Liko SilhouetteSling Mod. 22
Instructions for Use
Intended Use: Liko SilhouetteSling is a pliable sling which
adapts to the body and requires minimal space in the
wheelchair. It provides for a slightly reclined sitting posture
and excellent support for the entire body, which is good for
patients with reduced head and torso stability. The patient
can hold the arms either outside or inside the sling. The head
support is adjustable.
Design and material make Silhouette Sling particularly
suitable for lifting to molded seats, since the sling is usually
left in the wheelchair after the lifting operation is completed.
This makes it very popular in care and rehabilitation
situations, where sitting shells and molded seats are
commonly used. Silhouette Sling can also be used in bathing
and showering situations.
It is intended for use in following environments: Health care,
Intensive care, Emergency ward, Rehabilitation, Habilitation
and Home healthcare environment
A properly fitted and carefully applied sling will give the patient
an excellent sense of security, as well as a high degree of
comfort.
In this document, the person being lifted is referred to as the patient, and the person helping is referred to as the caregiver.
IMPORTANT!
Lifting and transferring a patient always involves a certain level of risk. Read the instructions for use for both the patient
lift and lifting accessories before use. It is important to completely understand the contents of the instructions for use.
The equipment should only be used by a trained caregiver. To be trained, a caregiver needs to read and understand the
Instructions for Use. Ensure that the lifting accessories are suitable for the lift used. Exercise care and caution during use.
As a caregiver, you are always responsible for the patient's safety. You must be aware of the patient's ability to make it
through the lifting situation. If something is unclear, contact the manufacturer or supplier.
7EN160137 Rev. 9
ENGLISH 2024
Product Description
Sizes
The SilhouetteSling is available in different sizes. It is important
to choose the correct size in order to achieve the highest level
of comfort and safety. A sling which is too large increases the
risk of the patient sliding out of it, while one which is too small
can cut into the groin and cause discomfort.
Fabrics
SilhouetteSling is made of a comfortable, pliable net polyester
fabric which allows body heat and moisture to pass through.
Suitable Lifts
The SilhouetteSling can be used with all Liko overhead and
mobile lifts. You can choose between the LikoGuard overhead
lift, Likorall overhead lift, and Multirall overhead lift, or the
Golvo mobile lift, Viking mobile lift, Uno mobile lift, and Liko
M220/M230 mobile lift.
