  • Page 1 Network Function Integrated Type Laser Displacement Sensor HL-G2 SERIES Specifications 2024.3...

  • Page 2: Order Guide

    (approx. 13.5 %) of the center light intensity. Due to leak light outside the defined range, the measurement values may be affected if the reflectance around the detecting point is higher than that of the detecting point. Panasonic Industry Co., Ltd.
  • Page 3 * Windows is a trademark or registered trademark of Microsoft Corporation in the United States and/or other countries. * Intel Core is a trademark or registered trademark of Intel Corporation and its subsidiaries in the United States and/or other countries. Panasonic Industry Co., Ltd.

  • Page 4: ExampleOfSystemConfiguration

    • When RS-485 wiring is used for the converter, be sure to check for proper operation using actual equipment before using. Analog output type HL-G2 Sensor Unit Analog Analog output input device Optional cable I/O control device Each I/O (for analog output type) (PLC, etc.) 6.562 ft, 5 m 16.404 ft Panasonic Industry Co., Ltd.

  • Page 5: Specifications

    * EtherNet/IP is a trademark or a registered trademark of Open DeviceNet Vendors Association (ODVA). * Modbus is a registered trademark of Schneider Electric USA Inc. * SLMP is a registered trademark of Mitsubishi Electric Corporation. Panasonic Industry Co., Ltd.
  • Page 6 500 m/s acceleration (50 G approx.) in X, Y and Z directions three times each Material Product casing: Aluminum die casting, Front cover: Glass, Cable: PVC Weight Net weight: 150 g approx., Gross weight: 200 g approx. Panasonic Industry Co., Ltd.
  • Page 7 0 V and SG terminals, an overcurrent may flow, causing a failure. Use an isolated RS-485 connected device. If using a non-insulated RS-485 connected device, match the reference potential on the power supply side. Panasonic Industry Co., Ltd.

  • Page 8: Analog Output Circuit

    (0 V) with that of the GND of the analog input device power supply. Note also that, if signals with a potential difference are incorrectly wired between the 0 V and the analog GND, an overcurrent may flow, causing a failure. Panasonic Industry Co., Ltd.
  • Page 9 Average count: 512 Average count: 512 -10° -10° -0.2 -0.2 -0.4 -0.4 3.937 6.890 9.843 12.795 15.748 3.937 6.890 9.843 12.795 15.748 (Measurement center distance) (Measurement center distance) Measuring distance L (mm in) Measuring distance L (mm in) Panasonic Industry Co., Ltd.

  • Page 10: Precautions For Proper Use

    0.008 0.079 0.002 0.110 0.008 HL-G208B-S-MK 0.09 HL-G208B-A-MK 0.079 0.012 0.118 0.004 0.157 0.008 HL-G212B-S-MK Measurement HL-G212B-A-MK 0.110 0.012 0.157 0.004 0.205 0.012 center distance 13.5 HL-G225B-S-MK 90 degrees HL-G225B-A-MK 0.098 0.028 0.315 0.012 0.531 0.020 Panasonic Industry Co., Ltd.
  • Page 11 HL-G225B-S-MK HL-G225B-A-MK 12.5 0.492 12.5 0.492 0.630 0.098 31.5 1.240 0.335 0.335 0.335 0.197 0.197 0.098 13.5 0.531 HL-G212B-S-MK HL-G212B-A-MK 12.5 0.492 0.748 0.295 0.197 19.5 0.768 0.236 0.236 19.5 19.5 0.394 92.5 3.642 0.768 0.768 Panasonic Industry Co., Ltd.

  • Page 12: Description Of Parts

    We recommend that the sensor be replaced. E200** E211** Overcurrent detection error Turn OFF the power and check the load. E212** (Analog output type only) E213** Note: Internal information is set in the last two digits (“**” section) of each error code. Panasonic Industry Co., Ltd.

  • Page 13: Sensor Installation

    (including the analog GND) to the connected device with insulated I/O. • When removing the connecting cable from the sensor, loosen the two M2.6 screws, hold the connector part of the cable, and pull out the cable. Panasonic Industry Co., Ltd.
  • Page 14 HL-G212B-A-MK HL-G225B-S-MK 9.843 6.5° HL-G225B-A-MK Laser radiation indicator (Green) Measurement 1.063 center distance (L) 2.244 15.5 0.610 ENTER key 0.150 49.4 1.945 Light emitting axis DOWN (UP) key UP (DOWN) key Light receiving axis Display section Panasonic Industry Co., Ltd.

  • Page 15: Installation Diagram

    CN-8A-C□ Optional Cable for Analog Output Type (Sold Separately) Installation diagram 0.189 M2.6 screw 13.6 0.535 13.6 0.535 0.787 0.709 ø5.7 ø0.224 cable • Length L Model No. Length L CN-8A-C2 2,000 78.740 CN-8A-C5 5,000 196.850 Panasonic Industry Co., Ltd.
  • Page 16 Panasonic Industry Co., Ltd. Industrial Device Business Division 7-1-1, Morofuku, Daito-shi, Osaka 574-0044, Japan industrial.panasonic.com/ac/e/ Specifications are subject to change without notice. ⓒ Panasonic Industry Co., Ltd. 2024.3 No. PCE-HLG2-SED...
