MikroTik RBD53GR-5HacD2HnD Quick Manual

EN - English - Quick Guide:
This device needs to be upgraded to RouterOS v6.49.1 or the latest version to ensure compliance with local authority regulations!
It is the end users' responsibility to follow local country regulations, including operation within legal frequency channels, output power, cabling
requirements, and Dynamic Frequency Selection (DFS) requirements. All MikroTik radio devices must be professionally installed.
This "hAP ac³ LTE6" series Quick Guide covers models: RBD53GR-5HacD2HnD&R11e-LTE6 (hAP ac³ LTE6 kit).
This is Wireless Network Device. You can find the product model name on the case label (ID).
Please visit the user manual page on
The most important technical specifications for this product can be found on the last page of this Quick Guide.
Technical specifications, brochures, and more info about products at https://mikrotik.com/products
Configuration manual for software in your language with additional information can be found at https://mt.lv/help
MikroTik devices are for professional use. If you do not have qualifications please seek a consultant https://mikrotik.com/consultants
This Device accepts input of a 24V DC power adapter, which is provided in the original packaging of this device.
First steps:
Insert micro SIM card into the slot;
After inserting the SIM card close the SIM port lid. Do not remove the card while the device is powered on;
Connect the device to the power source;
Open network connections on your PC and search for MikroTik wireless network - connect to it;
The configuration has to be done through the wireless network using a web browser or mobile app. Alternatively, you can use a WinBox configuration tool https
://mt.lv/winbox ;
Open https://192.168.88.1 in your web browser to start configuration, user name: a
Click the (Check for updates) button and update your RouterOS software to the latest version, must have a valid SIM card inserted;
Choose your country, to apply country regulation settings;
Set up your wireless network password;
Set up your router password;
Safety Information:
Before you work on any MikroTik equipment, be aware of the hazards involved with electrical circuitry, and be familiar with standard practices for preventing
accidents. The installer should be familiar with network structures, terms, and concepts.
Use only the power supply and accessories approved by the manufacturer, and which can be found in the original packaging of this product.
This equipment is to be installed by trained and qualified personnel, as per these installation instructions. The installer is responsible for making sure, that the
Installation of the equipment is compliant with local and national electrical codes. Do not attempt to disassemble, repair, or modify the device.
This product is intended to be installed indoors. Keep this product away from water, fire, humidity, or hot environments.
We cannot guarantee that no accidents or damage will occur due to the improper use of the device. Please use this product with care and operate at your own
risk!
In the case of device failure, please disconnect it from power. The fastest way to do so is by unplugging the power adapter from the power outlet.
Exposure to Radio Frequency Radiation:
uncontrolled environment. This MikroTik device should be installed and operated no closer than 20 centimeters from your body, occupational user, or the general
public.
Manufacturer: Mikrotikls SIA, Brivibas gatve 214i Riga, Latvia, LV1039.
BG - Български. Бързо ръководство:
Това устройство трябва да бъде надстроено до RouterOS v6.49.1 или най-новата версия, за да се гарантира спазването на местните
регулаторни разпоредби.
Крайните потребители са отговорни за спазването на местните разпоредби, включително работата в рамките на законни честотни канали,
извеждане на продукция изисквания за захранване, окабеляване и изисквания за динамичен избор на честота (DFS). Всички радиоустройства
на MikroTik трябва да бъдат професионално инсталиран.
Това серия "hAP ac³ LTE6" Бързо ръководство обхваща модели: RBD53GR-5HacD2HnD & R11e-LTE6 (hAP ac³ LTE6 kit).
Моля, посетете страницата с ръководството за потребителя на
Или сканирайте QR кода с мобилния си телефон.
Технически спецификации, брошури и повече информация за продуктите на https://mikrotik.com/products
Най-важните технически спецификации за този продукт могат да бъдат намерени на последната страница на това Кратко ръководство.
Ръководство за конфигуриране на софтуер на вашия език с допълнителна информация можете да намерите на https://mt.lv/help-bg
Устройствата MikroTik са за професионална употреба. Ако нямате квалификация, моля, потърсете консултант https://mikrotik.com/consultants
Това устройство приема вход на 24V DC адаптер за захранване, който се предлага в оригиналната опаковка на това устройство.
Първи стъпки:
https://mt.lv/um for the full up-to-date user manual. Or scan the QR code with your mobile phone.
This MikroTik equipment complies with the FCC, IC, and European Union radiation exposure limits set forth for an
dmin and there is no password by default;
https://mt.lv/um-bg за пълното актуализирано ръководство за употреба.
