- Page 1 Remote Fire Indicator FDU-80C Instruction Manual Document 53614 5/13/2013 Rev: P/N 53614:A2 ECN 13-439...
- Page 2 Fire Alarm & Emergency Communication System Limitations While a life safety system may lower insurance rates, it is not a substitute for life and property insurance! An automatic fire alarm system—typically made up of smoke (caused by escaping gas, improper storage of flammable materi- detectors, heat detectors, manual pull stations, audible warning als, etc.).
-
Page 3: Installation Precautions
HARSH™, NIS™, Notifier Integrated Systems™, and NOTI•FIRE•NET™ are all trademarks; and Acclimate® Plus, FlashScan®, NION®, NOTIFIER®, ONYX®, ONYXWorks®, UniNet®, VeriFire®, and VIEW® are all registered trademarks of Honeywell International Inc. Echelon® is a registered trademark and LonWorks™ is a trademark of Echelon Corporation. ARCNET® is a registered trademark of Datapoint Corporation. Microsoft® and Windows® are registered trademarks of the Microsoft Corporation. -
Page 4: Software Downloads
•Brief description of content you think should be improved or corrected •Your suggestion for how to correct/improve documentation Send email messages to: FireSystems.TechPubs@honeywell.com Please note this email address is for documentation feedback only. If you have any technical issues, please contact Technical Services. -
Page 5: Table Of Contents
Table of Contents Section 1: Overview........................6 1.1: Introduction..............................6 1.2: Related Documentation ..........................6 Section 2: The FDU-80C Indicator ................... 7 2.1: Compatible Panels ............................7 2.2: Features of the FDU-80C..........................7 2.3: Components ..............................8 2.4: SW1 DIP Switch Settings ..........................8 2.5: Typical Configuration ..........................10 Section 3: Mounting........................ -
Page 6: Section 1: Overview
Section 1: Overview 1.1 Introduction This document contains information for installing, programming, and operating the FDU-80C Remote Fire Indicator. 1.2 Related Documentation The following table provides a list of document sources (manuals) containing additional information regarding the fire alarm control panels and components that ACS annunciators can be connected to. The Notifier document (DOC- NOT) chart provides the current document revision. -
Page 7: Section 2: The Fdu-80C Indicator
Section 2: The FDU-80C Indicator The FDU-80C Indicator is a compact, 80-character, backlit LCD fire indicator designed for use with compatible FACPs (Fire Alarm Control Panels). It should be noted that the FDU-80C Indica- tor display will mimic the FACP display. The FDU-80C is capable of displaying English-language text of system point status including device type, independent point alarm, trouble or supervisory, zone and custom alpha labels pro- grammed into the control panel. -
Page 8: Components
The FDU-80C Indicator Components • Plug-in terminal blocks for ease of installation and service • DIP switches control piezo enable/disable, transmit/receive mode, FACP selection, function switches and key-switch enable/disable. • Up to 32 FDU-80C Indicators per FACP • Mounting options: –... - Page 9 SW1 DIP Switch Settings The FDU-80C Indicator 3 -ON = Supervision Receive/Transmit, OFF = Supervision Receive Only. • One Indicator - if a single FDU-80C is the only indicator connected to the EIA-485 loop, Switch 3 must be set to the ON position to allow the FACP to supervise the indicator. •...
-
Page 10: Typical Configuration
The FDU-80C Indicator Typical Configuration DIP switches 7 and 8: OFF (these switches are not used) 2.5 Typical Configuration The FDU-80C Indicator mimics the FACP display, has full point-display capacity and requires no programming. Note that the FACP may require programming to allow communication with the FDU-80C. -
Page 11: Section 3: Mounting
Section 3: Mounting 3.1 Indicator Preparation The FDU-80C Indicator can be surface mounted in a three-gang electrical box such as the P/N SBB-3 (2.75" depth) or semi-flush mounted in a three-gang electrical box, P/N 10103 or equiva- lent, with a minimum depth of 2-3/16". The FDU-80C Indicator can also be mounted in three gangable electrical switch boxes connected together. - Page 12 Mounting Indicator Preparation Lamp Local Test Silence Hold 3 sec. FDU-80C Trim Ring FDU-80C flange (replacement P/N 23165) 3-Gang Electrical Box P/N 10103 (semi-flush mount) 3-Gang Electrical Box P/N SBB-3 (surface mount) Three Ganged Electrical Boxes Figure 3.2 Hardware and Backboxes FDU-80C Instruction Manual —...
-
Page 13: Semi-Flush Mount Backbox
Semi-flush Mount Backbox Mounting 3.2 Semi-flush Mount Backbox 3.2.1 Mounting in SBB-3 Three Gang Electrical Box Remove the plug-in terminal blocks from the FDU-80C circuit board. Connect the EIA-485 and power wiring into the terminal block positions illustrated in Sections 4.1 and Section 4.2. Plug the terminal blocks back into the P2 and P1 connectors on the back of the indicator. -
Page 14: 2: Mounting In Three Electrical Boxes Ganged Together
Mounting Semi-flush Mount Backbox 3.2.2 Mounting in Three Electrical Boxes Ganged Together Remove the plug-in terminal blocks from the FDU-80C circuit board. Connect the EIA-485 and power wiring into the terminal block positions illustrated in Sections 4.1 and 4.2. Plug the terminal blocks back into the P2 and P1 connectors on the back of the indicator. -
Page 15: Surface Mount Backbox
Surface Mount Backbox Mounting 3.3 Surface Mount Backbox Remove the plug-in terminal blocks from the FDU-80C circuit board. Connect the EIA-485 and power wiring into the terminal block positions illustrated in Sections 4.1 and 4.2. Plug the terminal blocks back into the P2 and P1 connectors on the back of the indicator circuit board. Set DIP switch SW1 for the desired options. -
Page 16: Section 4: Electrical Connections
Section 4: Electrical Connections 4.1 Power Connections The FDU-80C Indicator can be powered by the FACP (refer to the specific technical manual for the proper connection of the FDU-80C) or from a remote UL listed, filtered power supply such as the FCPS-24S6/8C. -
Page 17: Eia-485 Connections
EIA-485 Connections Electrical Connections FDU-80C Earth Ground Option no connection -24 VDC OUT +24 VDC OUT NFS2-640/NFS-320C Figure 4.2 Power Wiring to the NFS2-640/NFS-320C FDU-80C Earth Ground Option no connection -24 VDC OUT +24 VDC OUT FCPS-24S6/8C Figure 4.3 Power Wiring to the FCPS-24S6/8C NOTE: 1. - Page 18 Electrical Connections EIA-485 Connections Refer to the following illustrations for EIA-485 connections from the FDU-80C to the FireWarden NFW2-100, NFS2-640, and NFS-320C. FDU-80C - - + + EIA-485 Out to Next Device EIA-485 Out to Next Device (or back to FACP) EIA-485 NFW2-100 Figure 4.4 EIA-485 Wiring to the NFW2-100...
-
Page 19: Section 5: Eia-485 Shield Termination
Section 5: EIA-485 Shield Termination The EIA-485 circuit must be wired using a twisted, shielded pair cable with a characteristic imped- ance of 120 ohms (+/- 20%). Do not run cable adjacent to or in the same conduit as 120 VAC ser- vice, noisy electrical circuits that are powering mechanical bells or horns, audio circuits above 25 , motor control circuits or SCR power circuits. -
Page 20: Shield In Full Conduit
EIA-485 Shield Termination Shield in Full Conduit 5.2 Shield in Full Conduit The EIA-485 line allows the FACP to communicate with the FDU-80C Indicator. The shield for the EIA-485 line must be connected to earth ground at the FACP (both exiting and entering the FACP) but must be left floating (no connection) at the indicator if it is the first or only device on the EIA-485 line. -
Page 21: Section 6: Operation
Section 6: Operation 6.1 Display Patterns The FDU-80C Indicator directly displays (mimics) the information on the FACP display with the following exceptions: • Upon Power-up, the FDU-80C may display the following message until a valid message is received from the FACP: INITIALIZING... -
Page 22: 2: Alarm
Operation LED Indicators 6.3.2 Alarm This is a red LED that turns on steady when one or more fire alarms occur. The Alarm LED turns off when the FACP Reset switch is pressed. 6.3.3 Supervisory This is a yellow LED that turns on steady when one or more supervisory conditions occur, such as a sprinkler valve tamper condition. -
Page 23: Appendix A: Ul 864 8Th Edition Applications
Appendix A: UL 864 8th Edition Applications WARNING: THE NFS-640, AFP-300/400, AND FIREWARDEN NFW-100 HAVE NOT BEEN CERTIFIED TO COMPLY WITH THE REQUIREMENTS IN THE STANDARD FOR CONTROL UNITS AND ACCESSORIES FOR FIRE ALARM SYSTEMS, UL 864 9TH EDITION. OPERATION OF THESE PRODUCTS WITH PRODUCTS TESTED FOR UL 864 9TH EDITION HAS NOT BEEN EVALUATED. -
Page 24: A.2: Eia-485 Connections
UL 864 8th Edition Applications EIA-485 Connections A.2 EIA-485 Connections EIA-485 connections to the annunciator must be power-limited and supervised. A maximum dis- tance of 6,000 feet (1829 m) @ 18 AWG (0.75mm ) twisted, shielded cable is allowed between the FACP and first FDU-80C, between each FDU-80C and return to the FACP from the last FDU-80C. -
Page 25: Index
Index Numerics FACP selection 9 Fault 21 80-character 7 FBD-1 Ferrite Core 17 FCC Part 15 requirements 17 FCPS-24S6/8C Power 17 AC loss 8 ferrite core 17 AFP-300/400 flange 13 EIA-485 24 function switches 8 Power 23 AHJ 8 alarm LED 7 grounding 11 alarm silenced LED 7 annunciator, maximum 10... - Page 26 P–W Index piezo sounder 7 power for indicator 7 power LED 7 power requirements 10 power source 16 power-limited 16 programming 7 receive only see also communication 9 receive/transmit see also communication 9 resound, piezo 7 SBB-3 backbox 11 semi-flush mounting 13 shield no conduit 19 see also EIA-485 19...
-
Page 27: Manufacturer Warranties And Limitation Of Liability
Manufacturer Warranties and Limitation of Liability Manufacturer Warranties. Subject to the limitations set forth herein, Manufacturer warrants that the Products manufactured by it in its Northford, Connecticut facility and sold by it to its authorized Distributors shall be free, under normal use and service, from defects in material and workmanship for a period of thirty six months (36) months from the date of manufacture (effective Jan. - Page 28 World Headquarters 12 Clintonville Road Northford, CT 06472-1610 USA 203-484-7161 fax 203-484-7118 www.notifier.com...
