ICON Truflo TKP Series Quick Start Manual

In-line paddle wheel flow meter sensor
Hide thumbs Also See for Truflo TKP Series:
Table of Contents

Advertisement

Quick Links

Download this manual
Truflo
— TKP | TK3P Series (V1)
®
In-Line Paddle Wheel Flow Meter Sensor
Read the user's manual carefully before starting to use the unit.
Producer reserves the right to implement changes without prior notice.
Find Quality Products Online at:
24-0597
© Icon Process Controls Ltd.
Quick Start Manual
Valuetesters.com
info@valuetesters.com
1
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Truflo TKP Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ICON Truflo TKP Series

Summary of Contents for ICON Truflo TKP Series

  • Page 1 In-Line Paddle Wheel Flow Meter Sensor Quick Start Manual Read the user's manual carefully before starting to use the unit. Producer reserves the right to implement changes without prior notice. Valuetesters.com Find Quality Products Online at: info@valuetesters.com 24-0597 © Icon Process Controls Ltd.

  • Page 2: Safety Information

    10% Particle Size - Not to Exceed .5mm Cross Section or Length. Please do not flush the pipe after the Flow Meter is installed with compressed air this may damage the ceramic shaft and will void warranty. Valuetesters.com Find Quality Products Online at: info@valuetesters.com 24-0597 © Icon Process Controls Ltd.

  • Page 3: Product Description

    Eliminates Finger Spread No Lost Paddles Increased Temp. Rating 360° Housing Protects Rotor Finger Spread = LOST Unprotected Rotor Thermal Plastic TK3P 316 SS vs. Competitor ‘A’ Valuetesters.com Find Quality Products Online at: info@valuetesters.com 24-0597 © Icon Process Controls Ltd.

  • Page 4: Technical Specifications

    RS485 Display Flow Rate + Flow Totalizer Standards and Approvals RoHS Compliant *Optional See Temperature and Pressure Graphs for more information ** ¼” - ⅜” SS Only Valuetesters.com Find Quality Products Online at: info@valuetesters.com 24-0597 © Icon Process Controls Ltd.

  • Page 5: Wiring Diagram

    Pulse (NPN) Load Flow White Pulse (NPN) Load -VDC RS485B Blue Grey Meter Yellow Output RS-485 Special Option Pulse Output Grey Circuit Pulse Output NPN White Black Blue Valuetesters.com Find Quality Products Online at: info@valuetesters.com 24-0597 © Icon Process Controls Ltd.

  • Page 6: Totalizer Reset

    Refer to Page 9 for K-Factor Values Totalizer Reset STEPS DISPLAY OPERATION Home Screen ▶ Home Screen �� 3 Sec . Totalizer Reset ▶ Totalizer Value will Reset to Zero Valuetesters.com Find Quality Products Online at: info@valuetesters.com 24-0597 © Icon Process Controls Ltd.

  • Page 7: Setting Output Limits

    Note: Refer to 'Relay Mode Selection' on Page 8 to Black Pulse Output (1 Pulse/Gal) configure the relay output as needed. White SSR (Flow Rate) Blue -VDC Valuetesters.com Find Quality Products Online at: info@valuetesters.com 24-0597 © Icon Process Controls Ltd.
  • Page 8 [SV - Hys] — ▶ Relay OFF: CV > [SV + Hys] or CV < [SV - HyS] — ▶ Relay ON Hys = Hysteresis — Acts like a buffer ± around (OP1) pulse output CV: Current Value (Flow Rate) | SV = Set Value Valuetesters.com Find Quality Products Online at: info@valuetesters.com 24-0597 © Icon Process Controls Ltd.

  • Page 9: Min/Max Flow Rates

    TK3P-20-SS 1” TKP-25-PP 1” TK3P-25-SS 1 ½” TKP-40-PP 1 ½” TK3P-40-SS 2” 2” TKP-50-PP TK3P-50-SS 3” Flanged TKP-80-PP 3” TK3P-80-SS 316SS PVDF 4” Flanged TKP-100-PP 4” TK3P-100-SS Valuetesters.com Find Quality Products Online at: info@valuetesters.com 24-0597 © Icon Process Controls Ltd.
  • Page 10 Pull the Screws | Do Not Remove! located on either side of the display. Lift the Display. Tighten Allen Screws | Snug Tight Rotate Display 90°. Lower Display. Do Not Over-Tighten! Valuetesters.com Find Quality Products Online at: info@valuetesters.com 24-0597 © Icon Process Controls Ltd.

  • Page 11: Installation Position

    fibers - max 10% Particle Size - Not to Exceed .5mm Cross Section or Length. Please do not flush the pipe after the Flow Meter is installed with Compressed Air this may damage the ceramic shaft and will Void Warranty. Valuetesters.com Find Quality Products Online at: info@valuetesters.com 24-0597 © Icon Process Controls Ltd.
  • Page 12 Icon Process Controls Ltd for a period of one year from the date of sale of such products. Icon Process Controls Ltd obligation under this warranty is solely...
