  • Page 1 EN User Manual | Hob KCD73443...

  • Page 2: Table Of Contents

    Welcome to Electrolux! Thank you for choosing our appliance. Get usage advice, brochures, trouble shooter, service and repair information: www.electrolux.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. SAFETY INSTRUCTIONS................5 3. INSTALLATION....................7 4. PRODUCT DESCRIPTION................10 5.

  • Page 3: General Safety

    • Children should be supervised to ensure that they do not play with the appliance. • Keep all packaging away from children and dispose of it appropriately. • WARNING: The appliance and its accessible parts become hot during use. Keep children and pets away from the appliance when in use and when cooling down.
  • Page 4 • Metallic objects such as knives, forks, spoons and lids should not be placed on the hob surface since they can get hot. • Do not use the appliance before installing it in the built-in structure. • Do not use a steam cleaner to clean the appliance. •...

  • Page 5: Safety Instructions

    means for disconnection must be incorporated in the fixed wiring in accordance with the wiring rules. • WARNING: Use only hob guards designed by the manufacturer of the cooking appliance or indicated by the manufacturer of the appliance in the instructions for use as suitable or hob guards incorporated in the appliance.
  • Page 6 • Use the correct electricity mains cable. • Set the cooking zone to “off” after each • Do not let the electricity mains cable use. tangle. • Do not put cutlery or saucepan lids on the • Make sure that a shock protection is cooking zones.

  • Page 7: Installation

    • Be careful not to let objects or cookware use abrasive products, abrasive cleaning fall on the appliance. The surface can be pads, solvents or metal objects, unless damaged. otherwise specified. • Do not activate the cooking zones with 2.5 Service empty cookware or without cookware.

  • Page 8: Connection Cable

    The window switch has to be installed by an authorised technician. Refer to the installation booklet. Find the video tutorial "How to install your Electrolux Extractor Hob 70 cm" by typing out min. min. 500mm the full name indicated in the graphic below.
  • Page 9 3. Connect the ends of black and brown CAUTION! cables. 4. Apply a new wire end sleeve on the Connections via contact plugs are shared wire's end (special tool required). forbidden. 5. Connect the ends of two blue cables. 6. Apply a new wire end sleeve on the CAUTION! shared wire's end (special tool required).

  • Page 10: Product Description

    4. PRODUCT DESCRIPTION 4.1 Product overview Grid Drip tray (under the hood system) Grease filter housing Grease filter (non-removable) Air duct adapter Long life carbon filter (not included in this Air duct fitting for the back wall model) 4.2 Cooking surface layout Induction cooking zone Control panel Hood...

  • Page 11: Control Panel Layout

    4.3 Control panel layout 1 12 Use the sensor fields to operate the appliance. The displays, indicators and sounds tell which functions operate. Sensor Function Description field On / Off To activate and deactivate the appliance. Pause To activate and deactivate the function. Timer To set the function.

  • Page 12: Before First Use

    5. BEFORE FIRST USE 4. Press to exit. WARNING! Power levels Refer to Safety chapters. Refer to “Technical data” chapter. 5.1 Power limitation CAUTION! Power limitation defines how much power is Make sure that the selected power fits used by the hob in total, within the limits of the house installation fuses.

  • Page 13: Heat Setting

    6.6 OptiHeat Control (3 step Residual heat indicator) WARNING! As long as the indicator is visible, there is a risk of burns from residual heat. The induction cooking zones produce the heat necessary for the cooking process directly in the bottom of the cookware. The glass ceramic is heated by the heat of the cookware.

  • Page 14: Minute Minder

    To change the time: select the cooking zone • The hood extractor is always available as an electrical load. with and press 6.9 Hood functions To deactivate the function: select the cooking zone with and press . The WARNING! remaining time counts back to 00. Refer to Safety chapters.

  • Page 15: Menu Structure

    accordingly. The indicators above the hood 5. To deactivate the function during cooking symbol appear. and switch to the manual mode of the 4. Press 0 on the hob control bar to hood, press AUTO. A signal sounds and the indicator above the deactivate a cooking zone or symbol disappears.

  • Page 16: Additional Functions

    User settings appears on the front timer. To navigate between the settings press on the front Sym‐ Setting Possible options timer. To change the setting value press on the front timer. Sound On / Off (--) Power limitation 15 - 73 To exit the menu: press Hood mode 1 - 4...

  • Page 17: Child Safety Device

    1. To activate the function: press To deactivate the function: press . Do The heat setting is lowered to 1. The speed of not set any heat setting / hood setting. Press the hood fan decreases to 1. and hold for 3 seconds, until the indicator 2.

  • Page 18: Noises During Operation

    Cookware material • correct: cast iron, steel, enamelled steel, stainless steel, multi-layer bottom (with a correct marking from a manufacturer). • not correct: aluminium, copper, brass, glass, ceramic, porcelain. Cookware is suitable for an induction hob • water boils very quickly on a zone set to the highest heat setting.

  • Page 19: Care And Cleaning

    Heat setting Use to: Time Hints (min) Keep cooked food warm. as neces‐ Put a lid on the cookware. sary 1 - 2 Hollandaise sauce; melt: butter, choco‐ 5 - 25 Mix from time to time. late, gelatine. Solidify: fluffy omelettes, baked eggs. 10 - 40 Cook with a lid on.

  • Page 20: Cleaning The Hob

    9.2 Cleaning the hob 2. Move the drip tray vertically downwards. Be careful not to spill the water. • Remove immediately: melted plastic, plastic foil, salt, sugar and food with sugar, otherwise, the dirt can cause damage to the hob. Take care to avoid burns. Use a special hob scraper on the glass surface at an acute angle and move the blade on the surface.

  • Page 21: Troubleshooting

    cleaning the grease filters. The counter for 3. Reassemble the filtering unit after the notification starts automatically when cleaning: you turn on the hood for the first time. a. Place the grease filter housing back inside. After 140 hours of use the indicator b.
  • Page 22 10.1 What to do if... Problem Possible cause Remedy You cannot activate or operate The hob is not connected to an elec‐ Check if the hob is correctly connected the hob. trical supply or it is connected incor‐ to the electrical supply. rectly.

  • Page 23: Technical Data

    Authorised Service Centres are in the Service Centre. Give the data from the rating guarantee booklet. plate. Make sure, you operated the hob correctly. If not the servicing by a service 11. TECHNICAL DATA 11.1 Rating plate Model KCD73443 PNC 949 599 262 00 ENGLISH...

  • Page 24: Cooking Zones Specification

    It changes with the material and dimensions of the cookware. 12. ENERGY EFFICIENCY 12.1 Product Information for hob Model identification KCD73443 Type of hob Built-In Hob Number of cooking zones Heating technology Induction Diameter of circular cooking zones (Ø)
  • Page 25 12.3 Product Information and Product Information Sheet for hood Product Information Sheet according to (EU) No 65/2014 Supplier’s name or trade mark ELECTROLUX Model identifier KCD73443 Annual Energy Consumption - AEChood 32.7 kWh/a Energy Efficiency Class Fluid Dynamic Efficiency - FDEhood 32.0...

  • Page 26: Environmental Concerns

    Appliance tested according to: IEC / EN • Increase the fan speed only to get rid of 61591, IEC / EN 60704-1, IEC / EN large amounts of steam or smoke. It is 60704-2-13, IEC / EN 50564. recommended to use the Boost function only in extreme situations.
