- Page 1 Günter & Hauer EN USER MANUAL BUILT-IN OVEN EOT 1267 B / EOT 1267 W / EOT 1267 IVR...
- Page 2 Thank you for your trust and choosing GÜNTER & HAUER products! This manual was developed to facilitate the use of the product. It will help you familiarize yourself with new appliance quickly. Make sure you have received the product without any damage. If damage is detected, please contact the purchasing organization where you have bought appliance.
-
Page 3: Table Of Contents
Dear buyer! First of all, thank you for preferring and buying our product. We hope that this product, manufactured with the use of the most modern technologies, will demonstrate the best operational results and become an indispensable assistant. Please read the information in this user manual carefully for successful and safe use of the appliance. -
Page 4: Product Overview
4) Turbo fan. 5) Side racks. 6) Іnner glass. 7) Oven door. 8) Door handle. Technical Specifications EOT 1267 B / EOT 1267 W / EOT 1267 IVR MODEL NAME Oven type Electric Top heating element 900 W Bottom heating element... -
Page 5: Safety Instructions
SAFETY INSTRUCTIONS The built-in electric oven is made for home use. Please do not use it for other purposes. Instullation This appliance must be installed by a qualified technician in accordance with the manufacturer instructions and relevant safety standards. This appliance is heavy. Be careful when moving it. Please dispose of all packaging and protective films of the appliance before first use. -
Page 6: Installation
Do not use aluminum foil to cover the grill pan or place items wrapped in foil under the grill, as this may cause a fire hazard. High reflectivity can also damage the oven components. After using the oven, wipe off any steam that may have formed due to the high temperature. -
Page 7: Installation Instructions
Installation instructions During installation, make sure that the oven is not connected to the network! The oven must be installed by an authorized technician only. • The dimensions and materials of the cabinet must be correct. They must be resistant to •... -
Page 8: Electrical Safety Information
Electrical safety information Connection to the main electrical network must be carried out only by an authorized electrician in accordance with current regulations. WARNING! This appliance must be properly grounded. Check that the power level of the mains and outlets corresponds to the maximum power of the oven indicated in the technical specification and has reliable, safe isolation. -
Page 9: Touch Buttons
If you have any doubts, contact a qualified technician. • If the appliance plug and outlet are not compatible, a qualified technician must replace the outlet with a suitable model. Technician must also make sure that the cross-section of the cable corresponds to the power consumption of the oven. The use of adapters, multi plugs and/or extension cords is not allowed. -
Page 10: Top Heating Element
TYPES OF PROGRAMS DEFROST FUNCTION In this mode, only the fan is used to circulate air in the oven at room temperature. The heating elements are not used. If possible, turn the products so that they defrost evenly. It is recommended to put defrosting products on the middle level. -
Page 11: Grill Function
CLASSIC HEATING + CONVECTION In this mode, the bottom and the top heating elements and the fan operate at the same time. The fan ensures even distribution of air throughout the oven space. This mode is suitable for cooking any kind of baking, drying vegetables and fruits. -
Page 12: Keep Warm Function
GRILL + CONVECTION FUNCTION When this mode is selected, the grill and the fan will be activated to circulate the air inside the oven. When roasting meat, this mode will keep the top part of the dish fresh, while the circulating hot air will cook it inside. This mode can also be used to roast meat and vegetables without the need to turn the food frequently. -
Page 13: Cooking Recommendations
COOKING RECOMMENDATIONS The parameters of the cooking time of food products may be different and depend on the composition, variety of ingredients and liquid content of specific dishes. We recommend to write down the settings you use during your first experiment with cooking or roasting certain foods in order to gain the necessary experience for preparing the same dishes in the future. -
Page 15: Oven Use
OVEN USE КОРИСТУВАННЯ ДУХОВКОЮ THE OVEN USE 1. ON/OFF THE OVEN 3. COOKING FUNCTION SELECTION You can use the function buttons The button turns the oven on or to navigate through off. It is independent of the «key lock». the menu. In OFF mode, the display is completely blank. - Page 16 5. DEFAULT COOKING TEMPERATURE 7. PAUSE, CHANGE OR STOP FUNCTION COOKING It is possible to program a default When the cooking process is temperature for some functions. To do stopped, «STOP» symbol appears. If this, when setting the cooking you tap on it during cooking process, temperature, touch and hold for 5 the symbol...
-
Page 17: Semi-Automatic Cooking
8. AUTOMATIC COOKING 4. To start cooking tap on After selecting the automatic 8.2. AUTOMATIC COOKING cooking tools, function and cooking (DELAYED START) temperature and/or temperature This mode allows you to set the probe, tap on to start cooking. start time and end time of cooking. 8.1. - Page 18 5. Set the cooking end time by using 3. Tap on . The two right-hand buttons . The symbol timer numbers on the «Timer / will appear on the display, Temperature probe» display will flash indicating the activation of the to show the current temperature for «DELAY START»...
- Page 19 Residual heat indicator When the set temperature is If the temperature in the oven reached, the symbol will disappear after a while and a warning cavity is above 60°C and there is no sound will be emitted. cooking process, the corresponding symbol will flash on the display and Key lock «HOT»...
- Page 20 Indications of errors If error mode is triggered, it may interfere with normal operation. When the appliance is in standby mode, the display shows an error code. This code will remain on the oven display until you tap on the button .
- Page 21 The cooling fan starts and stops its Cooling fan operation together with the If the temperature in the oven thermostat located inside the oven. exceeds 85°C, the cooling fan activated. As the cooling fan operates according to the temperature, even if The ventilation system prevents the the oven is switched off, the fan will external surface of the built-in oven...
-
Page 22: Cooking Guidelines
Cooking guidelines Oven tray position, 1-5 Cooking time, min. Thermostat Dishes Food position, °C top+bottom top+bottom heat top+bottom top+bottom heat +convection +convection heating heating 24-26 cm of Cake baking pan 18-22 cm of Cake in form, 5 pers. baking pan Biscuits, 12 Large oven pers. -
Page 23: Cleaning And Maintenance
Cleaning and Maintenance Oven cleaning 1. Before cleaning the oven, disconnect it from the power supply. If the oven is heated, wait for it to cool down. 2. Do not use abrasive cleaners to clean enamel, ceramics or painted surfaces. Use only creams or liquid detergents that do not contain abrasive substances. - Page 24 Do not perform this process while the oven is heated. Be careful, do not damage the glass during removing and cleaning. Do not clean the side wire racks during operation or in a warm state. When removing the side racks, follow the instructions in the figure below. When cleaning is complete, reverse the steps to install the side racks.
-
Page 25: Information About Transportation
- take out faild lamp bulb; - insert a new lamp bulb; - put the glass shade back in its place; - connect the appliance to the electrical network. Information about transportation During transportation, the oven must be in an upright position. Do not place anything on top of it. -
Page 26: Solving Issues
Solving issues Please perform the following steps before calling an authorized service center. The oven does not work The plug of your oven may be connected to an ungrounded outlet; the fuse may has tripped; the timer may not be configured in models where there is a timer. - Page 27 Günter & Hauer www.gunter-hauer.eu info@gunter-hauer.de...
