NETBOX
Installation Guide
1.
Place the NETBOX Point Duplex into the
pre-cut 120mm grommet hole
3.
Ensure the NETclips are pushed until the end.
Secure cable and insert into power source
or data outlet if required.
Point Duplex
2.
Secure the NETBOX Point Duplex into position
by inserting the 2 NETClips.
4.
NETBOX Point Duplex is ready to use
A. & H. Meyer Sdn Bhd (528797-M)
No. 3, Jalan Astaka U8/84
Section U8, Bukit Jelutong
40150 Shah Alam, Selangor
Malaysia
T: +60 3 7845 7277
W: www.ah-meyer.com.my
E: sales@ah-meyer.com.my
Secure cable and insert into power source
or data outlet if required. NETBOX Point Duplexvv
is ready to use
For dimensions
Please refer to the back.
Advertisement
Related Manuals for LEGRAND A.&H. Meyer NETBOX Point Duplex
Summary of Contents for LEGRAND A.&H. Meyer NETBOX Point Duplex
- Page 1 NETBOX Point Duplex A. & H. Meyer Sdn Bhd (528797-M) No. 3, Jalan Astaka U8/84 Section U8, Bukit Jelutong 40150 Shah Alam, Selangor Malaysia T: +60 3 7845 7277 W: www.ah-meyer.com.my E: sales@ah-meyer.com.my Installation Guide Place the NETBOX Point Duplex into the Secure the NETBOX Point Duplex into position pre-cut 120mm grommet hole by inserting the 2 NETClips.
- Page 2 NETBOX Point Duplex A. & H. Meyer Sdn Bhd (528797-M) No. 3, Jalan Astaka U8/84 Section U8, Bukit Jelutong 40150 Shah Alam, Selangor Malaysia T: +60 3 7845 7277 W: www.ah-meyer.com.my E: sales@ah-meyer.com.my Dimensions 140mm 67.4mm Cut Out For Installation Guide Please refer to the back.
