Summary of Contents for Cooke & Lewis CLHB 30 NE

  • Page 1 CLHB 30 NE- 04073826 CLHB 31 NE- 04073833 User and maintenance manual...
  • Page 3 R = Min. 6,5 mm Max. 8 mm Min. 50 mm R = 11,5 mm 483 mm 490 mm 560 mm R = 11,5 mm 6 mm R = Min. 6,5 mm Max. 8 mm R = Min. 6,5 mm Max.
  • Page 4 Min. 10 cm Min. 5 mm Min. 5 mm Min. 3 cm Max. 6 cm...
  • Page 5: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS YOUR SAFETY AND THAT OF OTHERS IS VERY IMPORTANT This manual and the appliance itself provide important safety messages, to be read and always observed. This manual and the appliance itself provide important safety messages, to be read and observed at all times. This is the danger symbol, regarding safety, warning of potential risks to users and others.
  • Page 6: Safeguarding The Environment

    SAFEGUARDING THE ENVIRONMENT Disposal of packing The packing material is 100% recyclable and marked with the recycling symbol ( ). The various parts of the packing must not be dispersed in the environment, but disposed of in compliance with local regulations. Disposal This appliance is marked in conformity with European Directive 2002/96/EC on Waste Electrical and Electronic Equipment (WEEE).
  • Page 7: Recommended Pot Bottom Widths

    RECOMMENDED POT BOTTOM WIDTHS Ø Ø Ø Ø 17 cm 28 cm 12 cm 18 cm 28 cm 18 cm Ø Ø Ø Ø 21 cm 14.5 cm 10 cm 14.5 cm 15 cm 21 cm INSTALLATION After unpacking the product, check for any damage during transport. In case of problems, contact the dealer or the After- Sales Service.
  • Page 8: Electrical Connection

    ELECTRICAL CONNECTION Disconnect the appliance from the power supply. WARNING Installation must be carried out by qualified personnel who know the current safety and installation regulations. The manufacturer declines all liability for injury to persons or animals and for damage to property resulting from failure to observe the regulations provided in this chapter.
  • Page 9 INSTRUCTIONS FOR USE Control Panel Description Control panel Timer On/Off Control panel lock the symbols are not active! To select the desired functions, touch the areas Cooking zone controls and corresponding display below. Switching the hob ON/OFF To switch the hob on, press the button for approx.
  • Page 10: Minute Minder

    Timer The timer can be used to set cooking time for a maximum of 99 minutes (1 hour and 39 minutes) for one cooking zone only. Select the cooking zone to be used with the timer (an illuminated dot appears to the bottom right hand side of the heat setting indicator on the display), then set the desired cooking time using the buttons “+”...
  • Page 11: Troubleshooting Guide

    TROUBLESHOOTING GUIDE • Read and follow the instructions given in the section “Instructions for use”. • Make sure there is not a power outage. • Dry the hob thoroughly after cleaning it. • If, when the hob is switched on, alphanumeric codes appear on the display, consult the following table for instructions.
  • Page 12: Power Level Table

    POWER LEVEL TABLE Power level Type of cooking Level use (indicating cooking experience and habits) Ideal for rapidly increasing the temperature of food to fast Max. power Boost Fast heating boiling in the case of water or rapidly heating cooking liquids Ideal for browning, starting to cook, frying deep frozen Frying - boiling products, fast boiling...
  • Page 14 B&Q House Chestnut Avenue Chandlers Ford SO53 3LE United Kingdom 09/11 5019 619 02040...
