52-inch smart ceiling fan
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Item #**********
Model #CF2003-W, CF2003-B, CF2003-N
ETL Model #CF2003-W, CF2003-B, CF2003-N
USE AND CARE GUIDE
OSSA 52-INCH SMART CEILING FAN
Questions, problems, missing parts? Before returning to the store,
call Home Decorators Collection Customer Service
8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday.
1-877-592-5233
HOMEDEPOT.CA/Hubspace
THANK YOU
to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home
improvement needs. Thank you for choosing Home Decorators Collection!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OSSA CF2003-W and is the answer not in the manual?

Questions and answers

Related Manuals for Home Decorators Collection OSSA CF2003-W

Summary of Contents for Home Decorators Collection OSSA CF2003-W

  • Page 1 8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday. 1-877-592-5233 HOMEDEPOT.CA/Hubspace THANK YOU to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you for choosing Home Decorators Collection!
  • Page 2 Table of Contents...

  • Page 3: Wireless Protocol

    "wobble" is normal and should not be considered a defect. Servicing performed by unauthorized persons shall render the warranty invalid. There is no other express warranty. Home Decorators Collection hereby disclaims any and all warranties, including but not limited to those of merchantability and tness for a particular purpose to the extent permitted by law.

  • Page 4: Pre-Installation

    Pre-Installation SPECIFICATIONS Gross Size Speed Volts Amps Watts Cu. Ft. Weight Weight 1800 0.045 2300 0.070 3100 0.105 52 in. 16.53lbs 21.38lbs 1.993 3900 0.160 (7.5 kg) (9.7 kg) 4700 0.260 15.5 5500 0.345 NOTE These are approximate measures. They do not include the amps and wattage used by the light kit.
  • Page 5 Pre-Installation (continued) Part Description Quantity Part Description Quantity Mounting bracket LED module Glass shade Canopy Canopy cover Blade Hanger ball (preassembled) Remote control receiver Remote control transmitter Downrod (preassembled) Remote control holder Coupling cover Extension wire Fan-motor assembly Light housing assembly HOMEDEPOT.CA/Hubspace Please contact 1-877-592-5233 for further assistance.

  • Page 6: Installation

    Installation MOUNTING OPTIONS Hanger Bar WARNING: personal inju ry, mount to outlet box marked “A cceptable for fan suppor t of 35 lbs. (15.9 kg) or less”, and use screws provided with the outlet box. An outlet box not be acceptabl e for fan supp ort and may need to be Outlet Box If your ceiling fan does not have an existing UL-listed mounting box, then install one using the following instructions:...
  • Page 7 Assembly — Hanging the Fan Install the mounting bracket to the outlet box To reduce the risk of fire, electric shock, or other personal injury, mount the fan only WARNING: to an outlet box or supporting system marked acceptable for fan support and use the mounting screws provided with the outlet box.
  • Page 8 Assembly - Hanging the Fan (continued) Attaching the downrod to the fan motor assembly Loosen the two fan motor assembly coupling set screws □ (QQ) from the fan motor assembly (G) coupling. □ Remove the hitch pin (PP) and lock pin (OO) from the downrod (E).
  • Page 9 Assembly - Hanging the Fan (continued) Making the electrical connections To avoid possible electrical shock, ensure the WARNING: electricity is turned off at the circuit breaker or main fuse box Figure 5 before wiring. Check to see that all connections are tight, WARNING: including the ground, and that no bare wire is visible at the wire nuts, except for the ground wire.
  • Page 10 Assembly - Hanging the Fan (continued) Securing the fan motor assembly to the mounting bracket Loosen two mounting bracket screws (RR) away from the mounting bracket (A) 1/3 length. □ □ Attach the canopy (B) key shape hole to the mounting bracket (A) screws (RR) previously loosen and clockwise rotate the Canopy.
  • Page 11 Assembly - Hanging the Fan (continued) Install the blades □ Remove all blade screws from the rotary plate (SS) of fan-motor assembly (G). □ Insert the blades (K) into holes of the rotary plate (SS) in place. □ Reattach all blade screws through the blade washers and tighten all screws to make sure the blades (K) is secure.
  • Page 12 Assembly - Hanging the Fan (continued) Install the light housing Install the LED module Remove 3pcs pre-installed screws from inside of the lightkti □ Remove one screw from the connect plate (P) of fan-motor □ assembly (G). And loosen other 2pcs screws away from 3/4 length. pan (H).
  • Page 13 Assembly - Hanging the Fan (continued) Install the glass shade Install the remote bracket Install scenarios 1: Direct to Wall via screws and dry wall anchors Rotate the glass shade (G) clockwise until it is secure. □ Using the remote bracket plate 2 as a guide, mark the two holes □...

  • Page 14: Remote Operation

    Remote Operation NOTE Wait for the fan to stop before reversing the direction of the Warm weather blade rotation. 433 Remote control Your fan is equipped with a remote contol to operate the speed and lights for your new ceiling fan. effect.
  • Page 15 Remote Operation Icon Button Name Action Notes Press different buttons will light up 6 Speed LED different quantity of indicators Short press to turn Fan and light All ON/OFF on/off Short press to turn fan on/off Fan ON/OFF Long press for 5 seconds to reset factory default setting Short press to turn light on/off The brightness and CCT will be the...
  • Page 16 Smart Setup Operation Download the Hubspace™ app from Create an account to sign in or log in the App Store or the Google Play if you already have an account. Store. For more information on the Hubspace app, visit hubspace.ca/Hubspace. Connect your ceiling fan to power Tap the ‘+’...

  • Page 17: Voice Commands

    Voice Commands he Ossa 52 in. LED Indoor Smart Color Changing Ceiling Fan works with Alexa a nd Google Assistant. This section list s some of the voice comm ands you can use. To view these and other commands, go to http://hub spaceconnect.ca Alexa Google urn on the fan only.

  • Page 18: Troubleshooting

    Troubleshooting Problem Solution The fan will not start. 1. Check to make sure the wall switch is in the on position if applicable. 2. Check the main and branch circuit fuses or breakers. 3. Make sure your device is connected to a power source. 4.
  • Page 19 Troubleshooting Problem Solution My Hubspace device is not Make sure your device is connected to a power source. Your Internet connecting to Wi-Fi. connection or Wi-Fi network may be down. My device cannot nd any Make sure you have a 2.4GHz capable Wi-Fi network within range of the Wi-Fi networks.
  • Page 20 Questions, problems, missing parts? Before returning to the store, call Home Decorators Collection Customer Service 8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday 1-877-592-5233 HOMEDEPOT.CA/Hubspace Retain this manual for future use.
