INSTRUCTION MANUAL
4800W Inverter Generator
Model # HB5046C
Have product questions or need technical support? Please scan the QR code to enter our official
website and contact us!
Website: www.powersmartusa.com
Toll free: 1-872-314-0005 Mon-Fri 9-5 EST
Email: support@amerisuninc.com / support@powersmartusa.com
1
website

Advertisement

loading
Need help?

Need help?

Do you have a question about the HB5046C and is the answer not in the manual?

Questions and answers

Related Manuals for Power smart HB5046C

Summary of Contents for Power smart HB5046C

  • Page 1 INSTRUCTION MANUAL 4800W Inverter Generator Model # HB5046C Have product questions or need technical support? Please scan the QR code to enter our official website and contact us! Website: www.powersmartusa.com Toll free: 1-872-314-0005 Mon-Fri 9-5 EST Email: support@amerisuninc.com / support@powersmartusa.com...
  • Page 3 GENERATOR OPERATION ............................15 MAINTENANCE ................................18 TROUBLESHOOTING ..............................22 EXPLODED VIEW & PARTS LIST ..........................24 WARRANTY .................................. 28 TECHNICAL DATA 4800W inverter generator Model#HB5046C Engine type: 4 stroke, OHV, single cylinder with forced air-cooling system Start type: Manual Phase:...
  • Page 4 INTRODUCTION Thank You for Purchasing a PowerSmart® Product. This manual provides information regarding the safe operation and maintenance of this product. Every effort has been made to ensure the accuracy of the information in this manual. PowerSmart® reserves the right to change this product and specifications at any time without prior notice.
  • Page 5 GENERAL SAFETY RULES DANGER: CARBON MONOXIDE Using a generator indoors CAN KILL YOU IN MINUTES. Generator exhaust contains carbon monoxide (CO). This is a poison gas you cannot see or smell. If you can smell the generator exhaust, you are breathing CO.
  • Page 6 ● Allow generator to cool down after use before touching engine or areas of the generator that become hot during use. CAUTION: Misuse of this generator can damage it or shorten its life. ● Only use generator for its intended purposes. ●...
  • Page 7 SYMBOLS Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the product better and safer. SYMBOL NAME DESIGNATION/EXPLANATION Volts Voltage Amperes Current Hertz Frequency (cycles per second)
  • Page 8 KNOWING YOUR INVERTER GENERATOR Use the illustrations below to become familiar with the locations and functions of the various components and controls of this generator. Fuel tank cap Control panel Recoil starter Carrying handle Carrying handle Oil maintenance cover Spark plug&air filter Fuel tap Muffler exhaust exit maintenance cover...
  • Page 9 CO Alarm Light(Red) When the concentration of CO exceeds the standard, the CO alarm light will turn on Red and the generator stops soon. CO Failure Light(Yellow) When the CO sensor is broken, the CO failure light will be on Yellow. MULTI-FUNCTION METER Load Indicator The load indicator on the left side of the meter shows the loaded electric devices load percent.
  • Page 10 Oil Warning Light (Yellow) The low oil level alarm system is designed to prevent engine damage due to insufficient oil in the crankcase. The low oil level alarm system automatically shuts down the engine before the engine oil in the crankshaft box is lowered to safety (the generator engine switch remains “ON”).
  • Page 11 When the gasoline engine starts up warmly, the starting switch is rotated to put the starting button in the "ON" position. Ground Terminal DANGER: Failure to properly ground the generator can result in electric shock. The ground terminal is connected to the ground wire to prevent electric shock. The generator must be properly connected to an appropriate ground.
  • Page 12 GENERATOR PREPARATION The following section describes steps necessary to prepare the generator for use. If after reading this section, you are unsure about how to perform any of the steps please call (872) 314-0005 Mon-Fri 9-5 EST for customer service. Failure to perform these steps properly can damage the generator or shorten its lifespan. Unpacking Unpack the generator and all its parts.
  • Page 13 tip the generating set during operation. Use generating set only for intended uses. If you have questions about intended use, ask your local dealer. Engine oil check WARNING: This engine is not filed with oil before send out to the factory. User must add the proper amount of oil before operating the generator for the first time.
  • Page 14 Generator Fuel Check WARNING: This generator may emit highly flammable and explosive gasoline vapors, which can cause severe burns or even death if ignited. A nearby open flame can lead to explosion even if not directly in contact with gasoline! ●...
  • Page 15 The connected electrical equipment must not exceed the maximum limit of the generator. Please refer to the specification table for details. NOTE: After completing the above preparation, the generator is ready to be started. GENERATOR OPERATION WARNING: It is prohibited to start or close the generating set when the output terminal of generating set is connected to an electric device is in “ON”...
  • Page 16 ● Allow the engine to stabilize and warm up for a few minutes after starting. ● Connect and start the electric devices. ● Turn off all electric devices and disconnect them from the generating set. DANGER: If connected devices overheat, turn them off and disconnect them from generating set. Electrical Shock To reduce the risk of electrical shock, DO NOT use electrical cords that are worn, frayed, bare or otherwise damaged.
  • Page 17 AC application 1. Start the engine, make sure the AC output light (green) is on. 2. Turn off the power supply switch and plug the device into the generator's output socket. NOTE: In order to obtain the best operation effect and the maximum service life of the generator, the new generator should run for at least 20 hours under 50% load, so that the engine performance can be optimized.
  • Page 18 MAINTENANCE The purpose of maintenance and periodic maintenance is to keep the generator in the best operating condition. WARNING: Improper maintenance or failure correct a problem before operation can cause a malfunction and result in property damage, serious injury or DEATH. lease use our original spare parts or the same quality parts when replacing damaged parts.Improper maintenance will void your warranty.
  • Page 19 every 10 hours; If necessary, change the air filter element every 25 hours. ● If maintenance period and the exact time(hour), the one which comes first should govern. ● If you have missed the scheduled time to maintain your engine, do it as soon as possible. Generator Maintenance WARNING: Never clean the generator when it is running! Never use water to clean the generating set.
  • Page 20 need to be maintained more frequently. 1. Loosen the cover screw and remove the appearance cover. 2. Loose the filter fix clamp and remove the cover of the air filter. 3. Remove the foam filter element. 4. Wash in liquid detergent and warm water. 5.
  • Page 21 Fuel Tank Filter Maintenance WARNING:Never use the gasoline while smoking or in the vicinity of an open flame. 1. Remove the fuel tank cap and filter. 2. Clean the filter with gasoline. 3. Wipe the filter and install it. 4. Install the fuel tank cap. NOTE: Be sure the fuel tank cap is tightened securely.
  • Page 22 TROUBLESHOOTING Failure Trouble Solution 1. Rotate the fuel tap to “START” position. 2. Fill fuel tank per instructions in this manual. 3. Check oil level. Add recommended oil if the oil level is low. 1. Fuel tap is in “OFF” position. This engine is equipped with a low oil sensor.
  • Page 23 WIRING DIAGRAM...
  • Page 24 EXPLODED VIEW & PARTS LIST Generator Exploded View...
  • Page 25 Generator Part List Item Stock＃ Description Item Stock＃ Description 41410-G30B501-H0400 Baseplate Assembly 25214-G290503-00000 Gauge Cover 92318-G290503-00000 Square Nut 25550-G240010-00000 Spill Valve 92319-G290502-00000 Clip-on Nut 25580-G370001-00000 Spill Valve Mounting Plate 41410-G30B502-H0200 Baseplate Assembly 25501-G79B501-00000 Steam-hose 44220-G660501-00000 Wheel Assembly 25134-G30B501-00000 Fuel Line Protective Sleeve 93120-G050010-00000 Fuel Tank Gasket 25190-G290032-00000...
  • Page 26 Engine Exploded View...
  • Page 27 Generator Part List Item Stock＃ Description Item Stock＃ Description Spring-type straight pin - 13310-E200010-00000 92403-E010010-00000 Flywheel nut Coiled, Standard duty 94100-6205-00000 Deep groove bearings 33330-G300010-00000 Magneto rotor assembly 93116-E010010-00000 Deep groove bearings 26201-E200010-00000 Cooling fan Hexagon flange bolt - Small 91709-E010010-00000 Oil drain bolt 91101-0616-00100...
  • Page 28 TWO (2) YEARS LIMITED WARRANTY PowerSmart is committed to building tools that are dependable for years. Our warranties are consistent with our ® commitment and dedication to quality. TWO (2) YEARS LIMITED WARRANTY OF POWERSMART PRODUCTS FOR HOME USE. PowerSmart (“Seller") warrants to the original purchaser only, that all PowerSmart consumer power tools will be free from defects in material or workmanship for a period of two (2) years from date of purchase.
