- Page 1 4409 ENCLOSED ANALOG HEAT DETECTOR Fire alarm solutions technical description www.panasonic-fire-security.com...
-
Page 2: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ABBREVIATIONS GENERAL DESCRIPTION 3.1. DETECTOR 3.2. LED 3.3. ADDRESS SETTING CHECK 3.4. EXTERNAL LED 3.5. CONNECTION BOX SET THE COM LOOP ADDRESS SET THE MODE 5.1. COMPATIBILITY TABLE 5.2. ALGORITHMS 5.3. TEST MODE MOUNTING INSTALLATION AND WIRING TECHNICAL DATA APPROVALS... -
Page 3: Introduction
4409 ENCLOSED ANALOG HEAT DETECTOR - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION 1. INTRODUCTION This document describes the enclosed analog heat detector, type number 4409. The document contains information about the product and instructions on how to mount and connect it. -
Page 4: General Description
3. GENERAL DESCRIPTION The enclosed analog heat detector measures the temperature through a thermistor. The temperature range is 0°C to 100°C in steps of 0.5°C. The detector is intended for outdoor use or in high humidity indoor premises. The detector must not be exposed to heavy sunlight or temperature lower than -20°C. -
Page 5: Set The Com Loop Address
4409 ENCLOSED ANALOG HEAT DETECTOR - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION 4. SET THE COM LOOP ADDRESS Each COM loop unit has to have a unique COM loop address (001-253). Set the address with the Address Setting Tool (4414). Use the connection cable with crocodile clips to connect the flying leads with the tool's SA &... -
Page 6: Mounting
6. MOUNTING The connection box must be mounted in the ceiling. Screws are not supplied. Cut out the required number of knockouts and apply the compression glands before mounting the connection box in the ceiling. Tighten the compression glands firmly. (Measure in mm) -
Page 7: Installation And Wiring
4409 ENCLOSED ANALOG HEAT DETECTOR - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION 7. INSTALLATION AND WIRING Insert the cables in the compression glands. If the outer cable diameter is < 6 mm, insert the enclosed rubber tube before installation of the cable. If the outer cable diameter is ≥... -
Page 8: Technical Data
8. TECHNICAL DATA All current consumptions are valid by nominal voltage and by 25 °C. Voltage: Allowed 12 – 30.0 V DC Normal 24V DC Current: Quiescent 0.185 mA Active (incl. internal LED) 1.650 mA Active (incl. external LED) ≤ 3.650 mA Address range 001-253 Address setting... -
Page 9: Approvals
4409 ENCLOSED ANALOG HEAT DETECTOR - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION 9. APPROVALS Applicable directive/ Approval Applicable standards Notified body EN54-5 No. 0786-CPR-21764 EN54-5 VdS 2344 No. G222045 VdS 2503 EN61000-6-3 (Emission) Self declaration EN50130-4 (Immunity) VdS (Certification) RoHS EN50581... - Page 10 DOCUMENT NAME: TECHNICAL DESCRIPTION 4409 DOCUMENT NUMBER: MEW02743 EN DATE OF ISSUE: 2022-07-15 REV: - DATE OF REVISION: - Panasonic Fire & Security Europe AB Jungmansgatan 12 SE-211 11 Malmö Sweden Tel: +46 (0)40 697 70 00 www.panasonic-fire-security.com...
