- Page 1 TL70 Basic Modular Tower Light Product Manual Original Instructions p/n: 233350 Rev. D 20-Feb-25 © Banner Engineering Corp. All rights reserved. www.bannerengineering.com...
-
Page 2: Table Of Contents
TL70 Basic Modular Tower Light Product Manual Contents Chapter 1 Features........................3 Models ........................................... 3 Chapter 2 Assembling the Modules ..................5 Chapter 3 Wiring........................6 Flash/Pulse Control ....................................... 6 Chapter 4 Specifications ......................7 FCC Part 15 Class B for Unintentional Radiators............................8 Industry Canada ICES-003(B).................................. -
Page 3: Chapter 1 Features
Chapter 1 Features Banner's TL70 Basic Tower Light is a 70 mm, modular LED indicator with bright and uniform light. The modularity gives the user flexibility to customize tower lights as needed and change positions in the field. The TL70 is also available preassembled for easy installation. - Page 4 TL70 Basic Modular Tower Light Product Manual Features Continued from page 3 Part Number Model 814502 TL70B-GYRAQ 814503 TL70B-BGYRQ 814504 TL70B-BGYRAQ 814505 TL70B-WBGYRQ page 4 of 16 © Banner Engineering Corp. All rights reserved. 20-Feb-25 www.bannerengineering.com...
-
Page 5: Chapter 2 Assembling The Modules
TL70 Basic Modular Tower Light Product Manual Chapter Contents Chapter 2 Assembling the Modules To assemble the modules: Align the notches on each module and press together. Rotate the top module clockwise to lock into place (notches shown in the locked position). -
Page 6: Chapter 3 Wiring
TL70 Basic Modular Tower Light Product Manual Chapter Contents Flash/Pulse Control ......................................6 Chapter 3 Wiring Diagram 5-Pin Pinout 8-Pin Pinout Position 5 Position 4 Position 3 1 = White (Position 3) 2 = Brown (Position 2) 1 = Brown (Position 2) -
Page 7: Chapter 4 Specifications
TL70 Basic Modular Tower Light Product Manual Chapter Contents FCC Part 15 Class B for Unintentional Radiators ..............................8 Industry Canada ICES-003(B)....................................8 Dimensions........................................... 8 Chapter 4 Specifications Supply Voltage and Current Indicator Characteristics 12 V DC to 30 V DC Color Lumen Dominant Wavelength Maximum Current (mA) -
Page 8: Fcc Part 15 Class B For Unintentional Radiators
TL70 Basic Modular Tower Light Product Manual Specifications FCC Part 15 Class B for Unintentional Radiators (Part 15.105(b)) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. - Page 9 Specifications TL70 Basic Modular Tower Light Product Manual Continued from page 8 Model Height (H) 1 light module, 1 audible module 144.3 mm (5.68 in) 2 light modules 137.3 mm (5.41 in) 2 light modules, 1 audible module 194 mm (7.64 in) 3 light modules 187 mm (7.36 in)
-
Page 10: Chapter 5 Accessories
TL70 Basic Modular Tower Light Product Manual Chapter Contents Cordsets ..........................................10 Mounting Brackets.......................................11 Elevated Mount System ..................................... 12 LMB Sealed Right Angle Bracket ..................................13 Top Replacement Cover..................................... 14 Chapter 5 Accessories Cordsets 5-Pin Single-Ended M12 Female Cordsets Model ... -
Page 11: Mounting Brackets
Accessories TL70 Basic Modular Tower Light Product Manual 8-Pin Single-Ended M12 Female Cordsets Model Length Style Dimension Pinout (Female) MQDC1-803 1 m (3.2 ft) 44 Typ. MQDC1-806 2 m (6.5 ft) MQDC1-815 5 m (16.4 ft) Straight M12 x 1 MQDC1-830 9 m (29.5 ft) ø 14.5 MQDC1-850 15 m (49.2 ft) 32 Typ. -
Page 12: Elevated Mount System
TL70 Basic Modular Tower Light Product Manual Accessories SMB30MM • 12-gauge stainless steel bracket with curved mounting slots for versatile orientation • Clearance for M6 (¼ in) hardware • Mounting hole for 30 mm sensor Hole center spacing: A = 51, A to B = 25.4 Hole size: A = 42.6 × 7, B = ø 6.4, C = ø 30.1 SMBAMS30P •... -
Page 13: Lmb Sealed Right Angle Bracket
Accessories TL70 Basic Modular Tower Light Product Manual Continued from page 12 Model Features Components Polished 304 Stainless Black Anodized Clear Anodized • Elevated-use stand-off pipe (½ in. NPSM/DN15) Steel Aluminum Aluminum • Polished 304 stainless steel, black anodized SOP-E12-150SS... -
Page 14: Top Replacement Cover
TL70 Basic Modular Tower Light Product Manual Accessories Top Replacement Cover C-TL70 Replacement Top Cover • Black polycarbonate housing • Fits TL70 tower lights • IP65 rated page 14 of 16 © Banner Engineering Corp. All rights reserved. 20-Feb-25 www.bannerengineering.com... -
Page 15: Chapter 6 Product Support And Maintenance
Engineering Corp. will repair or replace, free of charge, any product of its manufacture which, at the time it is returned to the factory, is found to have been defective during the warranty period. This warranty does not cover damage or liability for misuse, abuse, or the improper application or installation of the Banner product. - Page 16 LinkedIn X (formerly Twitter) Facebook © 2025. All rights reserved. www.bannerengineering.com...
