Delta EDF-90/135 User Manual

Manufactured in China for:
DELTA-OPTI Monika Matysiak,
60-713 Poznan, 10 Graniczna St., Poland
www.shopdelta.eu
Single motor lifting for table
User Manual EDF-90/135
Controller Interface Introduction
◆Display screen
◆ ∧ ：Up
◆ ∨ ：Down
Up or Down button operation
◆When the " ∧ " key is held down, the desktop moves up until it reaches the highest point of the desktop.
◆When the " ∨ " key is held down, the desktop runs down until it reaches the lowest point of the desktop.
◆When you press the " ∧ " or " ∨ " key, the desktop runs a short distance to achieve a short distance up or down.
◆After holding down the
position.
Reset function
∧
◆After pressing the "
∧
and press the " " + "
reaching the lowest mechanical zero point, the desktop will automatically run up to the fixed position, and the
reset process is over.
Error code table
Error code Instructions
E01 Motor not connected
E02 Over current of motor
E03 Motor hall fault
The main power supply is
E04
E05 Abnormal motor current
The motor power device
E06
is damaged
" ∧ " or " ∨ "
key for 3S, the desktop automatically starts to the highest or lowest
∨
" + " " button for 3S, wait for the controller operation indication to flash "--", then release
∨
" button to enter the reset mode, and the desktop will automatically run down. After
Press the up button or down button, if it still exists. Please check
the motor connection wire.
Press the up button or down button, if it still exists. Please replace
the motor or reduce the load.
Press the up button or down button, if it still exists. Please check
the connection or replace the motor.
After power failure cannot be eliminated, replace the power
abnormal supply.
This condition cannot be eliminated after power failure and needs
to be returned to the factory for maintenance.
This condition cannot be eliminated after power failure and needs
to be returned to the factory for maintenance.
Processing method
