the canister lid. The filters can be washed
in warm water then left to air-dry
naturally. IMPORTANT: Ensure the filters
are totally dry before re-fitting. Do not use
detergents.
Central filter
H
4 Lift the central canister filter  out of the
canister.
5 Remove any attached dirt by using the
brush.
6 Re-assemble by replacing the central
canister filter into the canister.
7 Replace the foam filter then the pleated
circular filter into the top of the canister.
Replacing the canister lid
8 Replace the canister lid by lining up the
arrows on the canister base and lid and
twisting clockwise to lock into place I.
The canister may be washed in water
6
12/05/2003 18:11
only but must be totally dry before re-fitting.
prevents it from being fitted back into place
if the filters have not been fitted correctly.
Motor protection filter
underneath the dust canister
1 Remove the dust canister.
2 Lift out the filter and shake rigorously
(no detergents) but must be totally dry before
re-fitting.
3 Replace the filter
Exhaust filter
I
dust canister compartment.
1 Remove the front cover.
2 Remove the exhaust filter by pulling
H
3 Take the filter out of the cage and shake
4 Replace the filter and the front cover.

Changing the belt


likely that the drive belt has snapped (usually
because the brush has been stalled). A spare
belt is supplied. Replacement belts can also
be obtained from Morphy Richards or a
Service Agent.
I
Page 6
The canister has a safety inter-lock that
The motor protection filter is located
over a dustbin.
The filter may also be washed in water
J
The exhaust filter is located below the
forward at the top and lift it away.
vigorously over a dustbin. The filter may
also be washed in warm water. Do not
use detergents. The filter must by
completely dry before re-fitting. Allow
filters to air-dry naturally.
