Liko SupportVest is a comfortable sit-to-stand vest
that is easy to use and requires relatively little indivi-
dual adjustment. It is suitable for patients who require
a lot of assistance in standing, but are capable of
standing steadily on their own once they are up.
The SupportVest lifts around the back and under the
arms. The inside is lined with corduroy, which pre-
vents the vest from sliding up on the body.
The Liko SupportVest is mainly intended for use in
combination with the Sabina sit-to-stand lift with the
350 Slingbar (narrow).
In combination with Sabina, the SupportVest form
a functional unit. For complete information and best
results, read the instruction guides for both products.
is a warning triangle used for situations which require extra care and attention.
In this document, the person being lifted is referred to as the patient and the person helping is referred to as the caregiver.
Read the instruction guide for both the sling and the lift being used. Instruction guides can be
downloaded, free of charge, at www.liko.com.
Liko SupportVest™, Mod. 91

Product Description

Sizes
The Liko SupportVest is available in different sizes.
It is important to choose the correct size in order to
achieve the highest level of comfort and safety.
Waist Belt
The SupportVest is equipped with a waist belt that
keeps the vest in place around the upper body during
application.
Padding
For a softer surface that distributes pressure more
evenly the SupportVest is equipped with a padding
liner of synthetic sheepskin. The vest can be used
with or without the padding, since the padding is
secured with a zipper and can be removed. Extra
paddings are available for replacement.
Instruction Guide
English
7EN160145-04

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SupportVest 91 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Liko SupportVest 91

  • Page 1: Product Description

    The Liko SupportVest is mainly intended for use in Padding combination with the Sabina sit-to-stand lift with the For a softer surface that distributes pressure more 350 Slingbar (narrow).
  • Page 2: Safety Instructions

    MDD Class I products and the harmonized EN ISO 10535 standard. Liko is quality certified in accordance with ISO 9001 and its equivalent for the medical device industry, ISO 13485. Liko is also certified in accordance with environmental standard ISO 14001.
  • Page 3 The waist belt on the SupportVest is intended to hold the vest in place around the patient, but it is not intended to be used lifting the patient or securing the patient in the vest. If the patient requires a waist belt for safety reasons, we recommend changing to Liko SafetyVest or Liko ComfortVest. Outer strap guide...
  • Page 4 Fasten the waist belt’s buckle. should be in level with the patient’s weist. The patient’s arms must always be held outside the vest to prevent the vest from sliding up. Liko SupportVest • 7EN160145-04 ww w . li ko.c om...
  • Page 5 This will help to keep the vest in place and provide good back support during raising. comfort and prevents the vest from sliding upward. Liko SupportVest • 7EN160145-04 w w w .l i k o .c o m...
  • Page 6 If the vest is too large, the patient may not be able to grasp the sling bar. Alternative Sit-to-stand Vests If the patient requires a waist belt for safety reasons, we recommend changing to Liko SafetyVest or Liko Comfort- Vest.
  • Page 7 Accessories for Liko SupportVest Sabina SeatStrap Prod. No. 3591115 The SeatStrap is an accessory that facilitates the first part of the raising motion. The SeatStrap is connected to a SeatStrap SlingBar, which helps the patient move the seat up when raising. In standing position, the SeatStrap can be easily disconnected so that it is not in the way when, e.g.,...
  • Page 8 We recommend Sabina with Sabina 350 SlingBar (narrow). Other Combinations Combinations of accessories/products other than those recommended by Liko can result in risks for the safety of the patient. In those cases where another manufacturer recommends Liko’s accessories/products in combination with their or others’...
