1
!
CAUTION: STATIC SENSITIVE EQUIPMENT
THIS EQUIPMENT IS SENSITIVE TO STATIC ELECTRICITY. IT MAY BE DAMAGED IF NOT PROPERLY
HANDLED. USE A GROUNDING WRIST STRAP AND AN ANTI-STATIC MAT WHEN HANDLING THIS
EQUIPMENT. FAILURE TO OBSERVE THIS REQUIREMENT COULD CAUSE LATENT DAMAGE TO THE
EQUIPMENT WHICH MIGHT NOT MANIFEST ITSELF UNTIL AFTER THE EQUIPMENT IS PLACED IN
SERVICE.
!
CAUTION: DISCONNECT ALL POWER
REMOVE ALL SOURCES OF POWER BEFORE SERVICING, REMOVING OR INSTALLING ANY UNITS.
1 Description
The N-MPS Series Manual Stations are used with a compatible addressable control panel. The addressable manual station
devices are powered by a compatible Notifier
protocol.
NOTE: The information contained in this Installation Instruction is a quick reference guide. For detailed
system information, refer to the panel manufacturer's installation manual. For product information, refer to the
Data Sheet P/N DN-5497. This installation document is generic and will not address specific programming
procedures.
2 Installation
The N-MPS Series manual stations are available as single- or two-stage manual stations. The single- and two-stage
manual stations are available in both addressable and conventional models. All models include screw terminal connectors
and a hex key reset. Two-stage manual stations include a key-switch and 1 key.
2.1 Installation Precautions
Install the N-MPS Series manual stations in accordance with the following precautionary notices.
!
CAUTION: ULC STANDARDS/REQUIREMENTS
INSTALL THE N-MPS SERIES MANUAL STATIONS IN ACCORDANCE WITH THESE INSTRUCTIONS,
APPLICABLE CAN/ULC-S524, STANDARD FOR THE INSTALLATION OF FIRE ALARM SYSTEMS, CAN/ULC-
S528, MANUAL STATIONS FOR FIRE ALARM SYSTEMS, AND CANADIAN ELECTRICAL CODES AND THE
REQUIREMENTS OF THE AUTHORITY HAVING JURISDICTION (AHJ). REGULAR TESTING OF THE
DEVICES SHOULD BE CONDUCTED IN ACCORDANCE WITH THE CAN/ULC-S536, STANDARD FOR THE
INSPECTION AND TESTING OF FIRE ALARM SYSTEMS. FAILURE TO FOLLOW THESE DIRECTIONS MAY
RESULT IN FAILURE OF THE DEVICE TO REPORT AN ALARM CONDITION. THE MANUFACTURER IS NOT
RESPONSIBLE FOR DEVICES THAT HAVE BEEN IMPROPERLY INSTALLED, TESTED OR MAINTAINED.
N-MPS Series Manual Stations
Product Installation Document
PN 53562:B 6/01/2010 10-277
®
data communication link (DCL) using the Notifier communications
12 Clintonville Road
Northford, CT 06472-1610 USA
203-484-7161 • FAX 203-484-7118
www.notifier.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the Notifier N-MPS Series and is the answer not in the manual?

Questions and answers

Related Manuals for Honeywell Notifier N-MPS Series

Summary of Contents for Honeywell Notifier N-MPS Series

  • Page 1 12 Clintonville Road Northford, CT 06472-1610 USA 203-484-7161 • FAX 203-484-7118 www.notifier.com N-MPS Series Manual Stations Product Installation Document PN 53562:B 6/01/2010 10-277 CAUTION: STATIC SENSITIVE EQUIPMENT THIS EQUIPMENT IS SENSITIVE TO STATIC ELECTRICITY. IT MAY BE DAMAGED IF NOT PROPERLY HANDLED.
  • Page 2 WARNING: INSTALLATION HAZARDS RADIO FREQUENCY INTERFERENCE AND ELECTROMAGNETIC INTERFERENCE ARE SOURCES OF NOISE THAT CAN ADVERSELY AFFECT FIRE ALARM SYSTEM INSTALLATIONS. WHEN INSTALLING THE FIRE ALARM SYSTEM DEVICES, AVOID PLACING THE DEVICES OR WIRING CLOSE TO POTENTIAL NOISE SOURCES SUCH AS: •...
  • Page 3 2.3 N-MPS Addressable Series Manual Station Backbox Installation Requirements The following mounting options are available for the N-MPS Addressable Series manual station: • a 10.16 cm (4" square) electrical backbox, (Requires an adapter plate, Part Number: RMS-TP3) • a 2 gang electrical back box, (Requires an adapter plate, Part Number: RMS-TP1) •...
  • Page 4 2.4 N-MPS Addressable Series Module Addressing Four Easy Steps: To install the module in a secure position, do the following steps. To loosen the two (2) securing screws, use a Phillips screwdriver and turn the screws counter-clockwise. (These screws are not intended to be removed). (See Figure 2.4.1 and Figure 2.4.2) 2.

  • Page 5: Wiring Connections

    3 Wiring Connections 3.1 N-MPS Addressable Series Manual Station Wiring Connections Figure 3.1.1 illustrates the wiring connections using DCLA and DCLB for the N-MPS Addressable Series manual station. Data Com m unication Link (DCLA, Sim ilar to Class A) DCL + ULC Listed ULC LISTED Notifier...
  • Page 6 3.2 N-MPS Conventional Series Manual Station Wiring Connections (Continued) Figure 3.2.1 illustrates the wiring connections using Style A and Style B for the N-MPS Conventional Series manual station. Class A IDC Return (Style A) IDC + ULC LISTED ULC Listed Notifier NOTIFIER IDC -...

  • Page 7: Specifications

    4 Specifications The following are the specifications for the N-MPS Series manual stations. Specifications - Addressable Models Normal Operating Voltage: 24.0 VDC Maximum SLC Voltage: 32.0 VDC Maximum SLC Current: Single-stage 550 µA, Two-stage 6.4 mA Operating Temperature: 32° F to 120° F (0° C to 49° C) Ambient Temperature: 32°...
