R11e-LTE6
R11e-LTE6
is
provides high speed and reliable mobile broadband data connection.LTE data rate can achieve DL 300Mbps/DL
50Mbps.
The rich of interfaces and RF bands allow it to be widely used in CPE, industrial routers, security monitoring,
IOT and other applications.
General Features
•CA(FDD):
B1+B5
B3+B8,B3+B20,B7+B8,B7+B12,B7+B20,B8+B1,B20+B1,
B5+B2,B12+B2,B5+B3,B7+B3,B8+B3,B20+B3,B20+B7,
B1+B1,B2+B2,B3+B3,B5+B5,B7+B7,B8+B8,B12+B12
•CA(TDD):
B38+B38,B39+B39,B40+B40,B41+41,B39+B41
•LTE(FDD):
Band 1/2/3/5/7/8/12/20/25/26
•LTE(TDD):
Band 38/39/40/41
•UMTS:
Band 1/2/5/8
•E
/GPRS/GSM:
a standard Mini PCIe module,supports LTE for next-generation cellular networks and
,
B1+B8,B1+B20,B2+B5,B2+B17,B3+B5,B3+B7,
Band 2/3/5/8
Data Features
• CA FDD :
Category 6, DL 300Mbps UL 50Mbps
• CA TDD:
Category 6, DL 224Mbps UL 10Mbps
• WCDMA CS:
DL 64 kbps/UL 64 kbps
• WCDMA PS:
DL 384 kbps/UL 384 kbps
• HSPA+:
DL 21.6 Mbps/UL 5.76 Mbps
• DC-HSPA+:
DL 42 Mbps/UL 5.76 Mbps
• GPRS:
DL 107 kbps/UL 85.6 kbps
• E
:
DL 296 bps/UL 236.8 kbps
Advertisement
Related Manuals for MikroTik R11e-LTE6
Summary of Contents for MikroTik R11e-LTE6
- Page 1 R11e-LTE6 R11e-LTE6 a standard Mini PCIe module,supports LTE for next-generation cellular networks and provides high speed and reliable mobile broadband data connection.LTE data rate can achieve DL 300Mbps/DL 50Mbps. The rich of interfaces and RF bands allow it to be widely used in CPE, industrial routers, security monitoring, IOT and other applications.
- Page 2 Interfaces •MIMO: 2*2 and 4*2 DL • Mini PCIe interface •Environmental • USB 2.0 x1 Operating Temperature: -20℃～+70℃ • SIM Card x1 Extreme working temperature:-40℃～+80℃ • IIC Interface x1 Humidity: 5%～95% •Power Supply: 3.2 V to 4.2V (typical: • PCM Interface x1 3.8V) •...
- Page 3 Certific • FCC*(North Americal) • CE*(Europe) • IC*(Canada) EU Regulatory RED Declaration of Conformance Hereby, we(Mikrotikls SIA) declared that this device is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU FCC Warnning: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
