Schwinn 190 Troubleshooting Manual

3/11/24, 3:06 PM
Schwinn 190 & 290 Bikes: Why is there no power to my machine or
console?
Follow this troubleshooting guide to help resolve issues involving power to the Schwinn 190 and 290 bikes or its console.
Some common complaints may include:
Console doesn't turn on
Console doesn't light up
Bike won't turn on
Bike doesn't power up
Follow these steps to troubleshoot the issue
Tools you may need:
Phillips head screwdriver
Flat head screwdriver
6mm hex/Allen wrench, or the wrench from the hardware
card included with your machine
Pedal wrench, or 15mm open-ended wrench
10mm open-ended wrench
Voltmeter
1.
If your console turns on but goes to sleep during a workout, please visit
speed reading properly?
2.
Unplug the power adapter from both ends. Inspect the entire length of the cord, checking for any visible wires or cuts,
breaks, or crimps in the cord. Check the tip/plug end of the adapter and ensure it is not detached from the cord. If
damage is present,
3.
Test to ensure the outlet is working. Plug another device into the desired outlet, such as a lamp, and turn it on. If the
outlet is not working, try again with another outlet [14521.B].
4.
Test power to your machine using a voltmeter following these instructions:
have a voltmeter, proceed to the next step.
5.
If the issue persists, unplug your machine from power. Remove the console pivot cover to inspect the mast cable
upper connector (reference 1). Unplug the connection and check for damage such as bent pins, crimps, or cuts. If
undamaged, firmly plug the cable back in and test if the issue persists [14521.C]. If damaged,
Cables [14521.D].
Please note that the wire colors going into each side of the connector will not match, and there is an extra red
and black wire from the mast cable that is not used on the console connector.
about:blank
Schwinn 190 & 290 Bikes:  Why is there no power to my machine or console?
to troubleshoot further.
order a Power Adapter [14521.A].
Schwinn 190 & 290 Bikes: Why isn't my
Reference 1
.
Bike Voltmeter Testing
order Main Mast
ID: 14521.4
If you do not
