Installation Guide
Included Installation Instructions
Network Camera
WV-S61300-ZY
Model No.
WV-U61300-ZY
WV-U61300-ZYPR
About the user manuals
Product documentation is composed of the following documents.
• Installation Guide (this document): Provides information about "Precautions",
"Precautions for installation" and the installation method.
• Basic Information (Refer to the link on the following product information
website): Provides information about "Precautions for use", "Parts and functions"
and "Detail specifications".
• Operating Instructions (Refer to the link on the following product information
website): Explains how to perform the settings and how to operate this camera.
https://i-pro.com/products_and_solutions/en/surveillance/documentation-database
"<Control No.: C****>" used in these documents should be used to search for
information on our technical information website (https://i-pro.com/products_and_
solutions/en/surveillance/learning-and-support/knowledge-base/technical-information)
and will guide you to the right information.
• Before attempting to connect or operate this product, please read these instructions
carefully and save this manual for future use.
• microSDXC/ microSDHC/ microSD memory card is described as microSD memory card.
• The external appearance and other parts shown in this manual may differ from the actual product within
the scope that will not interfere with normal use due to improvement of the product.
• The WV-U61300-ZYPR model does not comply with CE or UKCA.
Tokyo, Japan
https://www.i-pro.com/
© i-PRO Co., Ltd. 2025
For professional use only
Authorised Representative in EU:
i-PRO EMEA B.V.
Laarderhoogtweg 25, 1101 EB
Amsterdam, Netherlands
i-PRO EMEA B.V. UK Branch
1010 Cambourne Business Park,
Cambridgeshire CB23 6DP
1
Indoor use
WV-S61300-ZY
C0525-0
PGQP3793ZA
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for i-PRO WV-S61300-ZY
Summary of Contents for i-PRO WV-S61300-ZY
- Page 1 Explains how to perform the settings and how to operate this camera. https://i-pro.com/products_and_solutions/en/surveillance/documentation-database “<Control No.: C****>” used in these documents should be used to search for information on our technical information website (https://i-pro.com/products_and_ solutions/en/surveillance/learning-and-support/knowledge-base/technical-information) and will guide you to the right information.
- Page 2 Supplier’s Declaration of conformity environment. This equipment generates, uses, Trade name : i-PRO and can radiate radio frequency energy and, Model No. : WV-S61300-ZY/ WV-U61300-ZY if not installed and used in accordance with Responsible Party : the instruction manual, may cause harmful i-PRO Americas Inc.
-
Page 3: About Notations
About notations Some functions are expressed with the following notations in this document. C Clear dome cover Smoke dome cover WARNING: • Operation of this product in a residential environment could cause radio interference. Caution: Notice: • This product is not suitable for use in locations •... - Page 4 ■ Do not install or clean the camera, or touch this product, the power cable or the connected cables during thunder storms. Failure to observe this may cause electric shock. ■ Refer installation work to the dealer. Installation work requires technique and experience. Failure to observe this may cause fire, electric shock, injury, or damage to the product.
-
Page 5: Open Source Software
• All other trademarks identified herein are the property of their respective owners. Precautions for installation i-PRO Co., Ltd. assumes no responsibility for injuries or property damage resulting from failures arising out of improper installation or operation inconsistent with this documentation. - Page 6 • Locations near coasts directly subjected to sea breezes, or locations subject to corrosive gases such as from hot springs, volcanic regions, etc. • Locations where the temperature is not within the specified range • Locations subject to vibrations, such as on vehicles, marine vessels, or above product lines (This product is not designed for on-vehicle use.) •...
-
Page 7: Specifications
Approx. 800 g {1.77 lbs} Mass: Finish: Main body: Aluminum die cast/ ABS resin, i-PRO white Dome cover: Acrylic resin (Transmittance: 30 %) <WV-S61300-ZYG> <WV-U61300-ZYG> *1 Refer to our technical information website <Control No.: C0106> for further information about Power source and Power consumption information. -
Page 8: Optional Accessories
Optional accessories The latest information → technical information website “Accessory Selector” <Control No.: C0501> Troubleshooting Before requesting service, refer to “Troubleshooting” of “Basic Information” and “Operating Instructions”. Then, confirm the trouble. -
Page 9: Standard Accessories
Standard accessories IMPORTANT SAFETY INSTRUCTIONS ..1 pc. Attachment plate ×1 Template ×1 Power cord plug ×1 Cable for easy kitting ×1 *1 The cable for easy kitting and the power cord plug are attached to the camera. Do not use the cable for easy kitting after kitting work. -
Page 10: Back Side
Parts and functions Lock plate Attachment plate (accessory) Cable cover Enclosure Rear cover Camera part Dome cover <WV-U61300-ZYPR> <WV-S61300-ZY> <WV-U61300-ZY> Power supply terminal EXT I/O terminal (12 V DC) Audio input terminal Audio output terminal RJ45 network terminal Back side... -
Page 11: Front Side
LINK indicator (orange) ① SD MOUNT ACT indicator indicator (green) ② A click sound is heard. • All LEDs turn off Operating Instructions “Indicator” • Operating Instructions “Format” • Use a microSD memory card dedicated to i-PRO cameras. - Page 12 Step 1 Preparations ■ When using the side cable Cable cover access hole Cable for easy kitting Do not use for actual installation.
- Page 13 Step 2 46 mm {1-13/16 inches} ø25.4 mm {1 inch} 83.5 mm FRONT {3-9/32 inches} Ceiling Minimum pull-out strength: 196 N {44 lbf} (per 1 pc.) M4 (4 pcs.) (locally procured)
- Page 14 Step 3 RJ45 Ethernet cable 12 V DC EXT I/O 1 2 3 4 Audio out <10 m {32.8 feet} Audio in <1 m {3.28 feet} (Mic) <10 m {32.8 feet} (Line) Basic Information “ Cables” Operating Instructions “Audio output terminal” ...
-
Page 15: Installation
Step 4 Installation Lock plate... - Page 16 Step 4 Removal ① ② ②...
- Page 17 If there is a protection film on the dome cover, remove it. Ceiling Technical information website “IP Setting Software” <Control No.: C0123> “i-PRO Configuration Tool (iCT)” <Control No.: C0133> “Extra optical zoom” <Control No.: C0124> “Camera images that appear to overlap”...
