Air to Water Heat Pump
User manual
AE200DN**** / AE160DN**** / MIM-E03FN
• Thank you for purchasing this Samsung Product.
• Before operating this unit, please read this manual carefully and retain it for future reference.
DB68-12922A-02_IB_24Y EHS AE7000D_EU_EN_.indd 1
DB68-12922A-02_IB_24Y EHS AE7000D_EU_EN_.indd 1
2024-12-11 오전 10:04:37
2024-12-11 오전 10:04:37

Advertisement

loading
Need help?

Need help?

Do you have a question about the AE200DN Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Samsung AE200DN Series

Summary of Contents for Samsung AE200DN Series

  • Page 1 Air to Water Heat Pump User manual AE200DN**** / AE160DN**** / MIM-E03FN • Thank you for purchasing this Samsung Product. • Before operating this unit, please read this manual carefully and retain it for future reference. DB68-12922A-02_IB_24Y EHS AE7000D_EU_EN_.indd 1 DB68-12922A-02_IB_24Y EHS AE7000D_EU_EN_.indd 1...
  • Page 2 Contents Safety Information Safety Information Power Smart Features Controller Operation Operating basic modes Domestic Hot Water (DHW) mode Adjusting desired temperature • Setting the standard temperature Power Smart Features Operation status • Quiet mode • Away mode SmartThings app SmartThings app Energy-Saving Operation Energy-saving operation Setting a schedule •...
  • Page 3 Hereby, Samsung declares that this radio equipment is in compliance with Directive 2014/53/EU and with the relevant statutory requirements in the UK. The full text of the EU declaration of conformity and the UK declaration of conformity is available at the following internet address: http://www.samsung.com, go to...

  • Page 4: Safety Information

    Safety Information Safety Information This content is intended to protect the user’s safety and prevent property damage. Please read it carefully for correct use of the product. WARNING Hazards or unsafe practices that may result in severe personal injury or death. CAUTION Hazards or unsafe practices that may result in minor personal injury or property damage.
  • Page 5 FOR OPERATION WARNING If the appliance generates a strange noise, a burning smell or smoke, unplug the product immediately and contact your nearest service centre. • Failing to do so may result in electric shock or fire. To reinstall the product, please contact your nearest service centre. •...

  • Page 6: Controller Operation

    Power Smart Features Controller Operation Operate the product by using the controller. Operating basic modes Select Zone 1 or 2 on the control card on the Home screen to access the zone page, and select from Auto, Cool, Heat modes. Auto mode Hydro unit will automatically adjust the temperature of discharge water with the Auto mode for indoor heating.
  • Page 7 Domestic Hot Water (DHW) mode Select DHW on the control card on the Home screen to access the DHW page. Select from Economic, Standard, Power, and Forced modes. NOTE • To operate hot water mode, you need to set the hot water function 'YES' in the field specification setting mode (#3011) of AI Home and connect the temperature sensor of hot water tank.
  • Page 8 Controller Operation Adjusting desired temperature On each zone page, touch Temp and scroll up/down to adjust the temperature. NOTE • You can adjust the desired temperature by 0.5 or 1 °C. (Default: 1 °C) Setting the standard temperature On the Home screen, select >...

  • Page 9: Power Smart Features

    Power Smart Features There is a variety of useful functionality provided by the Samsung product. Operation status Swipe on the Home screen and select the Overview card. This allows the product’s operation to be checked. The below operations can be checked on the Overview screen.
  • Page 10 SmartThings app SmartThings app You will need a Samsung account to access AI Home, our network-based service that includes apps and our other smart features available through your device. Checking the power connections Check if the power is connected to the product and the access point.
  • Page 11 NOTE • If you already have a Samsung account, log in to the account. When your smartphone is a Samsung device and you have a Samsung account, your smartphone is automatically logged in to your account. • If you log in from a smartphone produced for a different country, you need to log in with its country code when you create your Samsung account, and the SmartThings app may not be used on some smartphones.
  • Page 12 • If any pop-window appears on the top of the smartphone while connecting to your product, do not select • If a Samsung account-related country error occurs during connecting to your product, log out of your current Samsung account, log in to your previous Samsung account, and then delete all devices that have been connected previously.

  • Page 13: Energy-Saving Operation

    Energy-saving operation Setting a schedule Set a schedule to have the product perform a specific operation on a set day, at a set time, for a set period. Swipe on the Home screen to display the Schedules card. Touch the "+" icon on the top right of the screen to create a schedule.

  • Page 14: Setting Options

    Home screen, and select from the setting options. General Settings and Heat Pump Settings are available. General settings Step 1 Step 2 Step 3 Description Default Samsung account input/ Samsung Account display Wi-Fi Wi-Fi on or off Bluetooth Connections SmartThings QR code...
  • Page 15 Step 1 Step 2 Step 3 Description Default Reset network Reset connected network settings settings Reset Reset all settings Reset all settings Restart Restart Status information Display device info (version) Device network info (MAC, BLE) AI Home Legal information Privacy notice About device Privacy Notice Terms of Service for...
  • Page 16 Setting Options Heat pump settings Step 1 Step 2 Step 3 Description Default Quiet mode Quiet mode on or off Quiet Schedule Quiet Schedule Quiet mode mode on or off A2A (cooling) Select a priority between Priority (A2A/DHW) A2A or DHW DHW (heating/hot (TDM product Only) water)
  • Page 17 Installation/Service mode Accessing Service mode On the Home screen, select > Heat pump > Service information. When "Customer service contact" is displayed, touch the display 10 to 15 times in quick succession to access Service mode. Heat pump FSV options can be set in Service mode. NOTE •...
  • Page 18 Installation/Service mode Installation/Service mode NOTE • Unavailable functions are marked inactive and they cannot be set. • If communication initialization is needed after the setting, the system will reset automatically and communication will be initialized. Step 1 Step 2 Step 3 Description Default Enter service...
  • Page 19 Step 1 Step 2 Step 3 Description Default Used / Not used When Used is selected, select from Activating hot water Control hot water Used / Not used (*1) function (3011) Note 3) thermo type 1 and Control hot water thermo type 2 Thermostat #1 UFHs (2091) Using the thermostat...
  • Page 20 Installation/Service mode Step 1 Step 2 Step 3 Description Default Min water out temp 17 to 55/65/70/75℃ 25℃ (*2) for Water Law 1 (2022) Max water out temp 17 to 55/65/70/75℃ 50℃ (*2) for Water Law 2 (2031) Min water out temp 17 to 55/65/70/75℃...
  • Page 21 Step 1 Step 2 Step 3 Description Default Water Law 2 5 to 25℃ 25℃ temperature (5016) Away mode settings DHW tank 30 to 70℃ 30℃ temperature (5019) Max temp for heat 45 to 53/55/63/70℃ 53/55/63/70℃ (*2) (*2) pump (3021) Heat pump thermo off 0 to 10℃...
  • Page 22 Installation/Service mode Step 1 Step 2 Step 3 Description Default On/Off Self-test mode display Water pump On/Off Booster heater On/Off DHW valve (3way valve) On/Off Self-test mode Self-test mode display 2way valve 1 Backup heater1 Backup heater2 Backup boiler 2way valve 2 Mixing valve Product Indoor unit product info...
  • Page 23 NOTE • Address is displayed in hexadecimal. Please refer to the following table. Hexadecimal Decimal Hexadecimal Decimal Hexadecimal Decimal Hexadecimal Decimal Hexadecimal Decimal English DB68-12922A-02_IB_24Y EHS AE7000D_EU_EN_.indd 23 DB68-12922A-02_IB_24Y EHS AE7000D_EU_EN_.indd 23 2024-12-11 오전 10:04:40 2024-12-11 오전 10:04:40...

  • Page 24: Field Setting Mode

    Field Setting Mode Field setting mode Air to Water Heat Pump: Only AE***DN**** / MIM-E03FN Model CAUTION • Set the FSV value of the product other than the specified models by referring to the FSV label provided with the manual of the product, and then attach it on the control box's cover. The FSV values in the table are applied to the specified models.
  • Page 25 AI Home Setting Range: Code 10** Space Cooling (FSV#1011~1022) • Target water outlet temperature : Upper limit(#1011, Default 25℃, Range : 18 ~ 25℃), Lower limit(#1012, Default 16℃, Range : 5 ~ 18℃) – With this default FSV settings, user can change the target water outlet temperature within the range of 16 ~ 25℃...
  • Page 26 Field setting mode Field Setting Value (FSV) 20** Code 20** : Water law design and external room thermostat Heating(2 WL’s for floor & FCU), Cooling(2 WL’s for floor & FCU), WL & Thermostat types • The values in the following table are just examples for your understanding. MODEL CODE : AE***DN*MPK / MODEL CODE : AE***DN*SPG / MIM-E03FN...
  • Page 27 Water Law & Room Thermostat / AI Home: Code 20** Heating WL Ts : Target Temp. at Floor/at FCU Cooling WL Ta : Ambient Temp. #2021/2031 #2022/2032 #2061/2071 #2062/2072 #2011 #2012 #2051 #2052 Water Law for Heating (FSV#2011~2041) • Outdoor air temperature range : Lower limit (#2011, Default -10℃, Range : -20 ~ 5℃), Upper limit (#2012, Default 15℃, Range : 10 ~ 20℃)
  • Page 28 Field setting mode External Room Thermostat (Field Option) (FSV#2091/2092) • Room thermostat #1 (#2091, Default 0 for no usage), #2 (#2092, Default 0 for no usage) – To use AI Home for heating/cooling operation, both of the above settings should be set to 0 simultaneously.
  • Page 29 • Thermostat #2 which controls FCU has the priority for operation modes and the discharge water temperature. • Samsung is not responsible for the accidents such as floor condensations which can occur by not connecting the floor valve to the 2 way valve #1 port of the Hydro Unit PBA.
  • Page 30 Field setting mode Field Setting Value (FSV) 30** Code 30** : User’s options for Domestic Hot Water(DHW) tank heating • The values in the following table are just examples for your understanding. MODEL CODE : AE***DN*MPK / MODEL CODE : AE***DN*SPG / MIM-E03FN AE***DN*THP Function...
  • Page 31 NOTE • The value is determined according to the type of outdoor unit. (*1) • : Applies to the AE200DN**** model. (*3) • : Applies to the AE160DN****/MIM-E03FN models. (*4) DHW Heating : Code 30** DHW Application (FSV#3011) The FSV #3011 in the AI Home should be set to 1 or 2 to use DHW function. If FSV #3011 is set to 1, the DHW operation starts based on the thermo on temperature.
  • Page 32 Field setting mode [DHW Tank water temperature thermo on/off control] > T < T HP MAX HP MAX Tu : User set temp. T(C) T(C) T(C) : Temp. (Celsius) #3021 #3021 HP MAX HP MAX #3022 HP OFF #3023 HP OFF #3023 HP ON HP ON...
  • Page 33 Booster Heater Variables for Controlling DHW Tank (FSV#3031~3033) • The FSV #3031 should be set to "1(On)" (Default) to use booster heater as an additional heat source for DHW tank. • Booster heater startup delay timer : In case of DHW request, this timer will delay the operation of booster heater compared to heat pump.
  • Page 34 Field setting mode <Example of using BSH in hot water supply> Case 1) When set temperature is 70℃ BSH is ON at less than 68 degrees, OFF at more than 70℃. Case 2) When setting temperature is 50℃ (FSV 3022 = 0 condition) Heat pump and BHS are ON at less than 45 degrees, OFF at more than 50℃...
  • Page 35 Disinfection Function 1) "Booster heater" Disinfection • The FSV #3041 should be set to "1 (On)" (Default) to use disinfection function. – Scheduling : Day (#3042, Default "Friday"), starting time (#3043, Default "23:00"), target tank temp. (#3044, Default "70℃"), duration (#3045, Default 10 min.) [Time variation control of Heat pump and booster heater of DHW] #3045 #3044...
  • Page 36 Field setting mode NOTE • Disinfection function is available only when a booster heater is connected. However, when setting FSV#6051, it is possible to replace it with a backup heater. (However, AE***CXY*** is also capable of Heat Pump Disinfection.) • R290 Mono Outdoor unit (AE***CXY**G) can be operated in disinfection mode without a booster heater. •...
  • Page 37 Field Setting Value (FSV) 40** Code 40** : User’s options for heating devices including internal backup heater and external boiler • The values in the following table are just examples for your understanding. MODEL CODE : AE***DN*MPK / MODEL CODE : AE***DN*THP AE***DN*SPG / MIM-E03FN Function Main Code...
  • Page 38 Field setting mode MODEL CODE : AE***DN*MPK / MODEL CODE : AE***DN*THP AE***DN*SPG / MIM-E03FN Function Main Code Menu Code Setting Standard Setting Standard Item Step Unit Default Min. value Max. value Default Min. value Max. value 1 (Yes) (*5) (*5) (*5) 1 (Yes)
  • Page 39 Additional heating option : 40** Heat Pump Variables for Space Heating (FSV#4011~4013) • FSV #4011 for DHW priority is set to "0(DHW)" as a default. Space heating gets a priority by setting FSV #4011 "1", but this is only valid when the outdoor temperature is lower than the specified temperature defined by FSV #4012.
  • Page 40 Field setting mode External Backup Boiler for Space Heating (Field Option) (FSV#4031~4033) • The FSV #4031 should be set to "1 (Yes)" to use a backup boiler as an additional heat source. (default: "0 (No installation)") • Priority of backup boiler and heat pump is defined by FSV #4032 (default: "0 (OFF)") •...
  • Page 41 Inverter Pump Installation (Field Option) (FSV#4051~4054) • FSV #4051=1 (Default) : Inverter pump use + Max PWM output 100%, FSV #4051=2 : Inverter pump use + Max PWM output 85%, FSV #4051=3 : Inverter pump use + Max PWM output 70%, FSV #4051=0 : Fixed pump.
  • Page 42 Field setting mode Field Setting Value (FSV) 50**/60** Code 50**/60** : User’s options for extra functions • The values in the following table are just examples for your understanding. MODEL CODE : AE***DN*MPK / MODEL CODE : AE***DN*THP AE***DN*SPG / MIM-E03FN Function Main Code Menu...
  • Page 43 MODEL CODE : AE***DN*MPK / MODEL CODE : AE***DN*THP AE***DN*SPG / MIM-E03FN Function Main Code Menu Code Setting Standard Setting Standard Item Step Unit Default Min. value Max. value Default Min. value Max. value Application 5091 0 (No) 1 (Yes) 0 (No) 1 (Yes) Setting Temp Shift...
  • Page 44 Field setting mode Others : Code 50**/60** Away mode (FSV#5011~5019) • All the target temperatures – space heating and cooling, water law, DHW, Room temperature – are set to the values defined in the above table under the Away mode. NOTE •...
  • Page 45 TDM variables (FSV #5031~5033) • Under the installation of both A2A (Air-To-Air type air conditioner) and A2W (Air-To-Water type hydro unit) at the same time, our outdoor machine can supply its full capacity to the operating indoor machines (including A2A or A2W). If there are simultaneous operating demands from many A2A machines with A2W, the priority of controlling the outdoor machine (ex: compressor frequency) will be given to A2A, because of their fast response for use’s comfort.
  • Page 46 Field setting mode Peak Power Control (FSV#5041~5043) • If users make contracts with local electric power company for limiting the amount of power consumption when a surge in power usage, users can set FSV of "Forced off". • The setting of FSV#5041 (default "0", No use) determines whether to use Peak power control. •...
  • Page 47 • Cooling mode (FSV #5082 = 2℃, Default) – Room sensor setting: Current setting value - FSV #5082 (Min = FSV #1022) – Water outlet setting: Current setting value - FSV #5082 (Min = FSV #1012) – Water law setting: Current setting value - FSV #5082 (Min = FSV #2061, #2062, #2071, #2072) •...
  • Page 48 Field setting mode DHW mode • The booster heater operates with the heat pump immediately without delay. – #5094=0 : Target setting temperature is 55/63/70℃ . FSV#3021 (Maximum DHW tank temperature (*1) with the heat pump operation) – #5094=1 : Target setting temperature is 70℃. [If FSV #3031 is 0 (no use booster heater) or DHW mode is economic mode, it does not activate booster heater.] Heating mode...

  • Page 49: Maintaining The Unit

    This maintenance should be carried out by SAMSUNG local technician. Besides keeping the AI Home and remote controller clean by means of a soft damp cloth, no maintenance is required by the operator.
  • Page 50 Maintaining the Unit <Emergency hot water supply_(when DHW on (FSV#3011) and Booster Heater on (FSV#3031)) • Hot water is supplied only by the booster heater if the outdoor unit malfunctions. Method 1 (AI Home setting) • Enabling the function: Select Emergency hot water supply ( >...

  • Page 51: Troubleshooting Tips

    Troubleshooting tips It the unit has some problem to work properly, error codes will be displayed on the AI Home. The following table describes the explanation of the error codes. Display Explanation Short- or open-circuit error of the room temperature sensor of the Zone 2 indoor unit (detected only when the AI Home temperature data is used) Short- or open-circuit error of the room temperature sensor of the Zone 1 indoor unit (detected only when the AI Home temperature data is used)
  • Page 52 Troubleshooting tips Communication Display Explanation Wi-Fi communication error Communication error between AI Home and the Hydro unit Tracking error between AI Home and the Hydro unit Memory(EEPROM) Read/Write Error (AI Home data error) Controller combination error E601, E604 E654 • MEMORY(EEPROM) Read/Write Error (AI Home data error) EEPROM Thermistor Micro...
  • Page 53 Water pump & Flow Sensor Display Explanation Low flow rate error • in case of low flow rate in 30 sec during water pump signals is ON(Starting) • in case of low flow rate in 15 sec during water pump signals is ON(After starting) E911 •...

  • Page 54: Error Codes

    Error codes Display Explanation Error Source Hydro Unit / Outdoor Unit communication connection error Hydro Unit Wi-Fi communication error Hydro Unit Address incomplete communication error Hydro Unit Short- or open-circuit error of the room temperature sensor of the Zone 2 Hydro Unit indoor unit (detected only when the AI Home temperature data is used) Short- or open-circuit error of the room temperature sensor of the Zone 1...
  • Page 55 Display Explanation Error Source Protection of Outdoor Unit when it is overload (during Safety Start, Outdoor Unit Normal operation state) Comp down due to high pressure sensor Outdoor Unit Comp down due to low pressure sensor Outdoor Unit Discharge of a compressor is overheated Outdoor Unit OUTDOOR UNIT EEV operation error Outdoor Unit...
  • Page 56 Error codes Display Explanation Error Source Input current sensor error Outdoor Unit AC Input Voltage Sensor Error Outdoor Unit IPM is overheated Outdoor Unit Comp down due to high pressure switch Outdoor unit PHE refrigerant leak error Outdoor unit Gas leak error Outdoor Unit Inverter EEPROM Checksum error Outdoor Unit...
  • Page 57 Display Explanation Error Source Mixing valve sensor error Hydro Unit Water Tank Sensor configuration error Hydro Unit Error that the set temperature for disinfection operation is not reached, or, after reaching, the temperature fails to continue for the requested Hydro Unit time FSV SD card data error Hydro Unit...

  • Page 58: Specifications

    5150 - 5850 MHz 20 dBm Open Source Announcement The software included in this product contains open source software. The following URL http://opensource.samsung.com/opensource/SMART_TP1_0/seq/0 leads to open source license information as related to this product. 58 English DB68-12922A-02_IB_24Y EHS AE7000D_EU_EN_.indd 58 DB68-12922A-02_IB_24Y EHS AE7000D_EU_EN_.indd 58...
  • Page 59 Memo English DB68-12922A-02_IB_24Y EHS AE7000D_EU_EN_.indd 59 DB68-12922A-02_IB_24Y EHS AE7000D_EU_EN_.indd 59 2024-12-11 오전 10:04:49 2024-12-11 오전 10:04:49...
  • Page 60 MOLDOVA +373-22-667-400 support/moldova Samsung, PO Box 12987, Blackrock, Co. Dublin. IE or Euro QA Lab. Saxony Way, Yateley, Hampshire GU46 6GG, UK This appliance is filled with R-32. DB68-12922A-02_IB_24Y EHS AE7000D_EU_EN_.indd 60 DB68-12922A-02_IB_24Y EHS AE7000D_EU_EN_.indd 60 2024-12-11 오전 10:04:49...
