ICON ProCon TB800 Series Quick Start Manual

Low range turbidity sensor
Hide thumbs Also See for ProCon TB800 Series:

Advertisement

Table of Contents

ProCon
— TB800 Series
®
Low Range Turbidity Sensor
Quick Start Manual
RoHS
Compliant
Read the user's manual carefully before starting to use the unit.
Producer reserves the right to implement changes without prior notice.
1
24-0605 © Icon Process Controls Ltd.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ProCon TB800 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ICON ProCon TB800 Series

Summary of Contents for ICON ProCon TB800 Series

  • Page 1 — TB800 Series ® Low Range Turbidity Sensor Quick Start Manual RoHS Compliant Read the user's manual carefully before starting to use the unit. Producer reserves the right to implement changes without prior notice. 24-0605 © Icon Process Controls Ltd.

  • Page 2: Installation

    The effluent/measured fluid outlet is a drainage connection; when the electric valve is activated, it will empty all the water in the turbidity measuring module. 24-0605 © Icon Process Controls Ltd.

  • Page 3: Technical Specifications

    Liquid Tight Connectors Liquid Tight Connectors Color Description +9-36 VDC Black -VDC 48mm 48mm Green RS485A White RS485B Blue Relay TB800 Series Turbidity Controller Yellow Relay Note: Refer Page 8 for Electric Valve connection 24-0605 © Icon Process Controls Ltd.

  • Page 4: Communication Protocol

    0.000 Read-Write Single Float Linear Compensation 1.000 Read-Write Single Float Temperature Correction 0.000 Read-Write Single Float Temperature Setting 25.0 Read-Write Single Float Second Calibration Point Read-Write Single Float Third Calibration Point Read-Write Single Float 24-0605 © Icon Process Controls Ltd.

  • Page 5: Sensor Calibration

    Example : To calibrate the turbidity sensor of range 0-400 NTU, the calibration solution prepared is 250 NTU. Select the 06 function code, Address input is 00138, that is, the 9th calibration point, then enter 250 in the Value. After the voltage value of the 00150 is stable, the calibration is completed. 24-0605 © Icon Process Controls Ltd.
  • Page 6 [3E 8A 41 6D]=14.8; | Temp. value; parsing order:41 6D 3E 8A ■ [09 18 41 88]=17.0; | Turbidity value; parsing order:41 88 09 18 ■ [XX XX] Represents the CRC 16 check code. Temperature Value = 14.8 Turbidity Value = 17.0 Fig.(c) 24-0605 © Icon Process Controls Ltd.
  • Page 7 25 ± 1°C incubator or constant temperature water bath. Let stand for 24 hours to make 4000NTU standard solution. Turbidity Standard Solution The total preparation volume was 100ml. Concentration (NTU) 400NTU Absorb Quantity (ml) 4000NTU Absorb Quantity (ml) – – – 17.5 1000 – 24-0605 © Icon Process Controls Ltd.
  • Page 8 TB800 Series Sensor – Controller Wiring RS485A (Green) -VDC (Black) RS485B (White) +VDC (Red) V+ V- A B V+ V- A B I1 G I2 A B G TX RX DC+ DC- Sensor Sensor 4-20mA RS485 RS232 24-0605 © Icon Process Controls Ltd.

  • Page 9: Maintenance

    Perform routine cleaning based on usage conditions to maintain measurement accuracy Inspection of Sensor Damage Examine the sensor for any visible damage. If damage is detected, promptly contact ICON at 905-469-7283 . This prevents potential issues caused by water ingress due to sensor damage.
  • Page 10 Icon Process Controls Ltd for a period of one year from the date of sale of such products. Icon Process Controls Ltd obligation under this warranty is solely...
