The complete WHC system (without hoses), part. no. 3446.1004, consists of:
Quantity
Position
1 1
2 2
3 2
4 1
5 2
6 6
7 3
8 2
9 1
10 1
11 4
12 3
13 1
14 4
15 2
16 1
17 1
18 1
19 3
20 2
21 1
22 1
23 2
24 1
25 1
25–a 1
26 1
27 12
28 1
29 1
30-a 4
30-b 4
30-c 4
31 4
Part no.
2214.1018 Bracket 1 for WHC system
2214.1013 Bracket 2 for WHC system
1349.265 Straight screw joint
1553.1045 Flow switch
1346.215 Nipple pipe 1/2" 100 mm
1367.078
Pipe clamp Ø21.3 single
1352.1003 Female adapter 1/2" – 2"
1341.1000 T-piece 2"
1375.1008 Air screw 1/2"
1345.1014 Nipple pipe 2" 120 mm
1344.1030 Union 1/2
1341.1001 T-piece 1/2"
1555.1009 Heating element 1000 W
1345.1013 Nipple pipe 1/2" 80 mm
1363.045 Ball valve
1372.282 Valve solenoid NC
1372.537 Coil 10 W
1375.008 Frese DN15 Needle valve
1345.1016 Nipple pipe 1/2" 30 mm
1375.147 Strainer 1/2"
1364.1010 Check valve
1341.1002 Elbow 90 deg. 1/2" – 1/2"
1352.1005 Female adapter 1/2" – 1"
1524.1003 Pump union set 1.1/2" – 1"
3448.1000 Control box, including ir33 controller (25–a)
3448.2003 Carel ir33 preprogrammed controller
1524.1103 Water pump
1424.157-E Screw M6x45
1342.1000 Hexagon nipple R3/4" – R1/2"
1364.1030 Safety valve 10 bar
1424.191-E Screw M10x25
1432.059 Nut M10
1436.035 Washer 21/10.5x2.0
1413.334 Screw M6x1 L= 12.9 DIN 912
Installation and operating manual - Sabroe WHC circulation system
8/17
Design and function
Description
011162 en 2021.05
