- Page 1 EN User Manual | Hob KCC83443...
-
Page 2: Table Of Contents
Welcome to Electrolux! Thank you for choosing our appliance. Get usage advice, brochures, troubleshooting, service and repair information: www.electrolux.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. SAFETY INSTRUCTIONS................5 3. INSTALLATION....................7 4. PRODUCT DESCRIPTION................10 5. BEFORE FIRST USE..................12 6. -
Page 3: General Safety
• Children should be supervised to ensure that they do not play with the appliance. • Keep all packaging away from children and dispose of it appropriately. • WARNING: The appliance and its accessible parts become hot during use. Keep children and pets away from the appliance when in use and when cooling down. - Page 4 • Metallic objects such as knives, forks, spoons and lids should not be placed on the hob surface since they can get hot. • Do not use the appliance before installing it in the built-in structure. • Do not use water spray and steam to clean the appliance. •...
-
Page 5: Safety Instructions
means for disconnection must be incorporated in the fixed wiring in accordance with the wiring rules. • WARNING: Use only hob guards designed by the manufacturer of the cooking appliance or indicated by the manufacturer of the appliance in the instructions for use as suitable or hob guards incorporated in the appliance. - Page 6 • Use the correct electricity mains cable. • Set the cooking zone to “off” after each • Do not let the electricity mains cable use. tangle. • Do not put cutlery or saucepan lids on the • Make sure that a shock protection is cooking zones.
-
Page 7: Installation
• Be careful not to let objects or cookware abrasive cleaning pads, solvents or metal fall on the appliance. The surface can be objects, unless otherwise specified. damaged. 2.5 Service • Do not activate the cooking zones with empty cookware or without cookware. •... - Page 8 Find the video tutorial "How to install your hob. The window switch has to be Electrolux Extractor Hob 80 cm" by typing out installed by an authorised technician. the full name indicated in the graphic below.
-
Page 9: Connection Cable
3.5 Connection cable CAUTION! • The hob is supplied with a connection Do not drill or solder the wire ends. It is cable. forbidden. • To replace the damaged mains cable, use the cable type H05V2V2-F which CAUTION! withstands a temperature of 90 °C or higher. -
Page 10: Product Description
4. PRODUCT DESCRIPTION 4.1 Product overview Grid Cabinet back wall fitting Filter Tube Filter housing Adapter Connector 4.2 Cooking surface layout Induction cooking zone Control panel Hood ENGLISH... -
Page 11: Control Panel Layout
4.3 Control panel layout 1 12 Use the sensor fields to operate the appliance. The displays, indicators and sounds tell which functions operate. Sensor Function Description field On / Off To activate and deactivate the appliance. Pause To activate and deactivate the function. Timer To set the function. -
Page 12: Before First Use
5. BEFORE FIRST USE 4. Press to exit. WARNING! Power levels Refer to Safety chapters. Refer to “Technical data” chapter. 5.1 Power limitation CAUTION! Power limitation defines how much power is Make sure that the selected power fits used by the hob in total, within the limits of the house installation fuses. -
Page 13: Heat Setting
6.6 OptiHeat Control (3 step between the two centres, Bridge function will Residual heat indicator) not be activated. WARNING! As long as the indicator is visible, there is a risk of burns from residual heat. The induction cooking zones produce the heat necessary for the cooking process directly in the bottom of the cookware. -
Page 14: Minute Minder
To change the time: select the cooking zone • The hood extractor is always available as an electrical load. with and press 6.9 Hood functions To deactivate the function: select the cooking zone with and press . The WARNING! remaining time counts back to 00. Refer to Safety chapters. -
Page 15: Menu Structure
3. Place cookware on the hob and select a When the function operates, the indicator heat setting level. Increase or decrease above AUTO appears. Once the cycle is the heat setting level as needed. over, the fan switches off automatically. The hood will react to the temperature of the To deactivate the function while it is cooking zone, increasing or decreasing the... -
Page 16: Additional Functions
timer. To change the setting value press on the front timer. Refer to "Menu structure". To exit the menu: press When the sounds are off you can still hear the sound when: OffSound Control • you touch • the timer comes down, You can activate / deactivate the sounds in •... -
Page 17: Hints And Tips
7.5 Bridge To activate the function: press . Do not set any heat setting / hood setting. Press and hold for 3 seconds, until the indicator The function operates when the pot above the symbol appears. Deactivate the covers the centres of the two zones. For hob with more information on the correct placement of cookware refer to "Using... -
Page 18: Noises During Operation
8.2 Noises during operation diameter value in "Technical data" > "Cooking zones specification"). – Cookware with a diameter smaller than the size of a given cooking zone The noises are normal and do not receives only part of the power indicate any malfunction. -
Page 19: Care And Cleaning
Heat setting Use to: Time Hints (min) 1 - 2 Hollandaise sauce; melt: butter, choco‐ 5 - 25 Mix from time to time. late, gelatine. Solidify: fluffy omelettes, baked eggs. 10 - 40 Cook with a lid on. 2 - 3 Simmer rice and milk-based dishes, 25 - 50 Add at least twice as much liquid as... -
Page 20: Cleaning The Hob
9.2 Cleaning the hob WARNING! • Remove immediately: melted plastic, Make sure no liquid gets inside the hood. plastic foil, salt, sugar and food with sugar, otherwise, the dirt can cause damage to If water or other liquids spill inside the the hob. -
Page 21: Cleaning The Filter Housing
regenerate the filter. The notification stays on for 30 seconds after you deactivate the hood and the hob. The notification does not block the use of the hob. WARNING! An oversaturated filter can pose a risk of fire. Disassembling / reassembling the filter The filter and filter housing are located right under the grid in the centre of the hob. -
Page 22: Troubleshooting
3. Reassemble the filtering unit and put it Regenerating the filter back inside the hood cavity. 1. Clean the filter first, as described above 4. Press briefly to reset the counter. in step 1. The counter restarts. 2. Put the filter in the oven set to 80-110 °C for 60 min. - Page 23 Problem Possible cause Remedy The control panel becomes hot to The cookware is too large or you put Put large cookware on the rear zones, the touch. it too close to the control panel. if possible. There is no sound when you The sounds are deactivated.
-
Page 24: Technical Data
Make sure, you operated the hob correctly. If not the servicing by a service 11. TECHNICAL DATA 11.1 Rating plate Model KCC83443 PNC 949 599 214 00 Typ 66 D4A 01 AA 220 - 240 V / 400 V 2N, 50 Hz Induction 7.35 kW... -
Page 25: Energy Efficiency
12. ENERGY EFFICIENCY 12.1 Product Information according to EU Ecodesign Regulation for Hob Model identification KCC83443 Type of hob Built-In Hob Number of cooking zones Heating technology Induction Diameter of circular cooking zones (Ø) Right front 14.5 cm Right rear 18.0 cm... - Page 26 Model identifier KCC83443 Annual Energy Consumption - AEChood 30.9 kWh/a Energy Efficiency Class Fluid Dynamic Efficiency - FDEhood 33.1 Fluid Dynamic Efficiency class Lighting Efficiency - LEhood lux/W Lighting Efficiency Class Grease Filtering Efficiency - GFEhood 85.1 Grease Filtering Efficiency class Minimum Air Flow in normal use 260.0...
-
Page 27: Environmental Concerns
• Clean the hood filter regularly and replace • Use the maximum diameter of the ducting it when necessary to maintain its system to optimize efficiency and minimize efficiency. noise. 13. ENVIRONMENTAL CONCERNS appliances marked with the symbol with Recycle materials with the symbol . - Page 28 867373866-G-382024...
