- Page 1 User’s guide “WF/CF” series Wall/ceiling aeroconvector Replacement component list included This unit complies with the CSA standards For further information or to consult this guide on line, please visit our Web site. INS_WF-CF1210...
- Page 2 If an option must be added, make sure it has been approved by Stelpro. This way, it will ensure that it has been tested in accordance with our safety rules and that an appropriate installation has been planned into the unit.
-
Page 3: Technical Drawings
SELECTION TABLE – WF SERIES SELECTION TABLE – CF SERIES Without control Without control Type volts watts Type volts watts WF1502 240/208 1500/1125 CF1502 240/208 1500/1125 WF1508 1500 CF1508 1500 WF1507 1500 CF1507 1500 WF2002 240/208 2000/1500 CF2002 240/208 2000/1500... -
Page 4: Installation
45 7/16'' 1154mm 11 5/16'' 7 3/16'' 8 15/32'' 182mm 287mm 215mm 1 29/32'' 2 27/32'' 49mm 72mm 3 25/32'' 96mm 1 1/2'' DESSUS/TOP 38mm WALL 11 7/32'' 7 13/32'' 8 1/4'' 7/8'' 285mm 188mm 210mm 5 9/32'' 47 3/4'' 22mm 134mm (2X) -
Page 5: Maintenance
MAINTENANCE N.B. In order for the warranty to be valid, the unit must be cleaned regularly. Switch off the main breaker in the electrical panel before cleaning the unit. Use a soft rag for dusting. When cleaning, use only a damp rag and non- abrasive dish soap. - Page 6 The warranty is limited to the repair or the replacement of the unit or the refund of its purchase price, at the discretion of Stelpro. Any parts replaced or repaired within the warranty period with the written authorization of Stelpro will be warranted for the remainder of the original war- ranty period.
