Network Eyeball Cameras
M-24-V-T
Quick Guide
V1.00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Advidia M-24-V-T and is the answer not in the manual?

Questions and answers

Related Manuals for i-PRO Advidia M-24-V-T

Summary of Contents for i-PRO Advidia M-24-V-T

  • Page 1 Network Eyeball Cameras M-24-V-T Quick Guide V1.00...
  • Page 2 Waterproof Requirements Please waterproof cables in accordance with the following instructions. User shall assume all responsibility for device damage caused by water due to improper waterproof measures. NOTE! ⚫ Before you start, connect all the needed cables and cut off the copper wires for the cables that you don't use.
  • Page 3 Tighten Tighten Tighten Waterproof tape Wrap the unused cables together into a bundle 3. Install the supplied waterproof components to the network cable in sequence. CAUTION! You need to mount the rubber ring onto the network cable interface first. 4. If your camera has a DC cable and you will not use it, insert the plug into the interface.

  • Page 4: Packing List

    Packing List Contact your local dealer if the package is damaged or incomplete. The attachments may vary with models, please see the actual model for details. Name Unit Camera Waterproof components Screw components Mount accessory User manual Remarks: * means optional and supplied with certain models only. (1)Including one or more waterproof components such as tape and plug.

  • Page 5: Maintenance

    ⚫ Do not overbend the cables during the installation, otherwise, poor cable contact may cause malfunction. ⚫ When connecting to an external interface, use an existing connection terminal, and ensure that the cable terminal (latch or clamp) is in good condition and properly fastened.

  • Page 6: Cable Connection

    Cable Connection The appearance and tail cable may vary with device model. NOTE! Use a pin to press and hold the Reset button for about 15 seconds to restore factory default settings. Perform this operation within 10 minutes after the device is powered on or the reset will fail otherwise.
  • Page 7 Insert the plastic anchors. Drill a hole to lead cables out of the ceiling. Knock in plugs. Loosen the fixing screw, then remove the housing. Loosen the fixing screw, then turn the housing to the position shown in figure  to remove it. Connect the cable and then secure the bottom ring.
  • Page 8 Connect cable and protect it with waterproof tape (Optional) insert a micro SD card Attach bottom ring to ceiling with taping screws Mount the housing. Adjust the housing to the position shown in figure above.Align the screw hole on the housing with the tail cable outlet on the base, attach the housing gently and then rotate clock/counterclockwise at least 8 degrees to lock.To ensure proper image display and illumination effects, make sure the mark (see figure above) is aligned...

  • Page 9: Access Your Camera

    NOTE! ⚫ Do not adjust monitoring direction by force with the screw fully tightened. Loosen the screw first. ⚫ For open installation, lead the tail cable out of the open slot on the base plate first and then fasten the screw. Startup After you have installed the device, connect one end of the power adapter (purchased separately) to power supply, and then connect the other end to the...
  • Page 10 NOTE! ⚫ DHCP is enabled by default. If a DHCP server is used in your network, your camera may be assigned an IP address, and you need to use the assigned IP address to log in. ⚫ You may need to install a plug-in at your first login. Please follow the on-screen instructions to complete the installation and then open the browser again to log in.

  • Page 11: Copyright Statement

    Disclaimer and Safety Warnings Copyright Statement No part of this manual may be copied, reproduced, translated or distributed in any form by any means without prior content in writing from our company (referred to as us hereafter). The product described in this manual may contain proprietary software owned by our company and its possible licensors.

  • Page 12: Network Security

    and recommendations in this manual are presented without warranty of any kind, expressed or implied, including, but not limited to, merchantability, satisfaction with quality, fitness for a particular purpose, and noninfringement. ⚫ Users must assume total responsibility and all risks for connecting the product to the Internet, including, but not limited to, network attack, hacking, and virus.

  • Page 13: Safety Warnings

    ⚫ Choose username and password discretely: Avoid using the username and password of your social media, bank, email account, etc, as the username and password of your device, in case your social media, bank and email account information is leaked. ⚫...
  • Page 14 ⚫ Use a UL certified power supply that meets LPS requirements if an adapter is used. ⚫ Use the recommended cordset (power cord) in accordance with the specified ratings. ⚫ Only use the power adapter supplied with your device. ⚫ Use a mains socket outlet with a protective earthing (grounding) connection. ⚫...
  • Page 15 © i-PRO Co., Ltd. All Rights Reserved. i-PRO, Viewnetcam.com, advidia, VideoInsight, CloUDE, and Unified Digital Evidence are registered trademarks or trademarks of i-PRO Co., Ltd. or i-PRO Americas Inc. in various jurisdictions. All other trademarks are the property of their respective owners.
