  • Page 1 For Gas Dual Display Digital Pressure Sensor DP-100 SERIES Ver.2 DP-100L SERIES IO-Link Compatible, Self-monitoring Type Pressure Sensors That Are More Advanced Than Ever IO-Link compatible, self-monitoring sensor lineup 2025.1...
  • Page 2 Ananalysisofsuchfielddatarequireshigh-levelknow-howandtime,causingaburdentopeopleresponsibleforthe production site management. The Self-Monitoring Sensor manufactured by Panasonic Industry is capable of reporting sensor data and its own state to the host device through the I/O Link master. With the Self-Monitoring Sensor, you can immediately judge the state of the sensor and easily identify the cause of failure.
  • Page 3 DP-100 Self-monitoring function With the Panasonic Industry’s Self-Monitoring Sensor, you can get high-level solutions! The introduction of IoT requires collection of the incident pressure value data and presents the following problems. Pressure value data Sensor Previously only ON/OFF data was Sensor required.
  • Page 4 30% compared to Normal operation ECO / FULL operation 720 mW 360 mW normal operation. pgrade Enhanced power circuitry Addition of a reverse polarity protection circuit to the transistor output circuit To prevent from breakage due to miswiring. Panasonic Industry Co., Ltd.
  • Page 5 The sensor status can therefore be understood easily, and operating errors can be reduced. OFF: Green (or Red) ON: Red (or Green) SET: Orange Main Display During normal operation During setting Panasonic Industry Co., Ltd.
  • Page 6 Human operating error is reduced. • Because all details are copied automatically, problems as a result of human error can be prevented. • Instruction manuals can be updated easily when changes are made to equipment design. Panasonic Industry Co., Ltd.
  • Page 7 Ideal for checking reference pressure Reset function –100 kPa –50 kPa 0 kPa 0 MPa 0.5 MPa 1 MPa If a problem ever occurs with the sensor settings, they can be reset to the default settings. Panasonic Industry Co., Ltd.
  • Page 8 Notes: 1) Hysteresis can be fixed to one of eight different levels. 2) “ ” or “ ” appears in the sub display for comparative output 1, and “ ” or “ ” appears for comparative output 2. Panasonic Industry Co., Ltd.
  • Page 9 “40”, the auto-reference input compensates for this every time by changing adjusts the reference pressure to “0” every time the reference pressure changes, so the threshold level, so any variation in the filling pressure can be ignored. any variation in the filling pressure can be ignored. Panasonic Industry Co., Ltd.
  • Page 10 10 steps. This prevents chattering and malfunction caused by a 1,000 ms (3 steps). Setting a longer time reduces display flickering. sudden pressure change or other factor. Momentary change due to pulsation Pressure Threshold value Prevention of malfunction Output Panasonic Industry Co., Ltd.
  • Page 11 Connection cable * * Options: 1 m 3.281 ft / 3 m 9.843 ft / 5 m 16.404 ft * Refer to p.16 for recommended commercially-available connectors. types are also available. Panasonic Industry Co., Ltd.
  • Page 12 By equipping the push-in converter with DP-10□-M(-P), pressure port can be converted from M5 female thread to Rc female thread. Bore diameter conversion to the DP2 / DP3 series (discontinued) is possible. M5 female thread female thread Conversion bushing MS-DP1-7 Panasonic Industry Co., Ltd.
  • Page 13 ― Setting copy mode 〇 〇 〇 〇 Reset setting *1: Communication output (C/Q) setting is linked with control output (DO). *2: Unit cannot be switched in products (DP-101Z□, DP-102Z□) for Japan. Panasonic Industry Co., Ltd. Panasonic Industry Co., Ltd.

  • Page 14: Order Guide

    Type without connector attached cable CN-14A-C2 is available. When ordering this type, suffix “-J” to the end of Model No. (Excluding M8 plug-in connector type and short pressure port type) (e.g.) Type without connector attached cable of DP-101-N is “DP-101-N-J” Accessory • CN-14A-C2 (Connector attached cable 2 m 6.562 Panasonic Industry Co., Ltd.
  • Page 15 DP-102ZL3-M-P-C pressure +1.000 MPa Note: Smartclick is a trademark or registered trademark of OMRON Corporation. Accessory • CN-14A-C2 (Connector attached cable 2 m 6.562 * M12 connector cable (0.3 m 0.984 ft) is not sold separately. Panasonic Industry Co., Ltd.
  • Page 16 Two M3 (length 8 mm 0.315 in) screws, two M4 (length 20 mm 0.787 in) screws are Smartclick is a trademark or registered attached. trademark of OMRON Corporation. * Contact the manufacturer for details of the recommended products. Panasonic Industry Co., Ltd.

  • Page 17: Specifications

    2) Model Nos. of Asia type having “-M” are short pressure port type. Model Nos. of Asia and North America types having the suffix “-P” are PNP output type. 3) Only standard type is equipped with comparative output 2. 4) Cannot be used at the same time. Panasonic Industry Co., Ltd.
  • Page 18 Notes:1)Wheremeasurementconditionshavenotbeenspecifiedprecisely,theconditionsusedwereanambienttemperatureof+20°C+68°F. 2) The power consumption does not include the output load current. 3) When the sensor is used as an ordinary sensor, the communication output (C/Q) provides the same output operation as the control output (DO). Panasonic Industry Co., Ltd.
  • Page 19 : Surge absorption zener diode : PNP output transistor , Tr : PNP output transistor : NPN input transistor Terminal arrangement diagram Terminal Designation Standard type: Comparative output 2 Multi-function type: Analog output or External input Comparative output 1 Panasonic Industry Co., Ltd.

  • Page 20: Wiring Diagrams

    Control output (DO) Control output (DO) Communication output (C/Q) (Note) Communication output (C/Q) (Note) Note: When the sensor is used as an ordinary sensor, the communication output (C/Q) provides the same output operation as the control output (DO). Panasonic Industry Co., Ltd.

  • Page 21: Precautions For Proper Use

    Connector attached cable MS-DP1-2 M4 (length 20 mm 0.787 screw (Accessory) Note: Take care that if the cable with connector is sticking out of the side groove of this product when mounting, the cable may disconnected. Panasonic Industry Co., Ltd.
  • Page 22 • Do not operate the keys with pointed or sharp objects. • The tightening torque should be 1 N·m or less when connecting a coupling to the pressure port of MS-DP1-FM. Pressure port Coupling (Purchase separately.) Panasonic Industry Co., Ltd.
  • Page 23 5th digit 6th digit 7th digit 8th digit Response time Unit switching Display refresh rate ECO mode 2.5 ms 250 ms 5 ms 500 ms Panasonic Industry Co., Ltd. kgf/cm 1,000 ms FULL 10 ms — — 25 ms...
  • Page 24 1.122 0.531 0.059 ø4.5 0.787 0.059 ø0.177 t 1.5 1.181 Material: Stainless steel (SUS304) 0.787 0.177 1.102 t 0.059 29.5 53.5 Two M3 (length 6 mm 0.236 in) screws with washers are attached. 1.161 2.106 1.181 Panasonic Industry Co., Ltd.
  • Page 25 −0.4 1.220 1.220 −0.016 −0.016 −0.4 1.220 −0.016 −0.4 1.220 2.165 −0.016 or more 1.220 n + 3.5 0.138 (n-1) 2.165 Note: The panel thickness should be 1 to 6 mm 0.039 to 0.236 or more Panasonic Industry Co., Ltd.
  • Page 26 Two M3 (length 8 mm 0.315 in) screws, two M4 (length 20 mm 0.787 in) screws 0.335 MS-DP1-FN has a two M4 (length 20 mm 0.787 in) screws are attached. female thread. are attached. Panasonic Industry Co., Ltd.
  • Page 27 1.969 CN-14A(-R)-C1 1,000 39.370 0.315 0.315 CN-14A(-R)-C2 2,000 78.740 CN-14A(-R)-C3 3,000 118.110 ø3.7 ø0.146 cable CN-14A(-R)-C5 5,000 196.850 DedicatedM12connectorcable(attachedtoDP-10□ZL3-M-P-C) 11.811 44.5 1.378 1.752 0.315 ø4 ø0.157 cable M12 connector Note: B esuretousethededicatedM12connectorcableattachedtotheproduct.Notethatthepinarrangementisdifferentfromthatforcommercially available M12 connector cables. Panasonic Industry Co., Ltd.
