Ultra-safe US-1075CA User Instruction Manual

REMOVABLE CONCRETE ANCHOR
MODEL: US-1075CA
DESCRIPTION:
• Stainless Steel
• Hole Diameter : 3/4"
• Min. Breaking load : 5000 lbs / 23 kN
• Meets : ANSI Z359.18-2017
• Net weight : 10.3 oz. / 291 g
WARNING
This product is part of a personal fall arrest, restraint,
work positioning, personnel riding, or rescue system.
The user must follow the manufacturer's instructions for
each component of the system. These instructions must
be provided to the user of this equipment. Serious injury
during fall arrest can be prevented by using compliant
fall protection and emergency rescue systems. Users
must understand the manufacturer's instructions and
be trained in the proper use of this product per OSHA 29
CFR 1910.66 and 1926.503 or applicable local standards.
Manufacturer's instructions must be followed for proper
installation, use, care, and maintenance of this product.
These instructions must always be available for reference.
Alterations or misuse of this product or failure to follow
instructions may result in serious injury or death.
IMPORTANT
This manual is intended to meet the manufacturer's
instructions as required by the American National
Standard Institute Z359.18. This manual must always be
available to the user and is only permitted to be removed
by the user of this equipment. For proper use refer to
supervisor, user instructions, or contact the manufacturer.
Do not alter or intentionally misuse this equipment.
1.0 WARNINGS REGARDING THE
REMOVABLE CONCRETE ANCHOR:
• To safely use this equipment, the user must have a
sound mind and body. The user should also consult
a physician to ensure they are clear of any medical
conditions that may influence their ability to safely
use this equipment in normal and emergency
situations.
• Users must be trained in accordance with OSHA 29
CFR 1910.66 requirements regarding the safe use
of the system and its components before using a
personal fall arrest system.
• Use only with ANSI/OSHA compliant personal fall
arrest or restraint systems. The anchorage must
USER INSTRUCTION MANUAL
have the strength capable of supporting a static
load, applied in the directions permitted by the
system, of at least 5,000 lbf (22kN) in the absence
of certification.
• Users must be equipped with the means to limit the
maximum dynamic forces exerted on them during
fall arrest to a maximum of 1,800 lbf (8kN).
• Before use, a competent engineer or other qualified
person must verify that this anchorage connector
is compatible with the structural and operational
characteristics of both the installation location and
the system that it will be connected to.
• Before use, the anchorage connector must be
inspected for a variety of factors, including wear,
damage, and other deterioration. Components that
do not pass this inspection must be immediately
removed from service in accordance with the
requirements of OSHA 29 CFR 1910.66 and 1926.502.
• Immediately after a fall, the anchorage connector
must be removed from service and destroyed.
• Before use, the complete fall protection system
(including all components, calculating fall
clearance, and swing fall) should be planned.
Ensure the anchorage connector is positioned to
minimize the potential for falls and the potential
distance during use.
• Users must have a rescue plan, and the means
on hand to implement it, that either: ensures the
prompt rescue of users in the event of a fall or
assures that users are able to rescue themselves.
2.0 WARNINGS REGARDING
WORKING AT HEIGHT:
• Before use, consult your doctor to ensure that your
physical condition allows you to safely withstand
the impact of all forces involved with working at
height.
• Do not use any fall protection equipment that has
failed inspection.
1
1-877-711-1155
Phoenix, AZ USA
61
(2.38)
37
(1.44)
111
(4.35)
117
(4.59)
ø21
(0.84)
mm (inch)
