New Classic Furniture LYNDHURST B493-070 Assembly Instructions

Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small
parts, which may have come loose inside the carton during shipment. Identify and count all items and
compare with the PARTS LIST and/or HARDWARE LIST shown below.
Caution: Please read the instructions thoroughly before assembly.
1. We recommend that you assemble this product with the assistance of another person; this will make the
assembly easier, and will help eliminate damage to the product or injury to persons during assembly.
2. Please do not over tighten screws or bolts until the assembly is completed.
3. Please put all parts on a non-abrasive floor before assembly, and follow the assembly steps to assemble your
newly purchased product correctly and efficently.
PARTS LIST
NO: COMPONENT
A CHEST
FRONT LEG
B
RIGHT SIDE FACING
C
(RSF) BACK LEG
LEFT SIDE FACING
D
(LSF) BACK LEG
E
ANTI-TIPPING KIT
STEP 1 Locate the leg box in the bottom drawer.
Assembly Instructions
ITEM: B493-070 LYNDHURST CHEST
SKETCH Q'TY
1 PC
2 PCS
1 PC
1 PC
1 SET
A
MADE IN VIETNAM
HARDWARE LIST
NO: COMPONENT
1 ALLEN KEY
2 BOLT 5/16"*1-3/4"L
3
LOCK WASHER 5/16"
4
SKETCH Q'TY
1 PC
4 PCS
4 PCS
4 PCS
PAGE : 1 OF 3
