The connected electrical equipment must not exceed the maximum limit of the generator. Please refer to the
specification table for details.
NOTE: After completing the above preparation, the generator is ready to be started.

GENERATOR OPERATION

WARNING: It is prohibited to start or close the generating set when the output terminal of
generating set is connected to an electric device is in "ON" state.
Generator Start
● Disconnect the electrical equipment from the alternator's AC socket before starting the engine.
● Make sure that the ECO switch is on "OFF"position.
● For initial use (long unused, start after gasoline is used up), turn the fuel tap to "ON" position for 10 to
20 seconds before starting, so that gasoline can enter the engine carburetor.
● Do not connect device to the panel before generator start. The device should be in off position when it
is connecting to the generator.
Cold Start
1. Disconnect all electrical equipment from the generator output socket before
starting the engine.
2. Rotate the Fuel Tap to place the start button on "CHOKE" position as shown in
the right figure.
3. Grasp the recoil starter handle and pull slowly until resistance is felt, and then pull
rapidly to avoid kickback. Firmly grasp the generator to avoid tumble of generator.
NOTE: Pay attention to pull the starting handle, the pull angle should not be too large,
to prevent the handle from wearing the housing. Do not allow the starting handle to
rebound and retract automatically to avoid damage to the shell. Slowly put the starting handle back.
4. After starting the engine, wait about 5 seconds, rotate the Fuel Tap to place the start button in the "ON"
position。
5. After all above operations, the engine can be normally loaded.
NOTE: To use electrical equipment, AC circuit breaker should be placed in "ON" position.
Warm Start
When the gasoline engine starts in the hot engine status, rotate the Fuel Tap to place the start button in the
"ON" position and pull the recoil starter.
WARNING: Check starter cord conditions before operating. Have it replaced immediately by
local authorized dealer if cord is frayed.
Using The Generator
Connect to electrical devices
● Inspect power cord for damage before using. There is a hazard of electrical shock from crushing, cutting
or heat damage.
● Make sure that the generating set has been properly grounded. If the electric devices require grounding,
the generating set must ground.
● Make sure that the electric devices are in "OFF" position.
