New Classic Furniture KAILANI B4378-315 Assembly Instructions

Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small parts, which may have
come loose inside the carton during shipment. Identify and count all items and compare with the parts list and/or hardware list
shown below.
PARTS LIST
ITEM DESCRIPTION
1 HEADBOARD
2 HEADBOARD LEG
(RSF)
3 HEADBOARD LEG
(LSF)
FOOTBOARD
4
5 FOOTBOARD LEG
6 SIDE RAIL
7 SLAT
SLAT SUPPORT LEG
8
W/ADJUSTABLE FFET
9 HEADBOARD
SUPPORT RAIL
IMPORTANT NOTE :
ASSEMBLY INSTRUCTIONS
KAILANI QUEEN BED
B4378-315 KAILANI 5/0 Q HB,FB & SLATS
B4378-335 KAILANI 6/6-5/0 Q/EK SIDE RAILS SLATS
SKETCH QTY
1PC
1PC
1PC
1PC
2PCS
2PCS
4PCS
4PCS
1PC
HARDWARE LIST
ITEM DESCRIPTION
A JCBB SCREW -
M8 x 25/32"
JCBC SCREW -
B
M6 x 19/32"
JCBC SCREW -
C
M6 x 1 3/8"
JCBC SCREW -
D
M6 x 1 9/16"
SPRING WASHER -
E
M6 x 15/32"
FLAT WASHER -
F
M6 x 3/4"
G CSK C/B SCREW -
M4 x 1 17/64"
H
M4 ALLEN KEY (2 9/16")
I
M5 ALLEN KEY (2 9/16")
SKETCH QTY
8PCS
6PCS
6PCS
6PCS
8PCS
8PCS
8PCS
1PC
1PC
PAGE 1 OF 3
