- Page 1 INSTALLATION AND MAINTENANCE MANUAL FOR JOCKEY PUMP CONTROLLERS MODEL JPLT V2025.02...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Important Safety Information Introduction Technical Data Installation Storage Seismic Environment Electromagnetic compatibility (EMC) Handling Location Mounting Wall mounting Making System Pressure Connections Making Electrical Connections Important Precautions Procedure Operator Interface How to configure the controller Methods of Starting/Stopping Automatic mode Manual mode Off mode Bump for rotation Commissioning Preventive Maintenance Program Factory recommendations Internal verifications External verifications Replacement Intervals V2025.02... -
Page 3: Important Safety Information
De-energize the power supply to the controller. The controller must be completely disconnected from the power source, and the disconnect switch must be in the “off” position in order to open the enclosure door. Tornatech cannot be liable for any misapplication or incorrect installation of its products. - Page 4 Warning: This product can expose you to chemicals including lead and lead compounds, which are know to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to: www.P65Warnings.ca.gov V2025.02...
-
Page 5: Introduction
INTRODUCTION Tornatech J ockey Pump Controllers are intended for use with fire pump systems. They are used for pres- sure maintenance in fire pump installations to prevent unnecessary cycling of the main fire pump. They are listed by Underwriters’ Laboratories, Inc., in accordance with UL508A, Standard for Industrial Controllers. They are built to meet or exceed the requirements of the approving authorities as well as NEMA and the latest edition NFPA 70 National Electrical Code. They also comply with the requirements of the Electromagnetic Compatibility (EMC) Directive 2014/30/EU, the Low Voltage Directive (LVD) 2014/35/EU, the Electromagnetic Compatibility Regu- lations (2016 No. 1091) and The Electrical Equipment (Safety) Regulations (2016 No. 1101). These instructions are intended to assist in the understanding of the installation and operation of these controllers. Read the instructions thoroughly prior to connecting or operating the controller. If there are any unanswered questions, please contact the local Tornatech representative or the factory service department. TECHNICAL DATA Rating Value Rated Operational Current Ie According to the Motor (HP/kW) Rated Insulation Voltage Ui 690, 600 (IEC) Rated Operational Voltage Ue According to the controller rating label Rated Impulse Withstand Voltage Uimp 6000V Rated Operational Frequency 50/60Hz Standard environmental temperature 4°C - 40°C Altitude ≤ 2000m Relative humidity 5% to 80% Pollution degree Short Circuit Current Rating Icc (SCCR) (A) According to the controller rating label Rated Peak Withstand Current Ipk According to IEC 61439-1:2020 Table 7 Standard degree of protection... -
Page 6: Installation
INSTALLATION STORAGE If the controller is not installed and energized immediately, Tornatech recommends following the instructions in chapter 3 of NEMA ICS 15. SEISMIC Jockey Pump controllers are optionally seismic approved and has been tested in accordance with the ICC-ES AC156, IBC 2015 & CBC 2013 standards. Proper installation, anchoring and mounting is required to validate this compliance report. Refer to this manual and drawings to determine the seismic mount- ing requirements and location of the center of gravity (you may need to contact factory). The equipment manufacturer is not responsible for the specification and performance of anchorage systems. The struc- tural engineer of record on the project shall be responsible for anchorage details. The equipment install- ation contractor shall be responsible for ensuring the requirements specified by the structural engineer of record are satisfied. If detailed seismic installation calculations are required, please contact the man- ufacturer for the performance of this work. ENVIRONMENT Jockey Pump controllers are intended to be installed in locations where ambient temperatures are within 4°C - 40°C and the relative humidity is controlled between 5% and 80%. Optionally, the controller can have an extended temperature of up to 55 °C and as low as -5°C, provided that the controller and the pressure water pipes are heated to prevent water freezing and damaging the electronics and the pip- ing system. They are intended for pollution degree 3 and shall be installed at an altitude of no more than 2000 meters. For abnormal installation environment, consult factory. ELECTROMAGNETIC COMPATIBILITY (EMC) Jockey Pump controllers have been tested for the most stringent conditions for emissions (Environment B) and immunity (Environment A), hence controllers can be installed in either environment. All con- trollers variants share the same electronics and comply to those criteria without requiring additional measures. HANDLING The weight of each Jockey Pump controller is indicated on the packing label. Lightweight controllers do not require special handling instructions, while heavy controllers are equipped with lifting means and should be handled following the guidelines specified in Tornatech's document "Large Enclosure Safe Handling Requirements_PN12162021". LOCATION Consult the appropriate job plans to determine the controller mounting location. -
Page 7: Mounting
damaged by water escaping from pump or pump connections. Current carrying parts of the controller shall be not less than 12 in. (305 mm) above the floor level. Working clearances around controller shall comply with NFPA 70, National Electrical Code, Article 110 or C22.1, Canadian Electrical Code, Article 26.302 or any applicable local codes. The standard controller enclosure is rated NEMA Type 2. It is the installer’s responsibility to insure that either the standard enclosure meets the ambient conditions or that an enclosure with an appropriate rating has been provided. Controllers must be installed inside a building and they are not designed for outside environment. T he paint color may change if the controller is exposed to ultraviolet rays for a long period of time. MOUNTING WALL MOUNTING Refer to the controller dimension drawing for necessary mounting dimensions. The controller is wall mounted by using at least four (4) wall anchors, 2 anchors for the top mounting brackets and 2 anchors for the bottom mounting brackets. The brackets are dimensionally on the same centerline for ease in mounting. There should be a clearance of at least 6 inches (152mm) around the controller to allow proper air circulation around the equipment. 1. Using either the dimension print or by measuring the distance between the center lines of the lower bracket slots, transcribe this dimension on to the wall. Note: The bottom edge of the enclos- ure should be a minimum of 12” (305mm.) from the floor in case flooding of the pump room occurs. 2. Drill and put anchors into the wall for the lower mounting brackets. 3. Mark on the wall, the location of the holes in the upper mounting brackets. 4. Drill and put anchors into wall for the upper mounting brackets. 5. Install bolts and washers in lower anchors. 6. ... -
Page 8: Making Electrical Connections
Failure to do so may cause Death, serious personal injury, damage the controller and subsequently void warranty. Prior to making any field connections 1. Open door of enclosure and inspect internal components and wiring for any signs of frayed or loose wires or other visible damage. 2. Verify that the controller information is what is required on the project: 1. Tornatech catalog number 3. Project's electrical contractor must supply all necessary wiring for field connections in accordance with the National Electrical Code, local electrical code and any other authority having jurisdiction. 4. Refer to the appropriate field connection drawing for wiring information. PROCEDURE All field connections, remote alarm functions and AC wiring are brought into the enclosure through c on- duit entrances as indicated on the dimensional drawing. For feet or wall-mounted enclosures, properly ... - Page 9 9. Connect AC power. 10. Check to see that all connections are both correctly wired (in accordance with the field con- nection diagram) and tight. 11. Close the enclosure door. V2025.02...
-
Page 10: Operator Interface
OPERATOR INTERFACE 1. LCD screen 2. Hand-Off-Auto selector 3. Menu navigation buttons. 1. Down / decrease value 2. Enter configuration / enter 3. Up / increase value 4. Integrated alarm buzzer HOW TO CONFIGURE THE CONTROLLER To enter the configuration, press the enter configuration button. Use the up and down buttons to select the value to edit, then press enter. Use the increase or decrease value button to edit the value. Holding those buttons will change the value with an increased speed. Once satisfied with the value, press the enter button. Edited items are not directly applied to the controller and are marked on the screen with an asterisk. Once satisfied with your new values, exit the menu by selecting the first menu line and pressing enter. A V2025.02... -
Page 11: Methods Of Starting/Stopping
confirmation popup will appear asking you to apply the new values to the controller, select "yes" then press enter. You may alternatively discard all changes made by selecting "no". METHODS OF STARTING/STOPPING AUTOMATIC MODE When the mode selector is in automatic, the controller w ill start automatically on low pressure detec- tion by the pressure sensor (below the cut-in threshold). The motor is automatically stopped after the restoration of the pressure (above the cut-out threshold), after a programmable run period timer. MANUAL MODE When the mode selector is in manual, the controller will run the motor continuously. OFF MODE When the mode selector is in off, the motor cannot be started and will be stopped if it was previously running. BUMP FOR ROTATION Successively applying manual mode and off mode to the controller can be used to bump for the motor and check rotation. If the rotation is incorrect, turn OFF power with the door mounted disconnect. Swap any two existing motor lead wires that are on the motor contactor in the controller V2025.02... -
Page 12: Commissioning
COMMISSIONING 1. Verify, and adjust if necessary, the motor overload setting. 2. For three-phase motors, verify the motor rotation by bumping the motor. In case of incorrect rotation, power off the controller and swap two wires at the contactor load side. 3. Enter the configuration menu and input the appropriate values for 1. Pressure unit i f required, in the Advanced sub menu; 2. Cut-out 3. Cut-in; 4. Timer on; 5. Timer off. 4. Exit the configuration menu and save changes. 5. Place the hand-off-auto selector in auto. Cut-out is required to be at least 10 PSI more than cut-in value and should be edited first. V2025.02... -
Page 13: Preventive Maintenance Program
PREVENTIVE MAINTENANCE PROGRAM Pursuant to NFPA 25, Standard for the Inspection, Testing, and Maintenance of Water-based Fire Pro- tection Systems, 2023 edition, a preventive maintenance program must be established according to the manufacturer's recommendations for all components of the pump assembly. T he program must begin after the pump assembly has passed all acceptance tests (See NFPA 25 Section 8.5.1 – 8.5.3 and Table 8.1.1.2 – Maintenance). F ailure to comply could result in loss of life and/or property. T he warranty may also be deemed null and void. The following information outlines the parts and intervals for preventive maintenance recommended by Tornatech to ensure the fire pump controller and associated components are in optimum condition. T he program should be used in conjunction with the general requirements for inspecting and testing out- lined in NFPA 25. FACTORY RECOMMENDATIONS The factory also recommends the following tasks be performed on an annual basis for all controller types: INTERNAL VERIFICATIONS • Check for corrosion on components or circuit boards. • Check for breakdown/fraying of conductor insulation. • Check for any signs of water leakage into controller. • Remove all objects placed inside the panel not associated with the fire pump. EXTERNAL VERIFICATIONS • Check for signs of water leakage on the system pressure sensing lines. • Clean the outside of the controller to remove any dust or other substances that may have accumulated. • Remove all objects placed on top of the panel not associated with the fire pump. REPLACEMENT INTERVALS 2 years • Pressure Transducer... - Page 14 AMERICAS Tornatech Inc. Head Office Laval, Quebec, Canada Tel.: +1 514 334 0523 Toll free: +1 800 363 8448 EUROPE Tornatech Europe SA Mont-Saint-Gilbert, Belgium Tel.: +32(0)10 84 40 01 MIDDLE EAST Tornatech FZE Dubai, United Arab Emirates Tel.: +971(0)4 821 7555 ASIA Tornatech Pte Ltd. Singapore Tel.: +65 6795 8114 Tel.: +65 6795 7823 FOLLOW US www.tornatech.com V2025.02...
