Ultra-safe US-5082AC User Instruction Manual

1.877.711.1155
PHOENIX, AZ USA
DESCRIPTION:
• Forged steel, heat treated
• Meets : ANSI Z359.18-2017
• Net weight : 4.08 lbs / 1.85 kg
TECHNICAL:
Material Forged Steel
Tensile Strength 10,000 lbs
Hardware for Steel 5/8" x 3" bolt
WARNING
This product is part of a personal fall arrest, restraint, work
positioning, personnel riding, or rescue system. The user must
follow the manufacturer's instructions for each component
of the system. These instructions must be provided to the
user of this equipment. Serious injury during fall arrest can be
prevented by using compliant fall protection and emergency
rescue systems. Users must understand the manufacturer's
instructions and be trained in the proper use of this product
per OSHA 29 CFR 1910.66 and 1926.503 or applicable local
standards. Manufacturer's instructions must be followed for
proper installation, use, care, and maintenance of this product.
These instructions must always be available for reference.
Alterations or misuse of this product or failure to follow
instructions may result in serious injury or death.
IMPORTANT
This manual is intended to meet the manufacturer's instructions
as required by the American National Standard Institute
Z359.18. This manual must always be available to the user and
is only permitted to be removed by the user of this equipment.
For proper use refer to supervisor, user instructions, or contact
the manufacturer. Do not alter or intentionally misuse this
equipment.
1.0 WARNINGS REGARDING THE SWIVEL ANCHOR:
• To safely use this equipment, the user must have a sound
mind and body. The user should also consult a physician
to ensure they are clear of any medical conditions that may
influence their ability to safely use this equipment in normal
and emergency situations.
• Users must be trained in accordance with OSHA 29 CFR
1910.66 requirements regarding the safe use of the system
and its components before using a personal fall arrest
system.
USER INSTRUCTION MANUAL
DESCRIPTION: STEEL SWIVEL ANCHOR & PUCK
MODEL: US-5082AC, US-5082AC-C, US-5082ACWP
MEETS OSHA & ANSI Z359.11-2017
• Use only with ANSI/OSHA compliant personal fall arrest or
restraint systems. The anchorage must have the strength
capable of supporting a static load, applied in the directions
permitted by the system, of at least 5,000 lbf (22kN) in the
absence of certification.
• Users must be equipped with the means to limit the
maximum dynamic forces exerted on them during fall arrest
to a maximum of 1,800 lbf (8kN).
• Before use, a competent engineer or other qualified person
must verify that this anchorage connector is compatible with
the structural and operational characteristics of both the
installation location and the system that it will be connected
to.
• Before use, the anchorage connector must be inspected
for a variety of factors, including wear, damage, and other
deterioration. Components that do not pass this inspection
must be immediately removed from service in accordance
with the requirements of OSHA 29 CFR 1910.66 and 1926.502.
• Immediately after a fall, the anchorage connector must be
removed from service and destroyed.
• Before use, the complete fall protection system (including
all components, calculating fall clearance, and swing fall)
should be planned. Ensure the anchorage connector is
positioned to minimize the potential for falls and the potential
distance during use.
• Users must have a rescue plan, and the means on hand to
implement it, that either: ensures the prompt rescue of users
in the event of a fall or assures that users are able to rescue
themselves.
2.0 WARNINGS REGARDING WORKING AT HEIGHT:
• Before use, consult your doctor to ensure that your physical
condition allows you to safely withstand the impact of all
forces involved with working at height.
• Do not use any fall protection equipment that has failed
inspection.
