect the tool's power wiring from the battery.
  • Page 46 5. Connect the new battery to the tool's power wiring. 6. Place the new battery in the specific housing being careful to position the wiring properly inside the compartment. 7. Reposition the compartment's cover being careful to not pinch the power wiring and any other wiring in the compartment.

  • Page 47: Replacing The Flexible Hose - Oil Separator Filter

    18.3 Replacing the Flexible Hose - Oil Separator Filter The assembly made up of the flexible hose and the oil separator filter must be replaced when the filter is visibly dirty, changes colour or in any case once a year. The procedure indicated below is valid for both sample hoses.

  • Page 48: General Cleaning Of The Tool

    18.4 General Cleaning of the Tool The tool must be kept clean. Use a moist cloth to clean the tool. Do not use corrosive chemicals, solvents or harsh detergents to clean the tool.

  • Page 49: Solutions To Problems

    19 SOLUTIONS TO PROBLEMS For any technical problem contact your retailer/distributor. Below you will find a list of simple instructions that the client can carry out without having to ask for technical assistance. PROBLEM POSSIBLE SOLUTION Make sure the power adapter cable is connected to the mains.

  • Page 50: Legal Notices

    20 LEGAL NOTICES TEXA S.p.A. Via 1 Maggio, 9 - 31050 Monastier di Treviso - ITALY Tax Code - Company Register of Treviso ID No. - VAT No.: 02413550266 Single-shareholder company subject to the direction and coordination activities of Opera Holding S.r.l.
