URBAN OUTFITTERS SPIRAL CONVERTIBLE HOOK KNOB Assembly Instructions

SPIRAL CONVERTIBLE HOOK / KNOB
Assembly Instructions
TOOLS REQUIRED BUT NOT INCLUDED:
Drill, Phillips head screwdriver driver, Pencil
WARNINGS:
Do not throw away packing materials and carton until after assembly.
Ensure all parts are present prior to assembly.
Contact customer service immediately if parts are missing.
Assemble all parts on a clean smooth surface.
CARE INSTRUCTIONS:
Avoid direct exposure to sunlight.
Do not place over heat or air conditioning vents.
Adjust levelers so that the furniture sits flat on uneven floors.
Blot spills with a clean white cloth, do not
Do not use harsh chemicals.
Before cleaning any part test a small spot in a hidden
You may need to re-tighten all bolts after initial use.
PARTS INCLUDED:
(A) Hook / Knob
x1
(D) Wall Anchor (for hook installation)
[0.35"Ø x 1.38" L]
or
[9Ø x 35 mm]
x1
10.08.2024
rub.
area.
(B) Screw (for knob installation)
[0.16"Ø x 1.6" L]
[4mm Ø, 40mm L]
EXCLUSIVE AND CONFIDENTIAL PROPERTY OF URBAN OUTFITTERS, INC.© 2017 UO,
Inc. All rights reserved, including all applicable copyright, design and patent rights.
Any unauthorized reproduction, adaptation, distribution or other infringement will be prosecuted.
(C) Double sided screw (for hook installation)
[0.16"Ø x 1" L Sharp / .6 Dull; 1.6" over-all]
or
[4mm Ø, 24 mm L Sharp / 16 Dull; 40mm over-all]
x1
Over-all
Sharp
Dull
or
x1
Page 1 of 3
