CATALOGUE
USE - MAINTENANCE
AND SPARE PARTS
Hydraulic Demolition Breaker
MDO 1600 TS
Before carrying out any operation with or on the machine, you must
read
carefully and understand each individual instruction written in this
manual
Ne de r la n d B .V .
43014 Medesano (Parma) Italia - Strada Ferrari, 38
Phone +39 0525 - 420929 - Fax +39 0525 - 420375
http://www.socomecspa.com
E-mail: info@socomecspa.com
