GETTING STARTED
Starting Up the TZ Program
(in DOS or at DOS Prompt in Windows)
Note: Proper installation of the monitor program assumes that the proper hardware setup is complete.
Before loading the monitor program, refer to Chapter 2: "Setup and Installation" for the complete
procedure for hardware setup and applying power.
1. Ensure that the PC is powered up and is functioning properly.
2. Verify that all hardware connections and settings are correct per Chapter 2 "Setup and
Installation."
3. If using a PC, load the Z8S180 Sample Files and Monitor Source Diskette and copy the TZ.EXE
program to the PC.
4. Enter "TZ com n " (where n is the COM serial port number [1–4] of choice); press <RETURN>.
5. Connect the emulator and power supply.
7. Power up (if power has been off) or press the RESET button on the emulator.
Starting Up the TZ Program
(TZ Icon in Windows)
Note: Proper installation of the monitor program assumes that the proper hardware setup is complete.
Before loading the monitor program, refer to Chapter 2: "Setup and Installation" for the complete
procedure for hardware setup, including setting up jumpers, connecting cables, and powering up
the emulator.
1. Ensure that the PC is powered up and is functioning properly.
2. Verify that all hardware connections and settings are correct per Chapter 2 "Setup and
Installation."
3. Double-click on the TZ icon (specifying one of the COM serial ports).
4. Connect the emulater and power supply.
5. Press the RESET button on the emulator.
Opening Screen Message
If all connections to your PC are correct, you should see the following opening message at power up
or by pressing the RESET button on the board:
Zilog Z80180 Monitor Version v.m
Z80180 >
1
Where v is the current version of the debug monitor and m is the revision.
