- Page 1 AFFICHEURS DÉPORTÉS REMOTE INTERFACES ATyS D10 & D20 Notice d’utilisation - Operating instructions MAKE YOUR BUSINESS SAFE SOCOMEC GROUP SWITCHING PROTECTION & UPS...
-
Page 2: Table Of Contents
PRÉSENTATION GÉNÉRALE ATyS D10 et D20 _______3 INSTALLATION ATyS D10 et D20 ___________________4 Montage _______________________________________4 Raccordements _________________________________4 Caractéristiques_________________________________4 UTILISATION ATyS D10 ___________________________5 Affichage_______________________________________5 UTILISATION ATyS D20 ___________________________6 Affichage_______________________________________6 Clavier _________________________________________7 Version logiciel __________________________________7 Programmation _________________________________8 Exploitation____________________________________18 Fonctionnement________________________________20 Visualisation ___________________________________20 GENERAL PRESENTATION ATyS D10 & D20________23 INSTALLATION ATyS D10 &... -
Page 3: Remote Interfaces
Remote interfaces GENERAL PRESENTATION ATyS D10 & D20 ATyS D10 and D20 models are remote interfaces designed for easy integration on front panels. They can be connected to ATyS 6e, 6m and C30 products to allow remote access to display or control features. -
Page 4: Installation Atys D10 & D20
4 N.m ATyS D10/D20 Characteristics > IP21 standard IP54 using gasket > Operation • Temperature: -10 to + 55 °C • hygrometry: 80 % humidity at 55 °C 95 % humidity at 40 °C SOCOMEC - Réf.: 532 212 A... -
Page 5: Operation Atys D10
Remote interfaces OPERATION ATyS D10 Display ATyS D10 allows remote display of transfer system positions, sources availability and operational mode. Programming and operations remain available directly on master product (ATyS 6e, 6m or C30). • ATyS Product faulty, transfer error •... -
Page 6: Operation Atys D20
Transfer system in in position 2 position 1 Transfer system in position 0 Transfer system in automatic mode Control mode active Test mode active Programming mode active * only on ATyS 6e and 6m SOCOMEC - Réf.: 532 212 A... -
Page 7: Keypad
Access to AUT, Test, Direct Access to Test and Control Control and Prog modes functionalities or navigation validation Software version Software version of the master product is displayed immediately after ATyS 6e, 6m or C30 power on. SOCOMEC - Réf.: 532 212 A... -
Page 8: Programming
• Step 1: Press the “ESC” push button when not entering any value, to come back to main programming menu • Step 2: Press again on “ESC” push button to exit programming New Active mode (Automatic or Manual) depends on information from the master device (ATyS 6e, 6m ou C30) SOCOMEC - Réf.: 532 212 A... - Page 9 In case of parameter displayed on 2 lines, press “validation” push button after first line modification to access next one “ESC” push button allows to come back to main menu or to cancel the modification SOCOMEC - Réf.: 532 212 A...
- Page 10 ATyS Remote interfaces Display OPERATION Keypad Software version ATyS D20 Programming Control and Test modes Operational sequences Visualisation Programming ARCHITECTURE OF THE PROGRAMMING MENU SOCOMEC - Réf.: 532 212 A...
- Page 11 Remote interfaces ATyS OPERATION SOCOMEC - Réf.: 532 212 A...
- Page 12 Number of permutation counter Reset Yes, No Programming code modification 0001 to 9999 1000 Possible to change the code only on AtyS 6m ** only on ATyS 6e & 6m *** only on ATyS C30. SOCOMEC - Réf.: 532 212 A...
- Page 13 Network 2 under frequency threshold hysteresis 80.5 - 99.5 % 97 % (> uF) Values defined are % of nominal values. Hysteresis thresholds must be programmed according to over and under frequency thresholds (respectively under & above). SOCOMEC - Réf.: 532 212 A...
- Page 14 Only on ATyS 6e or 6m in case of optional communication module. Denomination Setting range Default values Device address 1 to 247 Communication speed 2400, 4800, 9600, 9600 19200, 38400 StoP Stop bit 1, 2 Parity bit No, Odd, Even SOCOMEC - Réf.: 532 212 A...
- Page 15 (Ft2 ou S1A) • Step 2: press “top” and “bottom” push buttons to modify the variable • Step 3: press “validation” • Step 4: press “bottom” push button to acces nO variable selection SOCOMEC - Réf.: 532 212 A...
- Page 16 Load shedding relay. LS timer corresponds to time available to disconnect the shed loads. The relay is activated before permutation on standby network according to LS timer. The relay is de-activated after retransfer on mains network and LS timer countdown SOCOMEC - Réf.: 532 212 A...
- Page 17 (LS) • Step 2: press push buttons “top” and function “bottom” to modify the variable • Step 3: Press “validation” • Step 4: Press “bottom” push button to access timer value configuration timer SOCOMEC - Réf.: 532 212 A...
-
Page 18: Control And Test Modes
It is possible to test leds and LCD without entering any code by pressing directly Test on load or test off load access codes are displayed after pressing Enter the code 4000 using “left”, “right”, “top” and “bottom” push buttons Press “validation” push button to enter SOCOMEC - Réf.: 532 212 A... - Page 19 ATyS (6e, 6m ou C30) > Control or Test modes use Direct access by pressing To start a test (off load or on load) or to control the changeover switch electrically, press push buttons SOCOMEC - Réf.: 532 212 A...
-
Page 20: Operational Sequences
• Out of a permutation cycle, phase to phase voltages values. and frequency are displayed. Examples: Examples: Press “left”, “right”, “top” & “bottom” push buttons to access available screens Press “navigation” push button to navigate in visualisation, displaying all available screens SOCOMEC - Réf.: 532 212 A... - Page 21 Remote interfaces ATyS OPERATION Visualisation ARCHITECTURE OF VISUALISATION MENU **** only on AtyS 6e & 6m only U3-1 on AtyS C30 *** only on ATyS 6m **** visible if option LS selected and active SOCOMEC - Réf.: 532 212 A...
- Page 24 SOCOMEC - Ref.: 532 212 A - 02 / 05 H E A D O F F I C E S A L E S M A N A G E M E N T D I V I S I O N...
