Rectangular Wash Basin 600mm
Installation Instructions
KNP311612
KNP311612-100
KNP311610-100
Enware products are to be installed in accordance with the Plumbing Code of Australia (PCA) and AS/NZS3500.
Installations not complying with PCA and AS/NZS 3500 may void the product and performance warranty provisions.
Reference should also be made to the Australasian Health Facility Guidelines (AHFG), ABCB and Local Government
regulations when considering the choice of, and the installation of these products.
NOTE: Enware Australia advises:
1. Due to ongoing Research and Development, specifications may change without notice.
2. Component specifications may change on some export models.
All measurements are in millimetres.
I00644_09 Jan 2025
1300 369 273 | info@enware.com.au | enware.com.au
600
280
Advertisement
Related Manuals for Watts ENWARE KNP311612
Summary of Contents for Watts ENWARE KNP311612
- Page 1 Rectangular Wash Basin 600mm Installation Instructions KNP311612 KNP311612-100 KNP311610-100 Enware products are to be installed in accordance with the Plumbing Code of Australia (PCA) and AS/NZS3500. Installations not complying with PCA and AS/NZS 3500 may void the product and performance warranty provisions. Reference should also be made to the Australasian Health Facility Guidelines (AHFG), ABCB and Local Government regulations when considering the choice of, and the installation of these products.
- Page 2 INSTALLATION Ensure there is adequate wall structure and suitable reinforcement behind finished wall for basin fixings at the required height position. Prepare water and waste outlet points according to the plumbing setouts (refer to setout diagrams). Position the basin onto wall, level, and mark anchor holes. Pre-drill anchor holes where marked, and install fixing bolts.
- Page 3 STANDARD P-TRAP MICROTRAP SET OUT SET OUT Standard P-Trap (Optional) Microtrap Chrome Code: KOL15600 With Plug & Grate Standard Plug and Waste (supplied) (Optional) Code: IFO14934 Code: IFO15916 Shroud (Optional) With Pop Up (Optional) Code: KNP37100 Code: IFO15917 DN40 DWV PVC outlet for Standard P-Trap KOL15600 (not supplied) with...
- Page 4 - WATTS AUSTRALIA EFFECTIVE FROM 20 November 2023 3. Our responsibilities This Warranty Statement applies to products supplied by Australian Valve (a) In the event that the Supplier is reasonably satisfied that there is a Group Pty Ltd (ACN 068 227 270) (AVG) or Enware Pty Ltd (ACN 662...
