Cordless Rivet Nut Setter
This machine is a dedicated tool for blind rivet nut for professional use.
This machine is a dedicated tool for blind rivet nut for professional use.
Thank you for purchasing the LOBSTER brand cordless rivet nut setter.
• Before using this machine, thoroughly read this instruction manual to ensure proper operation.
• After reading this instruction manual, please save these instructions.
• When this machine becomes inoperable, refer to "Troubleshooting
• Note that the contents of this manual are subject to change without prior notice for improvement.
• Unauthorized publication, duplication, and translation of this instruction manual, in part or in whole,
is prohibited.
Call center
Tel: +81-72-980-1111 Fax: +81-72-980-1166
12-8 Shijo-cho, Higashi-Osaka City, Osaka
579-8053, Japan
N1B1
Instruction Manual
Original Instructions

Table of Contents

Introduction  ...........................2
........................12
........................16
How to Order Parts ..................33
Parts Table  ...........................33
(page
31)."
Website https://www.lobtex.co.jp/
..................3
............10
............13
............14
...............24
............29
..................31
No .NEN1B1SM2A50
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the N1B1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for LOBSTER N1B1

  • Page 1: Table Of Contents

    This machine is a dedicated tool for blind rivet nut for professional use. This machine is a dedicated tool for blind rivet nut for professional use. Thank you for purchasing the LOBSTER brand cordless rivet nut setter. • Before using this machine, thoroughly read this instruction manual to ensure proper operation.
  • Page 2: Introduction

    Introduction Introduction Thank you for purchasing the LOBSTER brand Cordless Rivet Nut Setter (hereinafter abbreviated as this machine). * This machine is a special tool for blind rivet nuts that is used to caulk and fasten shrimp-marked blind rivet nuts. We do not design, manufacture, or sell products in- tended for other uses.
  • Page 3: Safety Precautions

    Safety precautions Safety precautions ◆ Before use, please read all of these “Safety precautions” carefully and fully under- stand them so that you can use the product correctly and safely. ◆ Be sure to wear safety goggles while using this machine. Failure to do so may result in an accident or injury (loss of eyesight, etc.) due to parts flying out.
  • Page 4 ⚠ WARNING 6. If the battery liquid leaks out or abnormal odor is produced, immediately stop using the machine and keep the battery away from fire. ・ Consult the store where you purchased this machine or us.Use of the battery in this condition may cause an accident or injury.
  • Page 5 ⚠ WARNING 16. Do not immerse the battery pack in conductive liquid such as water. Do not let conductive liquid such as water enter the battery pack. ・ If conductive liquid such as water enters the battery pack, short-circuiting occurs, possibly leading to heat generation, fire, or bursting.
  • Page 6 ⚠ General Power Tool Safety Warnings WARNING: Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.
  • Page 7 ⚠ General Power Tool Safety Warnings d. Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury. e. Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations.
  • Page 8 ⚠ General Power Tool Safety Warnings 5. Battery tool use and care a. Recharge only with the charger specified by the manufacturer. A charger that is suitable for one type of battery pack may create a risk of fire when used with another battery pack.
  • Page 9 ⚠ ⚠ CAUTION CAUTION 1. Carefully take care of the charger. ・ Periodically inspect the power cable of the charger, and if it is damaged, request the store where you purchased this machine or us for repair.Failure to follow this instruction may cause an electric shock or short circuit.
  • Page 10: Names Of Components

    Names of components Names of components ● Machine body Work light (LED light) Hanger Monitor SELECT BUTTON BUTTON Nose housing Lock nut STROKE LOCK FORCE Nose piece SAVE DOWN Ventilation BUTTON BUTTON Screw mandrel holes Trigger Switch Forward and reverse switch Indicator panel Battery Pack (2.5Ah/BPL-1825) Battery pack remaining indication...
  • Page 11 ● Battery pack Terminal part Claw Button ● Charger Ventilation hole LED lamps (Green, Red) Battery pack attachment part Ventilation hole ● Power cable Inlet plug Power Plug for North America For Europe...
  • Page 12: Specifications

    Specification Specification Battery capacity Standard capacity Large capacity (optional) Model number N1B1 Weight 2.6kg 2.9kg Power source 18 V d.c. Dimensions L292 × W76 × H285 mm L292 × W76 × H304 mm Tool stroke 0.1 mm ~ 10 mm (0.1mm steps Nominal output 19.6 kN...
  • Page 13: Preparation Before Use

    Preparation before Use Preparation before Use Charge the battery pack before using this machine. (Refer to page 14.) Replace the parts (nose piece, screw mandrel) in accordance with the size of the blind nut rivet in use. (Refer to page 16.) Blind rivet nut size Nose piece Screw mandrel...
  • Page 14: Procedures For Charging

    Procedures for charging Procedures for charging For charging of the battery, be sure to use the dedicated charger. Connect the power cable to the charger ( ① ) and insert the power plug into a power outlet ( ② ).When power is applied, the green LED lamp will flash slowly. Charger Receptacle LED lamps...
  • Page 15 LED lamp lighting condition Contents of indication Green Blinking Standby for charging (charger is energized) (low speed) Charging in progress Blinking Completion of practical charging (completion (high speed) of 80% charging, full charging in progress) Full charging completed (charging completed) Blinking Charging is suspended due to a temperature (low speed)...
  • Page 16: How To Adjust

    ● How to adjust ● How to adjust How to replace the screw mandrel and nose piece and How to replace the screw mandrel and nose piece and how to adjust the protrusion of the screw mandrel how to adjust the protrusion of the screw mandrel Be sure to remove the battery pack.
  • Page 17 Replace the nosepiece and screw mandrel with the size you will be using. The nosepiece lock nut is the same for all sizes. Nosepiece (Lock nut) Screw mandrel With the slide unit pulled backwards ( ① ), screw in the screw mandrel until it touches the flange ( ②...
  • Page 18 Lightly screw the nosepiece into the nose housing. Nose Housing * The screw mandrel protrusion will be adjusted and then fixed, so this is just a temporary fix for now. Adjust the position of the nosepiece so that when you insert the nut you are using (press the nut against the nosepiece), the tip of the mandrel protrudes by about one thread.
  • Page 19 How to input and adjust stroke and output How to input and adjust stroke and output The stroke and output of this machine must be adjusted according to the thickness of the nut and base material being used. Follow the procedure below to input the crimping stroke and output, and adjust so that the crimping allowance of the nut is appropriate.
  • Page 20 Regarding the stroke value to enter, check the thickness of the base material and check the appropriate caulking from the caulking table attached to the rivet nut you are using. (Example) When the crimping allowance table for the Shrimp Nut is shown on the right, if the thickness of the base material (crimping plate thickness) is 1.0 mm, the appropriate crimping allowance...
  • Page 21 Save button ( ) Press (2 seconds or more) [Configuration complete] The settings are saved to the memory number selected in . If you want to check the output again, click the Select button ( ) Please press. <Stroke display> <Force display>...
  • Page 22 Input button lock method Input button lock method This machine can lock the input buttons to prevent settings from being changed accidentally. Select button Up button STROKE LOCK FORCE Down button Save button Pull the trigger switch to turn the power on. [Button Lock] ✓...
  • Page 23 Counter display method Counter display method The machine is equipped with a counter, which can be displayed by following the steps below. ⚠ CAUTION Select button Up button STROKE If the machine is left without operation for 3 minutes, or if the battery pack is removed and the power goes out, the counter display LOCK FORCE...
  • Page 24: Procedures For Work

    ●Work procedure ●Work procedure Drill a suitable pilot hole in the base material that matches the rivet nut you will be using. Install the battery pack and pull the trigger switch to turn it on. Press the Up button ( ) and Down button ( ) to recall the previously registered memory number (0 to 9).
  • Page 25 ➡ Rivet Nut Work light (flashing) Rivet Nut Work light (lit) Before import After import ⚠ CAUTION If the forward/reverse switch is in the reverse position, the screw mandrel will not rotate even if the rivet nut is pressed against the screw mandrel. Make sure that the forward/reverse switch is in the forward position before pressing the rivet nut against it.
  • Page 26 What to do in case of an abnormality What to do in case of an abnormality <The rivet nut cannot be crimped even if the trigger switch is pulled> If the rivet nut is not properly captured, an error will be displayed on the monitor and the rivet nut will not be crimped.
  • Page 27 <The rivet nut is stuck in the screw mandrel and cannot be removed> Be sure to remove the battery pack. ⚠ CAUTION The machine may move unexpectedly and cause injury. Insert the included hex wrench (4mm across flats) into the hex hole at the rear of the machine and turn it counterclockwise to forcefully turn the screw mandrel and remove the rivet nut.
  • Page 28 Cleaning and inspection of each part Cleaning and inspection of each part <Checking the charger> After unplugging the power plug from the outlet, check that the power cable is not damaged and that there is no dirt on the terminals. <Cleaning>...
  • Page 29: List Of Error Indication

    ●List of error indication ●List of error indication Error indication Error content Cancellation method The rivet nut was not loaded Set the forward/reverse switch to reverse, No STROKE △ correctly into the machine. pull the trigger switch to reverse the screw The rivet nut is not touching mandrel, and remove the rivet nut from the ▽...
  • Page 30 Output value setting table for our rivet nuts Thread Size Our product number 415M 425M 435M 515M 525M 535M Product number (NTK) 3M15 4M20 4M25 4M35 5M30 Force No. Force No. Force No. Force No. Force No. NSK-MR Force No. NSD-MR Force No.
  • Page 31: Troubleshooting

    ●Troubleshooting Please check the items below before assuming that the product is broken. If you have checked all of them and the problem still persists, please contact us or request repairs. When making inquiries or requesting repairs, please check the items below and provide as much detail as possible about the usage conditions, symptoms, etc.
  • Page 32 ●Troubleshooting Symptoms Cause Corrective action The rivet nut does not tighten even The rivet nut does not tighten even The forward/reverse Please put the when the trigger switch is pulled. when the trigger switch is pulled. switch is in the middle forward/reverse switch position.
  • Page 33: How To Order Parts

    1pièces N1B1 M3 Screw mandrel 71779 1pièces * Please note, if parts are upgraded, the old product will be in stock for 5 years. ● Cordless rivet nut setter N1B1 Parts list Code Expendable Part name Material parts ・ Parts marked with *...
  • Page 34 ● Cordless rivet nut setter N1B1 Parts diagram ④ ⑬ ⑩ ① ⑦ ⑭ (2 pice) ② ⑧ ⑮ ③ ⑨ ⑯ ⑤ ⑪ ⑰ ⑥ ⑫ ⑱ ⑲...
