- Page 1 Modern Series LCD Monitor Modern MD272UPSW (3PB1) User Guide...
-
Page 2: Table Of Contents
Contents Getting Started ........................3 Package Contents ..................... 3 Installing the Monitor Stand ..................4 Adjusting the Monitor ....................5 Monitor Overview ..................... 6 Remote Control Overview ..................8 Connecting the Monitor to PC .................. 9 OSD Setup ........................10 Navi Key ........................10 Hot Key ........................ -
Page 3: Getting Started
Getting Started This chapter provides you with the information on hardware setup procedures. While connecting devices, be careful in holding the devices and use a grounded wrist strap to avoid static electricity. Package Contents Monitor Modern MD272UPSW Documentation Quick Start Guide Stand Stand Base with Screw(s) Screw(s) for Wall Mount Bracket(s) -
Page 4: Installing The Monitor Stand
Installing the Monitor Stand 1. Leave the monitor in its protective packaging. Align and gently push the stand bracket towards the monitor groove until it locks in place. 2. Connect the base to the stand and tighten the screw to secure the base. 3. -
Page 5: Adjusting The Monitor
Adjusting the Monitor This monitor is designed to maximize your viewing comfort with its adjustment capabilities. Important ⚠ Avoid touching the display panel when adjusting the monitor. ● The reserved pivot 5° is designed for adjusting the level imbalance of some tables. ●... -
Page 6: Monitor Overview
Monitor Overview... - Page 7 Infrared Receiver Power LED Lit in white after the monitor is turned on. If no signal input, the LED will turn into orange. Lit in orange when the monitor is in Stand-by mode. Power Button & Navi Key Kensington Lock Cable Organizer 100 Mbps LAN Jack The standard RJ-45 LAN jack is provided for connection to the Local Area...
-
Page 8: Remote Control Overview
Remote Control Overview Power Turns the Monitor on or off. Mute To mute or un-mute the sound. Profile Switch Goes to the Google account page. Notification (Dashboard) Enter the Monitor settings. Google Assistant Turns on the bluetooth voice setting. Up/ Down/ Left/ Right/ OK Selects different items in the menu, adjusts the menu, and confirms the selection. -
Page 9: Connecting The Monitor To Pc
Connecting the Monitor to PC 1. Turn off your computer. 2. Connect the video cable from the monitor to your computer. 3. Connect the power cord to the monitor power jack. (Figure A) 4. Plug the power cord into the electrical outlet. (Figure B) 5. -
Page 10: Osd Setup
OSD Setup This chapter provides you with essential information on OSD Setup. Important ⚠ All information is subject to change without prior notice. Navi Key The monitor comes with a Navi Key, a multi-directional control that helps navigate the On-Screen Display (OSD) menu. Up/ Down/ Left/ Right: ●... -
Page 11: Google Tv Menus
Google TV Menus Channels & Inputs 1st Level Menu 2nd Level Menu External Inputs HDMI CEC Settings HDMI Signal Format Monitor 1st Level Menu 2nd Level Menu Quick Show MultiView MultiView Audio Focus Focus Auto Switch Settings On, go sleep when no signal On, go launcher when no signal Mouse/Keyboard wake up Multi-Platform Streamer... -
Page 12: Network & Internet
1st Level Menu 2nd Level Menu Screen Aspect Ratio Sound Sound Mode Surround Mode Sound Only Advanced Settings Audio output Output Device Audio Output Type Digital Audio Delay(ms) Digital Audio Volume eARC Network & Internet 1st Level Menu 2nd Level Menu Wi-Fi Available networks See all/fewer... -
Page 13: Privacy
Privacy 1st Level Menu 2nd Level Menu Device Settings Location Location status Scanning always available RECENT LOCATION REQUESTS Usage & diagnostics Account settings Google Assistant Personal settings Voice control View Permissions Personal results Searchable apps Shared settings SafeSearch filter Payment & Purchases Purchase authentication App settings Manage Updates... -
Page 14: Apps
Apps 1st Level Menu 2nd Level Menu Recently opened apps See all apps Show all apps Permissions Manage Updates Auto-update apps See available updates App permissions Phone Files and media Other permissions Special app access Energy optimization Usage access Notification access All files access Display over other apps Modify system settings... -
Page 15: Accessibility
1st Level Menu 2nd Level Menu Date & Time Automatic data&time Set date Set time Set time zone Use 24-hour format Language Google Definied Language Keyboard Current keyboard Gboard Settings Manage keyboards Storage Device storage Internal shared storage Free up storage Ambient Screensaver Google Defined Settings - Ambient Power &... -
Page 16: Remotes & Accessories
1st Level Menu 2nd Level Menu Captions Display Language Text size White on black Black on white Yellow on black Yellow on blue Custom High contrast text (Experimental) Remotes & Accessories 1st Level Menu 2nd Level Menu Bluetooth Pair accessory Full-screen BT pairing flow RCU Firmware Update RCU Firmware Update... -
Page 17: Specifications
Specifications Monitor Modern MD272UPSW Size 27 inch Curvature Flat Panel Type Resolution 3840x2160 (UHD) Aspect Ratio 16:9 Brightness 300 nits (typ.) Contrast Ratio 1000:1 Refresh Rate 60Hz ● 1 x 100 Mbps LAN Jack ● 1 x DisplayPort ● 1 x HDMI™ Connector ●... - Page 18 Monitor Modern MD272UPSW 6.30 kg Weight Gross 9.10 kg Operating ● Temperature: 0℃ to 40℃ ● Humidity: 20% to 90%, non-condensing ● Altitude: 0 ~ 5000m Environment ● Temperature: -20℃ to 60℃ Storage ● Humidity: 10% to 90%, non-condensing * Based on CIE1976 test standards. ** External Power Supply may vary by country.
-
Page 19: Preset Display Modes
Preset Display Modes Important ⚠ All information is subject to change without prior notice. Standard Default Mode Standard Resolution HDMI™ USB-C 640x480 @60Hz SVGA 800x600 @56Hz @60Hz 1024x768 @60Hz WXGA 1280x720 @60Hz WXGA+ 1440x900 @60Hz WSXGA+ 1680x1050 @60Hz 1920x1080 @60Hz 2560x1440 @60Hz 3840x2160... -
Page 20: Troubleshooting
Troubleshooting The power LED is off. ● Press the monitor power button again. ● Check if the monitor power cable is properly connected. No image. ● Check if the computer graphics card is properly installed. ● Check if the computer and monitor are connected to electrical outlets and are turned on. -
Page 21: Safety Instructions
● Place the power cord in a way that people are unlikely to step on it. Do not place anything on the power cord. ● If this device comes with an adapter, use only the MSI provided AC adapter approved for use with this device. - Page 22 ● If any of the following situations arises, get the device checked by service personnel: ● The power cord or plug is damaged. ● Liquid has penetrated into the device. ● The device has been exposed to moisture. ● The device does not work well or you can not get it working according to the User Guide.
-
Page 23: Tüv Rheinland Certification
TÜV Rheinland Certification TÜV Rheinland Low Blue Light Certification Blue light has been shown to cause eye fatigue and discomfort. MSI now offers monitors with TÜV Rheinland Low Blue Light certification to ensure users’ eye comfort and well-being. Please follow the instructions below to reduce the symptoms from extended exposure to the screen and blue light. -
Page 24: Regulatory Notices
1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. MSI Computer Corp. 901 Canada Court, City of Industry, CA 91748, USA (626) 913-0828 www.msi.com... -
Page 25: Weee Statement
Vietnam RoHS As from December 1, 2012, all products manufactured by MSI comply with Circular 30/2011/TT-BCT temporarily regulating the permitted limits for a number of hazardous substances in electronic and electric products. -
Page 26: Environmental Policy
Copyright and Trademarks Notice Copyright © Micro-Star Int’ l Co., Ltd. All rights reserved. The MSI logo used is a registered trademark of Micro-Star Int’ l Co., Ltd. All other marks and names mentioned may be trademarks of their respective owners. -
Page 27: Technical Support
If a problem arises with your product and no solution can be obtained from the user’ s manual, please contact your place of purchase or local distributor. Alternatively, please visit https://www.msi.com/support/ for further guidance. Restrictions for Products with Radio Functionality (select products only) CAUTION: IEEE 802.11x wireless LAN with 5.15~5.35 GHz frequency band is...
