INSTRUCTION MANUAL
2500W Inverter Generator
Model # HB5020C
Have product questions or need technical support? Please scan the QR code to enter our official
website and contact us!
Website: www.powersmartusa.com
Toll free: 1-872-314-0005 Mon-Fri 9-5 EST
Email: support@amerisuninc.com / support@powersmartusa.com
1
website
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Power smart HB5020C
Summary of Contents for Power smart HB5020C
- Page 1 INSTRUCTION MANUAL 2500W Inverter Generator Model # HB5020C Have product questions or need technical support? Please scan the QR code to enter our official website and contact us! Website: www.powersmartusa.com Toll free: 1-872-314-0005 Mon-Fri 9-5 EST Email: support@amerisuninc.com / support@powersmartusa.com...
- Page 3 GENERATOR OPERATION ............................15 MAINTENANCE ................................18 TROUBLESHOOTING ..............................22 EXPLODED VIEW & PARTS LIST ..........................24 WARRANTY .................................. 28 TECHNICAL DATA 2500W inverter generator Model#HB5020C Engine type: 4 stroke, OHV, single cylinder with forced air-cooling system Start type: Manual Phase:...
- Page 4 INTRODUCTION Thank You for Purchasing a PowerSmart® Product. This manual provides information regarding the safe operation and maintenance of this product. Every effort has been made to ensure the accuracy of the information in this manual. PowerSmart® reserves the right to change this product and specifications at any time without prior notice.
- Page 5 GENERAL SAFETY RULES DANGER: CARBON MONOXIDE Using a generator indoors CAN KILL YOU IN MINUTES. Generator exhaust contains carbon monoxide (CO). This is a poison gas you cannot see or smell. If you can smell the generator exhaust, you are breathing CO.
- Page 6 ● Allow generator to cool down after use before touching engine or areas of the generator that become hot during use. CAUTION: Misuse of this generator can damage it or shorten its life. ● Only use generator for its intended purposes. ●...
- Page 7 SYMBOLS Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the product better and safer. SYMBOL NAME DESIGNATION/EXPLANATION Volts Voltage Amperes Current Hertz Frequency (cycles per second)
- Page 8 KNOWING YOUR INVERTER GENERATOR Use the illustrations below to become familiar with the locations and functions of the various components and controls of this generator. Carrying handle Engine switch 7 Air filter and oil maintenance cover Tank cap switch Recoil start handle 8 Spark plug maintenance cover Fuel tank cap Control panel...
- Page 9 CO Alarm Light(Red) When the concentration of CO exceeds the standard, the CO alarm light will turn on Red and the generator stops soon. CO Failure Light(Yellow) When the CO sensor is broken, the CO failure light will be on Yellow. Oil Warning Light (Yellow) The low oil level alarm system is designed to prevent engine damage due to insufficient oil in the crankcase.
- Page 10 generating set must be properly grounded before operation. ECO switch When the energy-saving switch is in the energy-saving position, the generator is in the energy-saving state. When disconnecting or using low power, the engine automatically returns to a low speed state, thus reducing engine fuel consumption Full speed “full speed”...
- Page 11 GENERATOR PREPARATION The following section describes steps necessary to prepare the generator for use. If after reading this section, you are unsure about how to perform any of the steps please call (872) 314-0005 Mon-Fri 9-5 EST for customer service. Failure to perform these steps properly can damage the generator or shorten its lifespan. Unpacking Unpack the generator and all its parts.
- Page 12 engine damage and void your warranty. Engine Oil Recommendations Only use 4-stroke engine oil of SJ,SL or equivalent level which are in accordance with or higher than API standard. Check the API label on oil bottle or other container, and make sure the “SJ,SL” or equivalent level letter is in the label.
- Page 13 refueling, tighten the tank cover and wipe up any spilled fuel. Prevent dirt and water from entering the tank. ● Do not use gasoline containing more than 10% ethanol or gasoline containing methanol, otherwise the engine will be seriously damaged. To add gasoline, follow these steps: 1.
- Page 14 Generator Set Grounding DANGER: Failure to properly ground the generator can result in electric shock. The generator must be properly connected to an appropriate ground. It helps prevent electrical shock if a ground fault condition exists in the generating set or in connected electrical devices, especially when the unit is equipped with a wheel kit.
- Page 15 GENERATOR OPERATION Generator Start ● Disconnect the electrical equipment from the alternator's AC socket before starting the engine. ● For initial use (long unused, start after gasoline is used up), turn the engine switch knob to "ON" position for 10 to 20 seconds before starting, so that gasoline can enter the engine carburetor. 1.
- Page 16 Using The Generator WARNING: It is prohibited to start or close the generating set when the output terminal of generating set is connected to an electric device is in “ON” state. Connect to electrical devices ● Inspect power cord for damage before using. There is a hazard of electrical shock from crushing, cutting or heat damage.
- Page 17 DC application The output voltage of DC socket is 15-20 V, for 12V DC load only. ● When AC power is used, DC power supply can be used. ● Overload of DC may make DC over protector act. Firstly, remove the DC load, wait for a few minutes, and then reset the button of DC protector.
- Page 18 MAINTENANCE The purpose of maintenance and periodic maintenance is to keep the generator in the best operating condition. WARNING: Improper maintenance or failure correct a problem before operation can cause a malfunction and result in property damage, serious injury or DEATH. lease use our original spare parts or the same quality parts when replacing damaged parts.Improper maintenance will void your warranty.
- Page 19 every 10 hours; If necessary, change the air filter element every 25 hours. ● If maintenance period and the exact time(hour), the one which comes first should govern. ● If you have missed the scheduled time to maintain your engine, do it as soon as possible. Generator Maintenance WARNING: Never clean the generator when it is running! Never use water to clean the generating set.
- Page 20 Air Filter Maintenance WARNING: Do not run the engine without the air filter, or serious danger can result. A dirty Air Cleaner will restrict air flow into the carburetor. Please clean and maintain the air cleaner regularly to prevent carburetor from breaking down,If generators are often used in high dust areas, they need to be maintained more frequently.
- Page 21 Spark Collector Maintenance WARNING: The spark collector must be maintained for every 100 hours of engine operation. 1. When the muffler is cooled, loosen the screws from the muffler outlet and take off the spark collector. 2. Use a brush to clean the carbon deposits on the spark collector. If the spark collector is damaged, and replace it.
- Page 22 TROUBLESHOOTING...
- Page 23 WIRING DIAGRAM...
- Page 24 EXPLODED VIEW & PARTS LIST Generator Exploded View...
- Page 25 Generator Part List Item Stock＃ Description Item Stock＃ Description Item H79i powered Pipe H79i-TJDB000 25130-G290021-000I0 Hexagon flange bolt - Clamp 91101-0612-00200 95206-E010010-00000 Small series Frame shock-absorbing Clamp 41130-G290022-00000 95206-G290502-00000 seat assembly Frame shock-absorbing Fuel filter screen assembly 41130-G290021-00000 25190-G290032-00000 seat assembly Hexagon flange nut Rubber sleeve, Fuel tank 92201-0600-00100...
- Page 26 Engine Exploded View...
- Page 27 Engine Part List Item Stock＃ Description Item Stock＃ Description Item Hexagon flange bolt - Small Gasket, Air intake 91101-0614-00100 22002-E180010 series 28110-E180010- Recoil starter assembly Heat shield, Carburetor 22006-E180010 00001 Gasket, Carburetor heat Handle, Rope 28123-E180010 22007-E180010 shield Hexagon flange bolt - Small Carburetor 91101-0620-00100 25300-E180502...
- Page 28 TWO (2) YEARS LIMITED WARRANTY PowerSmart is committed to building tools that are dependable for years. Our warranties are consistent with our ® commitment and dedication to quality. TWO (2) YEARS LIMITED WARRANTY OF POWERSMART PRODUCTS FOR HOME USE. PowerSmart (“Seller") warrants to the original purchaser only, that all PowerSmart consumer power tools will be free from defects in material or workmanship for a period of two (2) years from date of purchase.
