Thor Kitchen GORDON RAMSAY GR Series Installation Instructions Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
R S E 3 0 | R S E 3 0 B | R S G 3 0 / L P | R S G 3 0 B / L P
R S E 3 6 | R S E 3 6 B | R S G 3 6 / L P | R S G 3 6 B / L P

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GORDON RAMSAY GR Series and is the answer not in the manual?

Questions and answers

Related Manuals for Thor Kitchen GORDON RAMSAY GR Series

Summary of Contents for Thor Kitchen GORDON RAMSAY GR Series

  • Page 1 R S E 3 0 | R S E 3 0 B | R S G 3 0 / L P | R S G 3 0 B / L P R S E 3 6 | R S E 3 6 B | R S G 3 6 / L P | R S G 3 6 B / L P...
  • Page 2 INSTALLATION INSTRUCTIONS GORDON RAMSAY COLLECTION BY THOR KITCHEN RSG MODELS GAS/LP RANGE RSG30/LP RSG36/LP RSG30B/LP RSG36B/LP RSE MODELS ELECTRIC RANGE RSE30 RSE36 RSE30B RSE36B...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS IMPORTANT INSTRUCTION                                                        Critical safety information                                                        Signal words explanation...

  • Page 4: Important Instruction

    IMPORTANT INSTRUCTION 1.1 Critical safety information WARNING: If the information in these instructions is not followed exactly, a fire or explosion can result causing property damage, personal injury, or death. - Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.

  • Page 5: Intended Use

    IMPORTANT INSTRUCTION WARNING • A child or adult can tip the appliance and be killed • Install the anti-tip device to the wall/floor (see chapter 3.10 Install anti-tip device) Verify the anti-tip device has been properly installed and engaged with the back of the appliance •...

  • Page 6: 14 Important Instruction

    IMPORTANT INSTRUCTION 1.4 IMPORTANT INSTRUCTION For all models This installation instructions is part of this appliance, and contains important information on setup and use Read this manual carefully, especially the IMPORTANT INSTRUCTION chapter, before using the appliance Failure to do so may result in personal injury and/or damage to the appliance •...
  • Page 7 IMPORTANT INSTRUCTION • Never Leave Surface Units Unattended at High Heat Settings - Boilover can cause smoke and greasy spillovers that may ignite • Protective Liners - Do not use aluminum foil to line the surface of cooktop drip pan or oven bottoms Improper installation of these liners may result in a risk of electric shock, fire or damage to the porcelain surface •...
  • Page 8 IMPORTANT INSTRUCTION WARNING This appliance contains chemicals known to the State of California to cause cancer and/or reproductive harm, and birth defects or other reproductive harm For more information go to wwwP65Warningscagov For gas appliances only (RSG30/LP, RSG36/LP, RSG30B/LP, RSG36B/LP) •...

  • Page 9: Delivery

    IMPORTANT INSTRUCTION • Clean Cook-Top With Caution Do Not clean cooktop when it's hot Do Not clean cooktop when it's hot - If a wet sponge or cloth is used to wipe spills on a hot cooking area, be careful to avoid steam burn Some cleaners can produce noxious fumes if applied to a hot surface DELIVERY 2.1 Unpack...

  • Page 10: 2.2 Appliance Description

    DELIVERY 2.2 Appliance description Door parts Door handle x 1 Hex key x 1 Door side bracket x 2 Anti-tip kit For model RSG30/LP and RSG30B/LP Anti-tip device x 1 Anti-tip device screw x 4 For model RSE30, RSE30B, RSE36, RSE36B , RSG36/LP and RSG36B/LP Anti-tip device x 1 Anti-tip device screw x 2 Spacer kit...
  • Page 11 DELIVERY Baking accessories 8a Oven rack x 1 Broiler pan x 1 8b Telescopic oven rack x 1 Air fry basket x 1 Grid x 1 Probe x 1 Not included for RSG30/LP and RSG30B/LP...
  • Page 12 DELIVERY RSG30/LP and RSG30B/LP overview 22 23...
  • Page 13 DELIVERY 13 Burner cap x 2 Control panel 14 Burner head x 2 Knob bezel x 4 15 Burner base Cooktop 16 Dual burner cap with flame spreader x 2 Viewing window 17 Dual burner simmer ring x 2 Oven door 18 Dual burner lower flame spreader x 2 Oven bottom cover 19 Dual burner base...
  • Page 14 DELIVERY RSG36/LP and RSG36B/LP overview 22 23...
  • Page 15 DELIVERY 13 Burner cap x 4 Knob bezel x 6 14 Burner head x 4 Cooktop 15 Burner base Viewing window 16 Dual burner cap with flame spreader x 2 Oven door 17 Dual burner simmer ring x 2 Oven bottom cover 18 Dual burner lower flame spreader x 2 Dual burner knob x 2 19 Dual burner base...
  • Page 16 DELIVERY RSE30 and RSE30B overview...
  • Page 17 DELIVERY 20 Oven cavity Exhaust vent 21 Light Foot x 4 22 Oven door lock Spacer holes 23 Oven door sensor Probe port 25 Rack positions Warning zone 27 Convection fan Single cooking zone 29 Control panel Dual cooking zone 30 Knob bezel x 4 Broil element 31 Cooktop...
  • Page 18 DELIVERY RSE36 and RSE36B overview...

  • Page 19: Installation

    DELIVERY 20 Oven cavity Exhaust vent 21 Light Foot x 4 22 Oven door lock Spacer holes 23 Oven door sensor Probe port 25 Rack positions Warning zone 27 Convection fan Single cooking zone 29 Control panel Dual cooking zone 30 Knob bezel x 6 Broil element 31 Cooktop...
  • Page 20 DELIVERY • To eliminate the risk of burns or fire by reaching over heated surface units, cabinet storage space located above the surface units should be avoided If cabinet storage is to be provided, the risk can be reduced by installing a appliance hood that projects horizontally a minimum of 5" (127 mm) beyond the bottom of the cabinets Dimensions Fig.
  • Page 21 INSTALLATION Clearances Clearances for cooktops (31) with a cabinet on top Fig. 2 B1/B2 Side view Front view Electrical RSG30/LP, RSG30B/LP RSG36/LP, RSG36B/LP RSE30, RSE30B RSE36, RSE36B 36" (914 cm) min 30" (762 cm) min 24" (609 cm) 30" (762 cm) 36"...
  • Page 22 INSTALLATION Legend Countertop height B1 Minimum clearance above cooktop (31) for unprotected cabinet bottom Minimum clearance above cooktop (31) for protected cabinet bottom: Cabinet bottom has to be protected with no less than 64 mm thick flame retardant millboard covered with no less than No 28 MSG sheet metal, 04 mm thick stainless steel, 06 mm thick aluminum or 05 mm thick copper Width of cabinet above cooktop (31) Clearance between cabinets and countertops...
  • Page 23 INSTALLATION RSG30/LP, RSG30B/LP RSG36/LP, RSG36B/LP RSE30, RSE30B RSE36, RSE36B 36" (914 cm) min 30" (762 cm) 30" (762 cm) 36" (914 cm) 30" (762 cm) 36" (914 cm) 18" (457 cm) 5" (127 cm) 20" (508 cm) 26" (66 cm) 20"...
  • Page 24 INSTALLATION Clearances for cooktops (31) with an over-the-range microwave Fig. 4 Front view Electrical RSG30/LP, RSG30B/LP, RSE30B and RSE30 36" (914 cm) min 30" (762 cm) 30" (762 cm) 18" (457 cm) 5" (127 cm) 20" (508 cm) 2" (51 cm) 9"...

  • Page 25: 33 Install The Handle

    INSTALLATION Legend A Countertop height B Width of over-the-range microwave C From cooktop (31) to top of over-the-range microwave D Clearance between cabinets and countertops F Clearance of the electrical component area from the side of the cabinet G Width of the electrical component area H Height of the gas connection area Width of the gas connection area J Clearance of the gas connection area from the side of the cabinet...

  • Page 26: 34 Attach/Detach The Oven Door

    Fig. 7 3.4 Attach/detach the oven door NOTICE The oven door (33) has multiple colors available (sold separately) Visit Thor kitchen website for further details • The oven door (33) may be too big or heavy It is recommended to have 2 people work together for attaching/detaching the oven door •...
  • Page 27 INSTALLATION 4 Close the oven door (33) until it is approximately at a 20° angle (Fig 9) When the oven door (33) is at the correct angle position, the hinges arms release from the appliance Fig. 9 20° 5 Take out the oven door (33) by lifting it upwards and outwards Attach 1 Firmly grasp both sides on the oven door (33) 2 With the door at the same 20°...

  • Page 28: 35 Attach/Detach The Kickplate

    6 Close the oven door (33) 3.5 Attach/detach the kickplate NOTICE The kickplate (37) has multiple colors available (sold separately) Visit Thor kitchen website for further details Detach 1 Tilt the kickplate (37) backwards to release it from the magnets (Fig 12) 2 Lift the kickplate (37) upwards to unhook it from the sides (Fig 12) Fig.

  • Page 29: 36 Install The Burner Knobs

    INSTALLATION Attach 1 At a tilted angle, hook the kickplate (37) to the slits on both sides of the appliance (Fig 13) 2 Rotate the kickplate (37) upwards, the magnets snap it into place (Fig 13) Fig. 13 3.6 Install the burner knobs There are markings located on the control panel (29) to show which knob bezel (30) corresponds to which burner base (15/19)/burner ring (46/47) on the cooktop (31) 1 Match the knobs (35/36) into its corresponding knob bezels (30) (Fig 14/15)...
  • Page 30 INSTALLATION Electrical models (RSE30, RSE36, RSE30B and RSE36B only) Fig. 15 2 Push the knobs (35/36) in fully Make sure there is no friction between the knobs (35/36) and the bezel around them 3.7 Installation for gas models (RSG30/LP, RSG36/LP, RSG30B/LP and RSG36B/LP only) NG to LP gas conversion (RSG30/LP, RSG36/LP, RSG30B/LP and RSG36B/LP only) The appliance is configured for use with NG gas as default To convert the NG gas configuration to LP gas...
  • Page 31 INSTALLATION For RSG30/LP and RSG30B/LP: Fig. 16 Rear Left Right Front NG configuration LP configuration Orifice size Orifice size Burner location Burner location (mm) (mm) Rear left 12000 150 Left rear 12000 107 Rear right 12000 150 Right rear 12000 107 Front left 15000...
  • Page 32 INSTALLATION For RSG36/LP and RSG36B/LP: Fig. 17 Rear Left Right Front Middle NG configuration LP configuration Orifice size Orifice size Burner location Burner location (mm) (mm) Rear left 12000 Rear left 12000 Rear middle 6000 106 Rear middle 6000 Rear right 12000 Rear right 12000...
  • Page 33 INSTALLATION Connect to a gas supply (RSG30/LP, RSG36/LP, RSG30B/LP and RSG36B/LP only) • A manual shut-off valve has to be installed in an accessible location in the gas piping external to the appliance for the purpose of turning on or shutting off the gas supply to the appliance •...

  • Page 34: 38 Electrical Connection For Gas Range (Rsg30/Lp, Rsg36/Lp, Rsg30B/Lp And Rsg36B/Lp Only)

    INSTALLATION 6 After making all necessary connections, conduct a leak test of the appliance according to the manufacturer's instructions (see the following chapter) Gas leak test (RSG30/LP, RSG36/LP, RSG30B/LP and RSG36B/LP only) • Leak testing of the appliance shall be conducted in accordance with these instructions 1 Ensure that all appliance burner knobs (35/36) are in the off position, and then turn on the main gas supply valve 2 Use a liquid gas leak detector to check all gas connection joints and fittings for leaks in the system...

  • Page 35: 39 Electrical Connection For Electric Range (Rse30, Rse36, Rse30B And Rse36B Only)

    INSTALLATION 3.9 Electrical connection for electric range (RSE30, RSE36, RSE30B and RSE36B only) • This appliance must be supplied with the proper voltage and frequency, and connected to an individual properly grounded branch circuit, protected by a circuit breaker or fuse having amperage as specified on the rating label The rating label is located on the right of the oven door (33) •...
  • Page 36 INSTALLATION 3 Remove the 4 lower terminal screws from the terminal block (50) (Fig 19) Fig. 19 4 Remove the 2 upper screws of the neutral (N) terminal and take out the grounding strip (Fig 19) 5 Re-tighten the 2 upper screws of the neutral (N) terminal (Fig 19) Fig.
  • Page 37 INSTALLATION 9 Ensure the ring terminals have good contact with the terminals on the terminal block (50) 10 Slightly push the power cord upwards to leave some slack above the strain relief (51), then tighten the screws on the strain relief (51) 11 Reinstall the terminal block cover (52) and re-tighten the screws 3-wire connection 1 Loosen the screws on the terminal block cover (52) and set the screws aside for later use...

  • Page 38: 10 Install The Back Spacers

    INSTALLATION 6 Hook the ring terminals of the power cord wire into their designated terminals on the terminal block (50) (live 1/2 and neutral) and tighten the screws securely (Fig 24) Fig. 24 7 Ensure the ring terminals have good contact with the terminals on the terminal block (50) 8 Slightly push the power cord upwards to leave some slack above the strain relief (51), then tighten the screws on the strain relief (51) 9 Reinstall the terminal block cover (52) and re-tighten the screws...

  • Page 39: 11 Move And Level The Appliance

    INSTALLATION 3.11 Move and level the appliance • It is recommended to use a furniture dolly when moving the appliance to prevent damaging the floor • If the appliance is too heavy, it is possible to remove the oven door (33) before moving the appliance •...
  • Page 40 INSTALLATION Equipment required • • Power drill Spirit level • • Pencil Measuring tape For RSG30/LP and RSG30B/LP 1 Place the anti-tip device (4) on the floor, on the right side of the installation area 2 Test the fit of the anti-tip device (4) by pushing the appliance into place Ensure that the anti-tip device (4) catches onto the back right foot (39) of the appliance 3 Once the correct placement is verified, pull out the appliance and mark the holes on the anti-tip device (4) onto the floor (Fig 27)...
  • Page 41 INSTALLATION For RSG36/LP, RSE30 , RSE36, RSG36B/LP, RSE30B and RSE36B 1 Measure the height between the floor and the left side of the back panel (Fig 29) 2 Mark this measurement on the back wall (Fig 29) Fig. 29 3 Place the anti-tip device (4) against the wall and mark the holes on it, ensuring they are level (Fig 30) 4 Drill holes on the marked places (Fig 30) Fig.

  • Page 42: 13 Place The Bottom Cover (Rsg30/Lp, Rsg36/Lp, Rsg30B/Lp And Rsg36B/Lp Only)

    INSTALLATION Check the installation of the anti-tip device 1 Remove any items on the cooktop (31) 2 Grasp the top rear edge of the appliance and carefully attempt to tilt it forward 3 Verify that the anti-tip device (4) is engaged 3.13 Place the bottom cover (RSG30/LP, RSG36/LP, RSG30B/LP and RSG36B/LP only)

  • Page 43: 14 Assemble The Burners

    INSTALLATION 3.14 Assemble the burners • The burner parts (13, 14, 16, 17, 18) come pre-assembled and taped to the cooktop (31) • If adhesive residue remains, use a soft cloth and dishwashing liquid to remove it Avoid harsh or abrasive cleaners •...

  • Page 44: 15 Perform A Test Run

    INSTALLATION 3.15 Perform a test run Check burner ignition (RSG30/LP, RSG36/LP, RSG30B/LP and RSG36B/LP only) 1 Select a burner knob (35/36) and simultaneously push in and turn to the Ignite position A clicking sound indicates proper ignition operation 2 The burner should ignite within 4 seconds once the air is purged from the supply lines After ignition, rotate the burner knob (35/36) out of the Ignite position 3 Visually check the combustion quality of the flames: Flame appearance...

  • Page 45: Troubleshooting

    TROUBLESHOOTING Problem Possible cause Solution The appliance is not The appliance has been installed Place the oven rack (8) in the center of the level improperly oven Place a level on the oven rack (8) Adjust the feet (39) until the oven rack (8) is level Ensure the floor is level and strong and stable enough to adequately support the appliance...
  • Page 46 WELCOME TO THE GORDON RAMSAY COLLECTION THOR Kitchen x Gordon Ramsay Collection is backed by a solid two-year warranty on both parts and labor. It’s our commitment to quality and your peace of mind. Registering your appliance ensures top-notch service and personalized support.
