Page 1 Ductless Floating Air ® Multi-Zone R-454B Refrigerant Outdoor Unit 230-Volt: FPHMR18A3D, FPHMR27A3D, FPHMR36A3D, FPHMR42A3D Wall Mounted Unit 230-Volt: FAHMW07A3D, FAHFW09A3D, FAHFW12A3D, FAHFW18A3D, FAHFW24A3D Cassette 230-Volt: FPHFC09A3D, FPHFC12A3D, FPHFC24A3D, FPHFC24A3D Ducted 230-Volt: FPHFD09A3D, FPHFD12A3D, FPHFD24A3D, FPHFD24A3D THE EXPERTS IN ROOM AIR CONDITIONING 966011404_00...
Page 2: Table Of Contents
TABLE OF CONTENTS INTRODUCTION Important Safety Information Personal Injury Or Death Hazards Model And Serial Number Location Model Identification Guide Serial Number Reference Guide SPECIFICATION 18-27k BTU (Outdoor Units) (Non-Ducted Configuration) 36-42k BTU (Outdoor Units) (Non-Ducted Configuration) 7-12K Wall Mounted Units 18-24k BTU Wall Mounted Units Allowable Configurations 18k-36k Allowable Configurations 42k...
Page 3 FAHFW09A3D, FAHFW12A3D, FAHFW18A3D, FAHFW24A3D (With A2L sensor connection) Ducted 9k &12k Ducted 18k &24k Cassette 9k -24k Outdoor Unit, FPHMR18A3D Outdoor Unit, FPHMR24A3D Outdoor Unit FPHMR36A3D APPENDIX Interactive Parts Viewer Limited Warranty Compressor Discharge Temp Sensor Resistance Values Friedrich Authorized Parts Depots...
Page 4: Introduction
Installation procedures are not given in this manual. They are given in the Installation/Operation manual which can be acquired on the Friedrich website. Click the Link or scan the QR code to be directed to the Professional page where you can locate our technical literature.
Page 5: Personal Injury Or Death Hazards
INTRODUCTION Personal Injury Or Death Hazards WARNING AVERTISSEMENT ADVERTENCIA SAFETY Do not remove, disable Ne pas supprime, désacti- No eliminar, desactivar o or bypass this unit’s ver ou contourner cette pasar por alto los dispositi- FIRST safety devices. Doing so l´unité...
Page 6: Mechanical Hazards
INTRODUCTION PERSONAL INJURY OR DEATH HAZARDS • REFRIGERATION SYSTEM REPAIR HAZARDS: • Use approved standard refrigerant recovering procedures and equipment to relieve high pressure before opening system for repair. Reference EPA regulations (40 CFR Part 82, Subpart F ) Section 608. Do not allow liquid refrigerant to contact skin.
Page 7 CAUTION: Do Not Operate Equipment During Active Stages Of Construction To ensure proper operation, Friedrich requires that all equipment is not operated during active construction phases. This includes active stages of completing framing, drywalling, spackling, sanding, painting, ﬂooring, and moulding in the equipment’s designated conditioning space. The use of this equipment during construction could result in premature failure of the components and/or system and is in violation of our standard warranty guidelines.
Page 8: Model And Serial Number Location
INTRODUCTION Model And Serial Number Location Indoor Unit On side of Unit Figure 101 (Indoor Unit Model Nameplate location) Outdoor Unit On side of Unit Figure 102 (Indoor Unit Model Nameplate location)
Page 9: Model Identification Guide
Optional hard-wired controller for Floating Air wall-mounted and cassette indoor models. FACTORY DESIGNATION 02 = FEBRUARY Included with concealed ducted models. Not compatible with AHU indoor models. See your M = FRIEDRICH MTY 03 = MARCH Friedrich representative for options. 04 = APRIL...
Page 10: Specification
SPECIFICATION 18-27k BTU (Outdoor Units) (Non-Ducted Configuration) Model Unit FPHMR18A3D FPHMR27A3D Power Supply V/ph/Hz 208-230/1/60 208/230/1/60 Energy Star Standard Energy Star -Cold Climate Performance Rated Capacity at 95℉ Btu/h 18000 27000 Cooling Capacity Range(MIN- Btu/h 9000-22000 9000-31000 MAX) Capacity at 115℉ Btu/h 18000 27000...
Page 11: Specifications
SPECIFICATIONS 18-27k BTU (Outdoor Units) (Non-Ducted Configuration) Model Unit FPHMR18A3D FPHMR27A3D Moisture Removal pints/hr Refrigerant R454B R454B Refrigerant charge volume oz 51.1 76.2 Compressor type ROTARY ROTARY Compressor MFG Panasonic Panasonic Compressor model # KRD220XAA21 KKD330XAA21 Expansion Device copper pipe+Hydrophilic alu- copper pipe+Hydrophilic alu- Refrigeration Condenser material...
Page 12: 36-42K Btu (Outdoor Units) (Non-Ducted Configuration)
SPECIFICATIONS 36-42k BTU (Outdoor Units) (Non-Ducted Configuration) Model Unit FPHMR36A3D FPHMR42A3D Power Supply V/ph/Hz 208/230/1/60 208/230/1/60 Energy Star Standard Energy Star -Cold Climate Performance Rated Capacity at 95℉ Btu/h 36000 42000 Cooling Capacity Range(MIN- Btu/h 36000 42000 MAX) Capacity at 115℉ Btu/h 9000-46800 9000-54600...
Page 13 SPECIFICATIONS 36-42k BTU (Outdoor Units) (Non-Ducted Configuration) Model Unit FPHMR36A3D FPHMR42A3D Moisture Removal pints/hr Refrigerant R454B R454B Refrigerant charge volume oz 105.8 105.8 Compressor type ROTARY ROTARY Compressor MFG CRSS CRSS Compressor model # C-7RZ420H1CAF C-7RZ420H1CAF Expansion Device copper pipe+Hydrophilic Refrigeration Condenser material copper pipe+Hydrophilic aluminium...
Page 14: 7-12K Wall Mounted Units
SPECIFICATIONS 7-12K Wall Mounted Units FAC Indoor Model FAHMW073D FAHFW09A3D FAHFW12A3D Power Supply V/ph/Hz 208V/230V~,60Hz,1P Energy Star Standard Energy Star -Cold Climate Performance Air Circulation(Max) ft3 CFM Air Circulation(high) ft3 CFM Air Circulation(medium) ft3 CFM Indoor Air- Flow Air Circulation(low) ft3 CFM Indoor Sound Pressure(Max//H/M/L/Quiet) dB (A)
Page 15: 18-24K Btu Wall Mounted Units
SPECIFICATIONS 18-24k BTU Wall Mounted Units FAC Indoor Model FAHFW18A3D FAHFW24A3D Power Supply V/ph/Hz Energy Star Standard Energy Star -Cold Climate Performance Air Circulation(Max) ft3 CFM Air Circulation(high) ft3 CFM Air Circulation(medium) ft3 CFM Indoor AirFlow Air Circulation(low) ft3 CFM Indoor Sound Pressure(Max//H/M/L/ dB (A) 48/45/41/39/36...
Page 16 SPECIFICATIONS 9-12k BTU Cassette FAC Indoor Model FPHFC09A3D FPHFC12A3D Power Supply V/ph/Hz 208-230/1/60 208-230/1/60 Energy Star Standard Energy Star -Cold Climate Air Circulation(Max) ft3 CFM Air Circulation(high) ft3 CFM Air Circulation(medium) ft3 CFM Indoor AirFlow Air Circulation(low) ft3 CFM Indoor Sound Pressure(Max//H/M/L/ dB (A) Quiet) Model...
Page 17 SPECIFICATIONS 18-24k BTU Cassette FAC Indoor Model FPHFC18A3D FPHFC24A3D Power Supply V/ph/Hz 208-230/1/60 208-230/1/60 Energy Star Standard Energy Star -Cold Climate Air Circulation(Max) ft3 CFM Air Circulation(high) ft3 CFM Air Circulation(medium) ft3 CFM Indoor AirFlow Air Circulation(low) ft3 CFM Indoor Sound Pressure(Max//H/ dB (A) M/L/Quiet) Model...
Page 18 SPECIFICATIONS 9-12k BTU Ducted FAC Indoor Model FPHFC09A3D FPHFC12A3D Type Ducted Ducted Power Supply V/ph/Hz 208~230/1/60 208~230/1/60 Energy Star Standard Energy Star -Cold Climate Air Circulation(Max) ft3 CFM Air Circulation(high) ft3 CFM Air Circulation(medium) ft3 CFM Air Circulation(low) ft3 CFM Indoor Sound Pressure(Max//H/ Indoor AirFlow dB (A)
Page 19 SPECIFICATIONS 18-24k BTU Ducted FPHFC18A3D FPHFC24A3D FAC Indoor Model Ducted Ducted Type 208~230/1/60 208~230/1/60 Power Supply V/ph/Hz Energy Star Standard Energy Star -Cold Climate Air Circulation(Max) ft3 CFM Air Circulation(high) ft3 CFM Air Circulation(medium) ft3 CFM Air Circulation(low) ft3 CFM Indoor AirFlow Indoor Sound Pressure(Max// dB (A)
Page 20: Allowable Configurations 18K-36K
SPECIFICATIONS FLOATING AIR PRO X | MULTI-ZONE ALLOWABLE CONFIGURATIONS ™ Allowable Configurations 18k-36k Choose the outdoor unit that is applicable to the number of indoor spaces you want to heat and cool. Mix-and-match flexibility lets you pick the type of indoor units best suited to the application. Choose from wall-mounted, ceiling cassette, or concealed ducted heat pumps.
Page 21: Allowable Configurations 42K
SPECIFICATIONS Allowable Configurations 42k FLOATING AIR PRO X | MULTI-ZONE ALLOWABLE CONFIGURATIONS ™ 3, 4, OR 5 ZONES 42,000 BTU 54,000 Btu max. connected capacity FPHMR42A3D FPHMR42A3D ZONE 1 ZONE 2 ZONE 3 ZONE 4 ZONE 5 TOTAL ZONE 1 ZONE 2 ZONE 3 ZONE 4...
Page 22: Room Size Restriction
SPECIFICATIONS Room Size Restriction Maximum Refrigerant Charge X[oz(g)] Model (Btu/h) Maximum Refrigerant 69.67 (1975) 101.34 (2873) 127 (3600) 128.33 (3638) Charge Figure 209 Minimum room size R-454B refrigerant is determined by total refrigerant charge in system. Use this chart to determine the minimum room size the indoor head can be installed in without an A2L Sensor.
Page 23: Installation Instructions
Installation Instructions / SPECIFICATIONS Indoor Unit Clearances Installation diasram Distance from ceiling should be over 7.9in Distance from wall '\.!,. should be over 2in Distance from the wall Distance from the obstacle should be over 9.8ft. should be over 2in Distance from floor should be over 6 ft.
Page 24: Dimensions Indoor Unit
SPECIFICATIONS Dimensions Indoor Unit FAHFW09A3D, FAHFW12A3D ALL DIMENSIONS GIVEN IN INCHES (") 33 7/8 Air Inlet 8 3/8 2 3/8 Tube Exit 28.5 2 3/4 7 1/4 7 1/2 Ceilng 26 1/2 20 5/8 > 7 7/8 2 5/8 2 3/4 2 5/8 >...
Page 25: Fahfw18A3D, Fahfw24A3D
SPECIFICATIONS Dimensions Indoor Unit FAHFW18A3D, FAHFW24A3D 44 1/8 ALL DIMENSIONS GIVEN IN INCHES (") CEILING 45 1/4 10 1/8 38 1/4 TUBE EXIT 3 3/8 38 1/4 2 1/4 AIR INLET 23 7/8 27 3/4 37 1/2 CEILING 28 7/8 >...
Page 26: Dimensions Outdoor Unit
SPECIFICATIONS Dimensions Outdoor Unit FPHMR18A3D Unit: in. Figure 214...
Page 27: Fphmr27A3D, Fphmr36A3D, Fphmr42A3D
SPECIFICATIONS Dimensions Outdoor Unit FPHMR27A3D, FPHMR36A3D, FPHMR42A3D Unit: in. 27K/36K/42KK Electric box 14-11/16 Liquid pipe 5-1/2 7-5/8 Gas pipe 8-11/16 3-5/32 38-3/8 Air inlet Drain pipe 2-3/4 5/32-7/16*11/16 Hole Air outlet Figure 215...
Page 28: Cassette Type
Cassette type SPECIFICATIONS 9K/12K Dimensions Cassette (9 and 12k BTU) Unit: in.(mm) Figure 216...
Page 29: Dimensions Cassette (18 And 24K Btu)
SPECIFICATIONS Dimensions Cassette (18 and 24k BTU) Unit: (mm) 37-3/8(950) 21-5/8(550) 19-3/16(487) 33(840) 8-1/4(209) 7-1/8 (182) 5-7/8 (148) 30(760) 8(203) 1-3/16(30) H+1-1/8(28) 33-7/8~35-7/8(860~910) Model 18K/24K Figure 217...
Page 30: Dimensions Ducted (9 And 12K Btu)
SPECIFICATIONS Dimensions Ducted (9 and 12k BTU) Unit : in.(mm) 7-1/12(190) Air outlet 6-11/16(170) 3-7/8(98) 3-3/8 (85) 1-3/8(35) Air inlet Gas pipe Liquid pipe Air outlet Drain pipe Electric box Air inlet M M o o d d e e l l ( ( B B t t u u / / h h ) ) 37-13/16 35-13/16...
Page 31: Dimensions Ducted (18 And 24K Btu)
SPECIFICATIONS Dimensions Ducted (18 and 24k BTU) Unit : in.(mm) 1/2(14) Electric box Air inlet 8-3/4(222) 5-7/8(150) 1(21) 2-1/4(58) Air outlet Liquid pipe Gas pipe Drain pipe Air inlet Air outlet Model(Btu/h) 26-1/2 33-1/2 26-1/2 31-1/2 (674) (850) (636) (673) (800) (636) (24)
Page 32: Sound Pressure Data - Outdoor Units
6 . S S O O U U N N D D P P R R E E S S S S U U R R E E D D A A T T A A SPECIFICATIONS 6. Sound Pressure Data Sound Pressure Data - Outdoor Units Outdoor unit Model...
Page 33: Capacity Characteristic Charts
5. Capacities and Selection Data SPECIFICATIONS 5.1 Capacity Characteristic Charts Capacities and Selection Data (Capacity Characteristics Charts) The following charts show the characteristics of outdoor unit capacity, which corresponds with the operating ambient temperature of outdoor unit. Conditions: ① Pipe length / height difference : 25 ft. (7.5m) / 0 ft. (0m) ②...
Page 34: Capacities And Selection Data (Capacity Characteristics Charts) 18K (Cooling Up To 2 Indoor Units Series)
SPECIFICATIONS 5. CAPACITIES AND SELECTION DATA Capacities and Selection Data (Capacity Characteristics Charts) 18K (Cooling Up to 2 indoor units series) 18K(Up to 2 indoor units series) Cooling Operation PERFORMANCE DATA OUTDOOR DB (°C) COMBINATION IDDB (°C) （%） SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT...
Page 35: Capacities And Selection Data
5. CAPACITIES AND SELECTION DATA SPECIFICATIONS Capacities and Selection Data (Capacity Characteristics Charts) 18K (Cooling Up to 2 indoor units series) Cooling Operation PERFORMANCE DATA OUTDOOR DB (°C) 48.8 COMBINATION IDDB IDWB (°C) (°C) （%） SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT 3.43 2.09 0.61 2117 3.05 1.86 0.61 2160 2.93 1.79 0.61 2181 2.78 1.70 0.61 2225...
Page 36: Error Code
SPECIFICATIONS 5. CAPACITIES AND SELECTION DATA Capacities and Selection Data (Capacity Characteristics Charts) 18K (Cooling up to 2 indoor units series) Cooling Operation PERFORMANCE DATA OUTDOOR DB (°C) COMBINATION IDDB (°C) （%） SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF...
Page 37 SPECIFICATIONS 5. CAPACITIES AND SELECTION DATA Capacities and Selection Data (Capacity Characteristics Charts) 18K (Cooling up to 2 indoor units series) Cooling Operation PERFORMANCE DATA OUTDOOR DB (°C) 48.8 COMBINATION IDDB IDWB (°C) (°C) （%） SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT 3.40 2.07 0.61 2097 3.02 1.85 0.61 2139 2.90 1.77 0.61 2161 2.76 1.68 0.61 2204...
Page 38 SPECIFICATIONS 5. CAPACITIES AND SELECTION DATA Capacities and Selection Data (Capacity Characteristics Charts) 18K (Cooling up to 2 indoor units series) Cooling Operation PERFORMANCE DATA OUTDOOR DB (°C) COMBINATION IDDB (°C) （%） SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF...
Page 39 SPECIFICATIONS 5. CAPACITIES AND SELECTION DATA Capacities and Selection Data (Capacity Characteristics Charts) 18K (Cooling up to 2 indoor units series) Cooling Operation PERFORMANCE DATA OUTDOOR DB (°C) 48.8 COMBINATION IDDB IDWB (°C) (°C) （%） SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT 3.37 2.06 0.61 2077 3.00 1.83 0.61 2118 2.88 1.76 0.61 2140 2.74 1.67 0.61 2183...
Page 40 SPECIFICATIONS 5. CAPACITIES AND SELECTION DATA Capacities and Selection Data (Capacity Characteristics Charts) 18K (Cooling up to 2 indoor units series) Cooling Operation PERFORMANCE DATA OUTDOOR DB (°C) COMBINATION IDDB (°C) （%） SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF...
Page 41 SPECIFICATIONS 5. CAPACITIES AND SELECTION DATA Capacities and Selection Data (Capacity Characteristics Charts) 18K( Cooling up to 2 indoor units series) Cooling Operation PERFORMANCE DATA OUTDOOR DB (°C) 48.8 COMBINATION IDDB IDWB (°C) (°C) （%） SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT 3.27 2.00 0.61 2026 2.91 1.78 0.61 2066 2.80 1.71 0.61 2087 2.66 1.62 0.61 2129...
Page 42 SPECIFICATIONS 5. CAPACITIES AND SELECTION DATA Capacities and Selection Data (Capacity Characteristics Charts) 18K( Cooling up to 2 indoor units series) Cooling Operation PERFORMANCE DATA OUTDOOR DB (°C) COMBINATION IDDB (°C) （%） SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF...
Page 43 SPECIFICATIONS 5. CAPACITIES AND SELECTION DATA Capacities and Selection Data (Capacity Characteristics Charts) 18K( Cooling up to 2 indoor units series) Cooling Operation PERFORMANCE DATA OUTDOOR DB (°C) 48.8 COMBINATION IDDB IDWB (°C) (°C) （%） SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT 3.21 1.96 0.61 2005 2.85 1.74 0.61 2046 2.74 1.67 0.61 2066 2.60 1.59 0.61 2108...
Page 44 SPECIFICATIONS 5. CAPACITIES AND SELECTION DATA Capacities and Selection Data (Capacity Characteristics Charts) 18K( Cooling up to 2 indoor units series) Cooling Operation PERFORMANCE DATA OUTDOOR DB (°C) COMBINATION IDDB (°C) （%） SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF...
Page 45 SPECIFICATIONS 5. CAPACITIES AND SELECTION DATA Capacities and Selection Data (Capacity Characteristics Charts) 18K( Cooling up to 2 indoor units series) Cooling Operation PERFORMANCE DATA OUTDOOR DB (°C) 48.8 COMBINATION IDDB IDWB (°C) (°C) （%） SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF 3.11 1.90 0.61 1985 2.77 1.69 0.61 2025 2.66 1.62 0.61 2045 2.52 1.54 0.61...
Page 46: Capacities And Selection Data (Capacity Characteristics Charts) 18K( Heating Up To 2 Indoor Units Series)
SPECIFICATIONS 5. CAPACITIES AND SELECTION DATA Capacities and Selection Data (Capacity Characteristics Charts) 18K( Heating up to 2 indoor units series) 18K(Up to 2 indoor units series) HEATING PERFORMANCE DATA OUTDOOR WB(℃） COMBINATION INDOOR -20.5 -17.7 -8.3 DB(℃）（%） INPUT INPUT INPUT INPUT...
Page 47 SPECIFICATIONS 5. CAPACITIES AND SELECTION DATA Capacities and Selection Data (Capacity Characteristics Charts) 18K( Heating up to 2 indoor units series) OUTDOOR WB(℃） COMBINATION INDOOR DB(℃）（%） INPUT INPUT INPUT INPUT INPUT INPUT 5.78 2542 5.93 2574 6.24 2669 6.55 2749 6.75 2804...
Page 48 SPECIFICATIONS 5. CAPACITIES AND SELECTION DATA Capacities and Selection Data (Capacity Characteristics Charts) 18K( Heating up to 2 indoor units series) OUTDOOR WB(℃） COMBINATION INDOOR -20.5 -17.7 -8.3 DB(℃）（%） INPUT INPUT INPUT INPUT INPUT INPUT INPUT INPUT 4.02 2124 4.53 2255 5.03...
Page 49 SPECIFICATIONS 5. CAPACITIES AND SELECTION DATA Capacities and Selection Data (Capacity Characteristics Charts) 18K( Heating up to 2 indoor units series) OUTDOOR WB(℃） COMBINATION INDOOR DB(℃）（%） INPUT INPUT INPUT INPUT INPUT INPUT 5.26 2376 5.39 2406 5.68 2495 5.96 2570 6.14 2621...
Page 50: Capacities And Selection Data (Capacity Characteristics Charts) 27K(Cooling Up To 3 Indoor Units Series)
SPECIFICATIONS 5. CAPACITIES AND SELECTION DATA Capacities and Selection Data (Capacity Characteristics Charts) 27K(Cooling up to 3 indoor units series) 27K(Up to 3 indoor units series) Cooling Operation PERFORMANCE DATA OUTDOOR DB (°C) COMBINATION IDDB (°C) （%） SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT...
Page 51 5. CAPACITIES AND SELECTION DATA SPECIFICATIONS Capacities and Selection Data (Capacity Characteristics Charts) 27K(Cooling up to 3 indoor units series) Cooling Operation PERFORMANCE DATA OUTDOOR DB (°C) 48.8 COMBINATION IDDB IDWB (°C) (°C) （%） SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT 5.20 3.17 0.61 3044 4.63 2.82 0.61 3105 4.45 2.71 0.61 3136 4.22 2.58 0.61 3199...
Page 52 SPECIFICATIONS 5. CAPACITIES AND SELECTION DATA Capacities and Selection Data (Capacity Characteristics Charts) 27K(Cooling up to 3 indoor units series) Cooling Operation PERFORMANCE DATA OUTDOOR DB (°C) COMBINATION IDDB (°C) （%） SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF...
Page 53 SPECIFICATIONS 5. CAPACITIES AND SELECTION DATA Capacities and Selection Data (Capacity Characteristics Charts) 27K(Cooling up to 3 indoor units series) Cooling Operation PERFORMANCE DATA OUTDOOR DB (°C) 48.8 COMBINATION IDDB IDWB (°C) (°C) （%） SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT 5.15 3.14 0.61 3015 4.59 2.80 0.61 3076 4.40 2.69 0.61 3106 4.18 2.55 0.61 3169...
Page 54 SPECIFICATIONS 5. CAPACITIES AND SELECTION DATA Capacities and Selection Data (Capacity Characteristics Charts) 27K(Cooling up to 3 indoor units series) Cooling Operation PERFORMANCE DATA OUTDOOR DB (°C) COMBINATION IDDB (°C) （%） SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF...
Page 55 SPECIFICATIONS 5. CAPACITIES AND SELECTION DATA Capacities and Selection Data (Capacity Characteristics Charts) 27K(Cooling up to 3 indoor units series) Cooling Operation PERFORMANCE DATA OUTDOOR DB (°C) 48.8 COMBINATION IDDB IDWB (°C) (°C) （%） SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT 5.11 3.12 0.61 2986 4.55 2.77 0.61 3046 4.37 2.66 0.61 3076 4.15 2.53 0.61 3138...
Page 56 SPECIFICATIONS 5. CAPACITIES AND SELECTION DATA Capacities and Selection Data (Capacity Characteristics Charts) 27K(Cooling up to 3 indoor units series) Cooling Operation PERFORMANCE DATA OUTDOOR DB (°C) COMBINATION IDDB (°C) （%） SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF...
Page 57 SPECIFICATIONS 5. CAPACITIES AND SELECTION DATA Capacities and Selection Data (Capacity Characteristics Charts) 27K(Cooling up to 3 indoor units series) Cooling Operation PERFORMANCE DATA OUTDOOR DB (°C) 48.8 COMBINATION IDDB IDWB (°C) (°C) （%） SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT 4.96 3.03 0.61 2913 4.42 2.69 0.61 2971 4.24 2.59 0.61 3001 4.03 2.46 0.61 3061...
Page 58 SPECIFICATIONS 5. CAPACITIES AND SELECTION DATA Capacities and Selection Data (Capacity Characteristics Charts) 27K(Cooling up to 3 indoor units series) Cooling Operation PERFORMANCE DATA OUTDOOR DB (°C) COMBINATION IDDB (°C) （%） SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF...
Page 59 SPECIFICATIONS 5. CAPACITIES AND SELECTION DATA Capacities and Selection Data (Capacity Characteristics Charts) 27K(Cooling up to 3 indoor units series) Cooling Operation PERFORMANCE DATA OUTDOOR DB (°C) 48.8 COMBINATION IDDB IDWB (°C) (°C) （%） SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT 4.86 2.97 0.61 2884 4.33 2.64 0.61 2941 4.15 2.53 0.61 2971 3.95 2.41 0.61 3031...
Page 60 SPECIFICATIONS 5. CAPACITIES AND SELECTION DATA Capacities and Selection Data (Capacity Characteristics Charts) 27K(Cooling up to 3 indoor units series) Cooling Operation PERFORMANCE DATA OUTDOOR DB (°C) COMBINATION IDDB (°C) （%） SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF...
Page 61 SPECIFICATIONS 5. CAPACITIES AND SELECTION DATA Capacities and Selection Data (Capacity Characteristics Charts) 27K(Cooling up to 3 indoor units series) Cooling Operation PERFORMANCE DATA OUTDOOR DB (°C) 48.8 COMBINATION IDDB IDWB (°C) (°C) （%） SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT 8.21 5.83 0.71 1594 8.13 5.77 0.71 1609 8.04 5.71 0.71 1624 7.94 5.63 0.71 1637...
Page 62: Capacities And Selection Data (Capacity Characteristics Charts) 27K (Heating Up To 3 Indoor Units Series)
5. CAPACITIES AND SELECTION DATA SPECIFICATIONS Capacities and Selection Data (Capacity Characteristics Charts) 27K (Heating up to 3 indoor units series) 27K(Up to 3 indoor units series) HEATING PERFORMANCE DATA OUTDOOR WB(℃） COMBINATION INDOOR -20.5 -17.7 -8.3 DB(℃）（%） INPUT INPUT INPUT INPUT...
Page 63 5. CAPACITIES AND SELECTION DATA SPECIFICATIONS Capacities and Selection Data (Capacity Characteristics Charts) 27K (Heating up to 3 indoor units series) OUTDOOR WB(℃） COMBINATION INDOOR DB(℃）（%） INPUT INPUT INPUT INPUT INPUT INPUT 8.77 4336 8.99 4390 9.47 4553 9.94 4690 10.24 4784...
Page 64: Capacities And Selection Data (Capacity Characteristics Charts) 27K (Heating Up To 3 Indoor Units Series)
SPECIFICATIONS 5. CAPACITIES AND SELECTION DATA Capacities and Selection Data (Capacity Characteristics Charts) 27K (Heating up to 3 indoor units series) OUTDOOR WB(℃） COMBINATION INDOOR -20.5 -17.7 -8.3 DB(℃）（%） INPUT INPUT INPUT INPUT INPUT INPUT INPUT INPUT 6.10 3623 6.86 3847 7.63...
Page 65: Capacities And Selection Data (Capacity Characteristics Charts) 27K (Heating Up To 3 Indoor Units Series)
SPECIFICATIONS 5. CAPACITIES AND SELECTION DATA Capacities and Selection Data (Capacity Characteristics Charts) 27K (Heating up to 3 indoor units series) OUTDOOR WB(℃） COMBINATION INDOOR DB(℃）（%） INPUT INPUT INPUT INPUT INPUT INPUT 7.97 4053 8.18 4104 8.61 4256 9.04 4384 9.31 4471...
Page 66: Capacities And Selection Data (Capacity Characteristics Charts) 36K(Cooling Up To 4 Indoor Units Series)
SPECIFICATIONS 5. CAPACITIES AND SELECTION DATA Capacities and Selection Data (Capacity Characteristics Charts) 36K(Cooling up to 4 indoor units series) 36K(Up to 4 indoor units series) Cooling Operation PERFORMANCE DATA OUTDOOR DB (°C) COMBINATION IDDB (°C) （%） SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT...
Page 67 5. CAPACITIES AND SELECTION DATA SPECIFICATIONS Capacities and Selection Data (Capacity Characteristics Charts) 36K(Cooling up to 4 indoor units series) Cooling Operation PERFORMANCE DATA OUTDOOR DB (°C) 48.8 COMBINATION IDDB IDWB (°C) (°C) （%） SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT 6.87 4.19 0.61 4462 6.11 3.73 0.61 4551 5.87 3.58 0.61 4597 5.57 3.40 0.61 4689...
Page 68 SPECIFICATIONS 5. CAPACITIES AND SELECTION DATA Capacities and Selection Data (Capacity Characteristics Charts) 36K(Cooling up to 4 indoor units series) Cooling Operation PERFORMANCE DATA OUTDOOR DB (°C) COMBINATION IDDB (°C) （%） SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF...
Page 69 SPECIFICATIONS 5. CAPACITIES AND SELECTION DATA Capacities and Selection Data (Capacity Characteristics Charts) 36K(Cooling up to 4 indoor units series) Cooling Operation PERFORMANCE DATA OUTDOOR DB (°C) 48.8 COMBINATION IDDB IDWB (°C) (°C) （%） SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT 6.80 4.15 0.61 4419 6.05 3.69 0.61 4508 5.81 3.55 0.61 4553 5.52 3.37 0.61 4644...
Page 70 SPECIFICATIONS 5. CAPACITIES AND SELECTION DATA Capacities and Selection Data (Capacity Characteristics Charts) 36K(Cooling up to 4 indoor units series) Cooling Operation PERFORMANCE DATA OUTDOOR DB (°C) COMBINATION IDDB (°C) （%） SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF...
Page 71 5. CAPACITIES AND SELECTION DATA SPECIFICATIONS Capacities and Selection Data (Capacity Characteristics Charts) 36K(Cooling up to 4 indoor units series) Cooling Operation PERFORMANCE DATA OUTDOOR DB (°C) 48.8 COMBINATION IDDB IDWB (°C) (°C) （%） SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT 6.75 4.12 0.61 4376 6.00 3.66 0.61 4464 5.76 3.52 0.61 4509 5.48 3.34 0.61 4599...
Page 72 SPECIFICATIONS 5. CAPACITIES AND SELECTION DATA Capacities and Selection Data (Capacity Characteristics Charts) 36K(Cooling up to 4 indoor units series) Cooling Operation PERFORMANCE DATA OUTDOOR DB (°C) COMBINATION IDDB (°C) （%） SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF...
Page 73 5. CAPACITIES AND SELECTION DATA SPECIFICATIONS Capacities and Selection Data (Capacity Characteristics Charts) 36K(Cooling up to 4 indoor units series) Cooling Operation PERFORMANCE DATA OUTDOOR DB (°C) 48.8 COMBINATION IDDB IDWB (°C) (°C) （%） SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT 6.55 4.00 0.61 4269 5.83 3.56 0.61 4355 5.60 3.41 0.61 4399 5.32 3.24 0.61 4487...
Page 74 SPECIFICATIONS 5. CAPACITIES AND SELECTION DATA Capacities and Selection Data (Capacity Characteristics Charts) 36K(Cooling up to 4 indoor units series) Cooling Operation PERFORMANCE DATA OUTDOOR DB (°C) COMBINATION IDDB (°C) （%） SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF...
Page 75 SPECIFICATIONS 5. CAPACITIES AND SELECTION DATA Capacities and Selection Data (Capacity Characteristics Charts) 36K(Cooling up to 4 indoor units series) Cooling Operation PERFORMANCE DATA OUTDOOR DB (°C) 48.8 COMBINATION IDDB IDWB (°C) (°C) （%） SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT 6.42 3.92 0.61 4227 5.71 3.48 0.61 4311 5.48 3.35 0.61 4355 5.21 3.18 0.61 4442...
Page 76 SPECIFICATIONS 5. CAPACITIES AND SELECTION DATA Capacities and Selection Data (Capacity Characteristics Charts) 36K(Cooling up to 4 indoor units series) Cooling Operation PERFORMANCE DATA OUTDOOR DB (°C) COMBINATION IDDB (°C) （%） SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF...
Page 77 5. CAPACITIES AND SELECTION DATA SPECIFICATIONS Capacities and Selection Data (Capacity Characteristics Charts) 36K(Cooling up to 4 indoor units series) Cooling Operation PERFORMANCE DATA OUTDOOR DB (°C) 48.8 COMBINATION IDDB IDWB (°C) (°C) （%） SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT 6.22 3.80 0.61 4184 5.54 3.38 0.61 4268 5.32 3.24 0.61 4311 5.05 3.08 0.61 4397...
Page 78: Capacities And Selection Data (Capacity Characteristics Charts) 36K (Heating Up To 4 Indoor Units Series)
SPECIFICATIONS 5. CAPACITIES AND SELECTION DATA 36K(Up to 4 indoor units series) Capacities and Selection Data (Capacity Characteristics Charts) 36K (Heating up to 4 indoor units series) HEATING PERFORMANCE DATA OUTDOOR WB(℃） COMBINATION INDOOR -20.5 -17.7 -8.3 DB(℃）（%） INPUT INPUT INPUT INPUT...
Page 79 5. CAPACITIES AND SELECTION DATA SPECIFICATIONS Capacities and Selection Data (Capacity Characteristics Charts) 36K (Heating up to 4 indoor units series) OUTDOOR WB(℃） COMBINATION INDOOR DB(℃）（%） INPUT INPUT INPUT INPUT INPUT INPUT 11.57 5234 11.87 5299 12.50 5495 13.12 5660 13.52 5773...
Page 80 SPECIFICATIONS 5. CAPACITIES AND SELECTION DATA Capacities and Selection Data (Capacity Characteristics Charts) 36K (Heating up to 4 indoor units series) OUTDOOR WB(℃） COMBINATION INDOOR -20.5 -17.7 -8.3 DB(℃）（%） INPUT INPUT INPUT INPUT INPUT INPUT INPUT INPUT 8.05 4373 9.06 4643 10.07...
Page 81 SPECIFICATIONS 5. CAPACITIES AND SELECTION DATA Capacities and Selection Data (Capacity Characteristics Charts) 36K (Heating up to 4 indoor units series) OUTDOOR WB(℃） COMBINATION INDOOR DB(℃）（%） INPUT INPUT INPUT INPUT INPUT INPUT 10.53 4892 10.80 4953 11.37 5137 11.94 5291 12.29 5396...
Page 82: Capacities And Selection Data (Capacity Characteristics Charts) 42K (Cooling Up To 5 Indoor Units Series)
SPECIFICATIONS 5. CAPACITIES AND SELECTION DATA Capacities and Selection Data (Capacity Characteristics Charts) 42K (Cooling up to 5 indoor units series) 42K(Up to 5 indoor units series) Cooling Operation PERFORMANCE DATA OUTDOOR DB (°C) COMBINATION IDDB (°C) （%） SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT...
Page 83 5. CAPACITIES AND SELECTION DATA SPECIFICATIONS Capacities and Selection Data (Capacity Characteristics Charts) 42K (Cooling up to 5 indoor units series) Cooling Operation PERFORMANCE DATA OUTDOOR DB (°C) 48.8 COMBINATION IDDB IDWB (°C) (°C) （%） SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT 9.11 5.55 0.61 5880 8.10 4.94 0.61 5998 7.78 4.75 0.61 6058 7.39 4.51 0.61 6179...
Page 84 SPECIFICATIONS 5. CAPACITIES AND SELECTION DATA Capacities and Selection Data (Capacity Characteristics Charts) 42K (Cooling up to 5 indoor units series) Cooling Operation PERFORMANCE DATA OUTDOOR DB (°C) COMBINATION IDDB (°C) （%） SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF...
Page 85 SPECIFICATIONS 5. CAPACITIES AND SELECTION DATA Capacities and Selection Data (Capacity Characteristics Charts) 42K (Cooling up to 5 indoor units series) Cooling Operation PERFORMANCE DATA OUTDOOR DB (°C) 48.8 COMBINATION IDDB IDWB (°C) (°C) （%） SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT 9.02 5.50 0.61 5823 8.03 4.90 0.61 5940 7.71 4.70 0.61 6000 7.32 4.47 0.61 6120...
Page 86 SPECIFICATIONS 5. CAPACITIES AND SELECTION DATA Capacities and Selection Data (Capacity Characteristics Charts) 42K (Cooling up to 5 indoor units series) Cooling Operation PERFORMANCE DATA OUTDOOR DB (°C) COMBINATION IDDB (°C) （%） SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF...
Page 87 5. CAPACITIES AND SELECTION DATA SPECIFICATIONS Capacities and Selection Data (Capacity Characteristics Charts) 42K (Cooling up to 5 indoor units series) Cooling Operation PERFORMANCE DATA OUTDOOR DB (°C) 48.8 COMBINATION IDDB IDWB (°C) (°C) （%） SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT 8.94 5.46 0.61 5767 7.96 4.86 0.61 5883 7.64 4.66 0.61 5942 7.26 4.43 0.61 6061...
Page 88 SPECIFICATIONS 5. CAPACITIES AND SELECTION DATA Capacities and Selection Data (Capacity Characteristics Charts) 42K (Cooling up to 5 indoor units series) Cooling Operation PERFORMANCE DATA OUTDOOR DB (°C) COMBINATION IDDB (°C) （%） SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF...
Page 89 5. CAPACITIES AND SELECTION DATA SPECIFICATIONS Capacities and Selection Data (Capacity Characteristics Charts) 42K (Cooling up to 5 indoor units series) Cooling Operation PERFORMANCE DATA OUTDOOR DB (°C) 48.8 COMBINATION IDDB IDWB (°C) (°C) （%） SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT 8.68 5.30 0.61 5626 7.73 4.71 0.61 5739 7.42 4.53 0.61 5796 7.05 4.30 0.61 5913...
Page 90 SPECIFICATIONS 5. CAPACITIES AND SELECTION DATA Capacities and Selection Data (Capacity Characteristics Charts) 42K (Cooling up to 5 indoor units series) Cooling Operation PERFORMANCE DATA OUTDOOR DB (°C) COMBINATION IDDB (°C) （%） SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF...
Page 91 SPECIFICATIONS 5. CAPACITIES AND SELECTION DATA Capacities and Selection Data (Capacity Characteristics Charts) 42K (Cooling up to 5 indoor units series) Cooling Operation PERFORMANCE DATA OUTDOOR DB (°C) 48.8 COMBINATION IDDB IDWB (°C) (°C) （%） SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT 8.51 5.19 0.61 5570 7.57 4.62 0.61 5681 7.27 4.44 0.61 5738 6.91 4.21 0.61 5853...
Page 92 SPECIFICATIONS 5. CAPACITIES AND SELECTION DATA Capacities and Selection Data (Capacity Characteristics Charts) 42K (Cooling up to 5 indoor units series) Cooling Operation PERFORMANCE DATA OUTDOOR DB (°C) COMBINATION IDDB (°C) （%） SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF...
Page 93 5. CAPACITIES AND SELECTION DATA SPECIFICATIONS Capacities and Selection Data (Capacity Characteristics Charts) 42K (Cooling up to 5 indoor units series) Cooling Operation PERFORMANCE DATA OUTDOOR DB (°C) 48.8 COMBINATION IDDB IDWB (°C) (°C) （%） SHC SHF IPT SHC SHF IPT SHC SHF IPT SHC SHF IPT 8.25 5.03 0.61 5514 7.34 4.48 0.61 5624 7.05 4.30 0.61 5680 6.70 4.08 0.61 5794...
Page 94: Capacities And Selection Data (Capacity Characteristics Charts) 42K (Heating Up To 5 Indoor Units Series)
5. CAPACITIES AND SELECTION DATA SPECIFICATIONS 42K(Up to 5 indoor units series) Capacities and Selection Data (Capacity Characteristics Charts) 42K (Heating up to 5 indoor units series) HEATING PERFORMANCE DATA OUTDOOR WB(℃） COMBINATION INDOOR -20.5 -17.7 -8.3 DB(℃）（%） INPUT INPUT INPUT INPUT...
Page 95 5. CAPACITIES AND SELECTION DATA SPECIFICATIONS Capacities and Selection Data (Capacity Characteristics Charts) 42K (Heating up to 5 indoor units series) OUTDOOR WB(℃） COMBINATION INDOOR DB(℃）（%） INPUT INPUT INPUT INPUT INPUT INPUT 15.34 4984 15.73 5046 16.57 5234 17.40 5391 17.92 5498...
Page 96 SPECIFICATIONS 5. CAPACITIES AND SELECTION DATA Capacities and Selection Data (Capacity Characteristics Charts) 42K (Heating up to 5 indoor units series) OUTDOOR WB(℃） COMBINATION INDOOR -20.5 -17.7 -8.3 DB(℃）（%） INPUT INPUT INPUT INPUT INPUT INPUT INPUT INPUT 8.01 4164 9.01 4422 10.01...
Page 97 SPECIFICATIONS 5. CAPACITIES AND SELECTION DATA Capacities and Selection Data (Capacity Characteristics Charts) 42K (Heating up to 5 indoor units series) OUTDOOR WB(℃） COMBINATION INDOOR DB(℃）（%） INPUT INPUT INPUT INPUT INPUT INPUT 13.95 4659 14.31 4717 15.07 4892 15.82 5039 16.30 5139...
Page 98: Capacities And Selection Data (Piping Length Correction Factor)
5. CAPACITIES AND SELECTION DATA SPECIFICATIONS 5.2 Piping Length Correction Factor Capacities and Selection Data (Piping Length Correction Factor) The maximum allowable length of refrigerant piping, and the maximum allowable height difference between the outdoor and indoor units, are listed below. The shorter the refrigerant piping is, the better the performance will be.
Page 99 SPECIFICATIONS Capacities and Selection Data (Piping Length Correction Factor) Cooling 33ft. 49ft. 66ft. 82ft. 98ft. 115ft. 131ft. 148ft. 164ft. (10m) (15m) (20m) (25m) (30m) (35m) (40m) (45m) (50m) Model 18K/27K 0.96 0.95 0.93 0.91 0.89 0.87 0.86 0.84 0.96 0.95 0.93 0.91 0.89...
Page 100: Capacities And Selection Data (Correction Factors According To Defrosting Operation)
5. C C A A P P A A C C I I T T I I E E S S A A N N D D S S E E L L E E C C T T I I O O N N D D A A T T A A SPECIFICATIONS Capacities and Selection Data (Correction Factors According To Defrosting Operation) 5 5 .
Page 101: Installation
INSTALLATION General...
Page 102 INSTALLATION General...
Page 103 INSTALLATION General...
Page 104 INSTALLATION General...
Page 105 INSTALLATION General...
Page 106 INSTALLATION General...
Page 107 INSTALLATION General...
Page 108: Cassette
INSTALLATION Cassette local and national...
Page 109 INSTALLATION Cassette...
Page 110 INSTALLATION Cassette...
Page 111 INSTALLATION Cassette...
Page 112 INSTALLATION Cassette...
Page 113 INSTALLATION Cassette...
Page 114 INSTALLATION Cassette...
Page 115 INSTALLATION Cassette...
Page 116 INSTALLATION Cassette...
Page 117 INSTALLATION Cassette...
Page 118 INSTALLATION Cassette...
Page 119 INSTALLATION Cassette...
Page 120 INSTALLATION Cassette...
Page 121 INSTALLATION Cassette...
Page 122 INSTALLATION Cassette...
Page 123 INSTALLATION Cassette...
Page 124 INSTALLATION Cassette This product must be installed on a single dedicated electrical circuit. Circuit breaker protection must be installed in accordance with this manual. In moist and humid locations, an ELB type circuit breaker must be used. local and national When used, select...
Page 125: Ducted
INSTALLATION Ducted Composition of the Air Conditioner Indoor unit 9K/12K 18K/24K -+-- - -2 --=� -:::�M--t--3 '"'--'� - -5 l � D--t - - 4 = = =i= = �;;;;;;;;;;�=c=iJJl�- 6 '------ 7 �''-----5 '------ 6 '------ 7 1. Air inlet 2.
Page 126 INSTALLATION Ducted minute delay...
Page 127 INSTALLATION Trouble Shooting Ducted Trouble Shooting I A. CAUTION When drain water overflows from the indoor unit, stop the operation and contact your dealer. When you smell or see white smoke coming out of the unit, turn OFF the main power supply and contact your dealer.
Page 128: Air Filter
INSTALLATION Ducted Air Filter Filter Cleaning CAUTION Turn OFF the main power switch before taking filter. 1. Take Out the Filter Remove the fixed screws of the filter and pull the filter down along the rail of the flange as the figure below. 9K/12K 18K/24K Air filter...
Page 129 INSTALLATION Ducted local and national...
Page 130: Installation And Maintenance
INSTALLATION Installation and Maintenance Ducted 2. Tools and Instruments for Installation Number Tool Number Tool Number Tool Pipe cutter Churn drill Standard screwdriver Pipe expander Cross head screw-driver Vacuum pump Inner hexagon spanner Charge hose Knife or wire stripper Pipe bender Leveler Measuring tape Adjustable wrench...
Page 131 INSTALLATION Ducted...
Page 132 INSTALLATION Installation and Maintenance Ducted Example 3: Installation of one access hole 3.2 Installation 3.2.1 Suspension bolts (1) Consider the pipe direction, wiring and maintenance carefully, and choose the proper Maintenance Port 3 direction and location for installation. The same size as the Air Outlet + 12 (310) or more indoor unit (2) Install the suspension bolts as shown in Fig.
Page 133 INSTALLATION Installation and Maintenance Ducted 3.2.3 Install the indoor unit - - E C: � �E The installation of the indoor unit is shown in Fig. 3.2.3. -- ll) C')� Suspension bolts (4-M10 or W3/8) ( Field sup lied ) Nuts and Fig.
Page 134: Refrigerant Pipe
INSTALLATION Installation and Maintenance Ducted (2) As shown in Fig. 4.2, screw up the nuts with 2 <Example> (For MSP/HSP Type) spanners. Static pressure The valve for � �� .,...,_. � the a moun t of air ��...
Page 135 INSTALLATION Ducted...
Page 136: Electrical Wiring
INSTALLATION Installation and Maintenance Ducted 6. Electrical Wiring 6.1 General Check A. CAUTION • Before proceeding with electrical connections, make certain that power supply are as specified on the unit rating plate. See unit wiring label for proper field high and low-voltage wiring. Make all electrical connections in accordance with the NEC and any local codes or ordinances that may apply.
Page 137 INSTALLATION Ducted This product must be installed on a single dedicated electrical circuit. Circuit breaker protection must be installed in accordance with this manual. In moist and humid locations, an ELB type circuit breaker must be used. 9k-24k local and national codes When using an ELB, select...
Page 138 INSTALLATION Ducted...
Page 139: Wall Mount
Installation Instructions / INSTALLATION Installation diasram Wall Mount Distance from ceiling C.2 Clearances should be over 7.9in Distance from wall '\.!,. should be over 2in Distance from the wall Distance from the obstacle should be over 9.8ft. should be over 2in Distance from floor should be over 6 ft.
Page 140: Pre-Installation Checkpoints
INSTALLATION Wall Mount C.3 Pre-Installation Checkpoints 1. Ensure there are no obstacles near the air outlet and air can be easily blown to every corner. 2. Where piping and wall hole can be easily arranged. 3. Keep the required space from the unit to the ceiling and wall according to the installation diagram on previous page.
Page 141: Installation Of The Unit
INSTALLATION C. INSTALLATION OF THE UNIT Wall Mount Installation instructions / C.4 Install Mounting Plate Horizontal ruler Mounting plate position 1. Installing the Mounting Plate 1) Decide an installing location for the mounting plate Holder according to the indoor unit location and piping (for some models) ..
Page 142 INSTALLATION C. INSTALLATION OF THE UNIT Wall Mount C.4 Install Mounting Plate 8 in. or more to ceiling Indoor unit outline 2 in. or more ! 2 in. or more to wall i towall Pipe hole Pipe hole For 18K/ 24K Series Models, WIDTH: 37 5/ 38 in.
Page 143 INSTALLATION C. INSTALLATION OF THE UNIT Installation instructions / Wall Mount C.5 Drill Hole for Piping Table of Wall Hole Mounting size per Unit Size Size A Size A Size B SizeC Unit Model 1 3/8 in 1 3/8 in 1 3/4 in 2 3/4 in 7K/9K/12K Series...
Page 144 INSTALLATION C. INSTALLATION OF THE UNIT Wall Mount Fig. C.5 C.6 Piping Provisions 3. Piping Provision 1) Put the piping (liquid and gas pipe) and cables through the wall hole from outside or put them through from inside after indoor piping and cables connection is complete to connect to the outdoor unit. 2) Decide whether to cut the knockout plate in accordance with the piping direction.
Page 145: Indoor Unit Installation
Cracked Uneven Thickness INSTALLATION C. INSTALLATION OF THE UNIT Fig. C.6.4 Fig. C.6.5 Fig. C.7.1 Wall Mount C.7 Indoor Unit Installation 4. Indoor Unit Piping Installation 1) Hang the unit onto mounting plate Indoor unit installation (Fig. C.7.1). 2) In the A position, open the front panel as shown in Fig. C.7.2. 3) In the B position, open the screw covers as shown in Fig.
Page 146 INSTALLATION Installation instructions / C. INSTALLATION OF THE UNIT Wall Mount C.7 Indoor Unit Installation Indoor unit installation 6) Connect the piping Piping Connection: Small sealing cap Before unscrewing the big and the small sealing caps, press the small sealing cap with the finger until the exhaust noise stops, and then loosen ' '9----.
Page 147 INSTALLATION C. INSTALLATION OF THE UNIT Wall Mount C.7 Indoor Unit Installation ( Indoor unit installation The 18K/24K indoor unit include the switch tie-in accessory -..___ Gas valve only for 18K/24K indoor if required. It may switch 3/8" gas connection tube into 1/2" or 5/8" connection tube. ·.�...
Page 148 Installation instructions / INSTALLATION C. INSTALLATION OF THE UNIT Wall Mount C.7 Indoor Unit Installation Indoor unit installation 10) Pull the baffles as shown in Fig. C.5.20 Close the front shell as shown in Fig. C.5.21 . Then press the E position to fasten the front shell as shown in Fig.
Page 149: Electrical Shock Hazard
INSTALLATION E. ELECTRICAL Wall Mount Model Wire Diameter(AWG) Interconnecting Wire WARNING 7-9k 14-4 AWG 600V THHN 14-4 AWG 600V THHN 14-4 AWG 600V THHN Electrical Shock Hazard 14-4 AWG 600V THHN Always ensure power is Table E.1 disconnected before attempting NOTE: All communication wire must be stranded wire to connect wires.
Page 150 INSTALLATION E. ELECTRICAL Wall Mount E.1 Indoor Unit Wiring Connection Diagram Diagram is reference only, actual product terminals should be followed.
Page 151: Outdoor Unit
INSTALLATION Outdoor Unit...
Page 152 INSTALLATION Outdoor Unit...
Page 153 INSTALLATION Outdoor Unit...
Page 154 INSTALLATION Outdoor Unit 20 in.(500 mm) 10 in. (350 mm) over 10 in. (350 mm).
Page 155 INSTALLATION Outdoor Unit...
Page 156 INSTALLATION Outdoor Unit...
Page 157 INSTALLATION Outdoor Unit...
Page 158 INSTALLATION Outdoor Unit...
Page 159 INSTALLATION Outdoor Unit...
Page 160 INSTALLATION Outdoor Unit...
Page 161 INSTALLATION Outdoor Unit...
Page 162 INSTALLATION Outdoor Unit...
Page 163 INSTALLATION _lns t allat i on inst�uct i ons..,, Outdoor Unit Electrical Data Circuit Breaker Model Transmitting Power Supply (Capacity: Cable Size Nominal Sensitive Btu/h} Current (mA) 208/230V -/60Hz 4*14AWG 208/230V -/60Hz 4*14AWG 208/230V -/60Hz 4*14AWG 208/230V -/60Hz 4*14AWG Max. Running Current (A): REFER TO NAMEPLATE Notes, (1) Follow local codes and regulations when select field wires, and all the above are the minimum wire size.
Page 164 INSTALLATION Outdoor Unit...
Page 165: Operation
OPERATION Operation Range (Cooling and Heating) Temperature Cooling operation Heating operation Indoor temperature 90˚F 81˚F 70˚F 45˚F outdoor temperature 125˚F 75˚F 5˚F -13˚F Figure 301 *Optimum performance will be achieved within these operating temperature. If air conditioner is used outside of the above conditions, the protective device may trip and stop the appliance.
Page 166: Remote Control
OPERATION Remote Control Figure 302...
Page 167 OPERATION Remote Control...
Page 168 OPERATION Remote Control...
Page 169 OPERATION Remote Control...
Page 170 OPERATION Remote Control...
Page 171 OPERATION Remote Control...
Page 172 OPERATION Remote Control...
Page 173 OPERATION Remote Control...
Page 174 OPERATION Remote Control...
Page 175 OPERATION Remote Control...
Page 176: Unit Function
OPERATION 1. FUNCTION AND CONTROL Unit Function 1. Function and Control 1.1 Control mode 1) Cooling Anti-freeze Protection To prevent freezing caused by low temperature of indoor evaporator, the air conditioner will implement real-time detection over the indoor coil temperature. If the indoor coil temperature is too low, the compressor will be prohibited from increasing or decreasing the frequency and even shut down automatically.
Page 177: Start-Up Protection
OPERATION 1. FUNCTION AND CONTROL Unit Function b. Mode conflict The operating mode of outdoor unit is decided by the operating mode of the indoor unit booted first. Indoor unit subsequently booted will firstly determine whether it’s own mode is in conflict with the outdoor mode.
Page 178 OPERATION 1. FUNCTION AND CONTROL Unit Function 1.2 Control Logic Description Contents 1) Sensors in HVAC Systems 1.1 Discharge temperature sensor 1.2 Suction sensor 1.3 Outdoor coil temperature sensor 1.4 Outdoor ambient temperature sensor 1.5 Defrosting sensor 1.6 Gas tube sensor 1.7 Liquid tube sensor 2) Compressor Frequency Control 2.1 Compressor frequency control...
Page 179 OPERATION 1. FUNCTION AND CONTROL Unit Function 1) Sensors in HVAC Systems Figure 303 a. Discharge temperature sensor It is designed to detect and control the temperature at the compressor discharge port. When the discharge temperature is too high, the compressor will run at low frequency or shut down.
Page 180 OPERATION 1. FUNCTION AND CONTROL Unit Function c. Outdoor coil temperature sensor It is designed to detect the temperature in the middle of the outdoor condenser. When the temperature is too high, the compressor will run at low frequency or shut down. Additionally, it is used to: 1.
Page 181: Electronic Expansion Valve Control
OPERATION 1. FUNCTION AND CONTROL Unit Function 3) Electronic Expansion Valve Control a. Opening control during powering on Reset: Each time the power is turned on or the compressor is turned off, the electronic expansion valves close to the minimum opening and then open to the opening in standby mode in turn.
Page 182: Defrost Control
OPERATION 1. FUNCTION AND CONTROL Unit Function b. Speed control in heating mode In heating mode, the lower the outdoor ambient temperature, the higher the initial outdoor air speed; different initial speed gears are set according to the different outdoor ambient temperatures.
Page 183: Unit Function
1. FUNCTION AND CONTROL OPERATION Unit Function Anti-freezing during Category Exhaust Overload cooling Overload heating cooling Frequency limiting Trl1 Thl1 temperature Frequency reduction Trl2 Thl2 temperature Shutdown Td13 Trl3 Thl3 temperature Indoor unit Frequency limiting − Frequency limiting − shutdown shielding; Frequency limiting −...
Page 184: Field Settings
2. FIELD SETTING OPERATION 2.1 Field setting Field Settings DIP setting DIP Switch Setting of Outdoor Unit TURN ON all power sources before setting. Mark of " " indicates the position of DIP switches. Capacity: silence 1. Force defrosting mode By default setting is OFF.
Page 185 OPERATION 8. FIELD SETTING Field Settings Step 3: Switch on the machine power. Step 4: Switch S4-2 to ON position on the checker board, the outdoor unit starts, and the current frequency value is displayed on the LED digital tube of the checker board. Step 5: The frequency value will keep changing until "CLOS"...
Page 186 OPERATION 2. FIELD SETTING Field Settings Running Parameter Query For up to 3 IDUs/ up to 4 IDUs/ up to 5 IDUs series, outdoor running parameters can be checked by 7 segment display. ● ● ● Decrease Select Increase There are 3 buttons on the digital display board: 1) Select button: Select to display outdoor/indoor unit parameter.
Page 187 OPERATION 2. FIELD SETTING Field Settings Parameter Parameter Descriptions Descriptions Code Code Unit C fault codes Unit E fault codes Unit C valve actual opening Unit E valve actual opening Unit C liquid pipe temperature Unit E liquid pipe temperature Unit C gas pipe temperature Unit E gas pipe temperature Unit C coil temperature...
Page 188 OPERATION 2. FIELD SETTING Field Settings 2.2 Test Run Test run should be performed after refrigerant piping, drain, wiring, etc. have been finished. CAUTION The heat pump air conditioner is provided with a crankcase heater. If ambient temperature is below 32°F(0°C), check to ensure that the switch on the main power source has been ON for more than 6 hours ahead of power on preheating, otherwise it might damage the compressor! o not operate the system until all the check points have been cleared.
Page 189: Maintenance
MAINTENANCE...
Page 190 MAINTENANCE The following is a deep cleaning and must be completed by a professional. Usera are strictly forbidden operate privately, otherwise they will be at their own risk. Cut off the power supply by moving the power switch In the dlnictlon of the arrow.
Page 191 MAINTENANCE L'.h The followlng 18 a deep cleanlng and must be completed by a professlonal. L'.h Users ara strlctly forbidden to operate prlvately, otherwise they wlll be at their own risk. Remove the acrews of the air duct. (G poaltlon and H poaltlon) screws.
Page 192: Troubleshooting
TROUBLESHOOTING Outdoor Unit Basic Troubleshooting Troubleshooting Possible Reason of Abnormality How to Deal With 1. Power supply failure; 1. Check power supply circuit; 2. Trip of breaker or blown fuse℉ 2. Measure insulation resistance to ground to see if there is 3.
Page 193: Diagnostic Codes _ Intro
TROUBLESHOOTING 3. TROUBLESHOOTING Outdoor Unit Diagnostic Codes _ Intro How to check fault codes Troubleshooting according to fault codes When the air conditioner failure occurs, the fault code will display on control board, or maintenance board. Outdoor unit Fault code displayed by LED lamps on outdoor main control board. There are 3 LED lamps on control board, LED1, LED2 and LED3.
Page 194 TROUBLESHOOTING Outdoor Unit 3. TROUBLESHOOTING Diagnostic Codes _ Intro LED3: Ten’s place LED4: Unit’s place LED5: Drive failure indicator Main Control Board 36K/42K For example, outdoor main control fault 32: For example, outdoor drive fault 32: Fault codes also can be checked by 7 segment display on the maintenance board. Fault codes will display directly when fault occurs.
Page 195: Outdoor Unit
TROUBLESHOOTING Outdoor Unit Diagnostic Codes _Main PCB Fault Fault description Possible reasons for abnormality How to deal with code Outdoor ambient 1. The outdoor ambient temperature sensor is connected 1. Reconnect the outdoor ambient temperature sensor. temperature sensor loosely. 2. Replace the outdoor ambient temperature sensor fault 2.
Page 196 TROUBLESHOOTING Outdoor Unit Diagnostic Codes _Main PCB Fault Fault description Possible reasons for abnormality How to deal with code AC voltage is 1. The AC voltage>275V or <160V; 1. Normal protection, please check the supply power; abnormal 2. The AC voltage of sampling circuit on the driver board is 2.
Page 197 TROUBLESHOOTING Outdoor Unit Diagnostic Codes _Main PCB Fault Fault description Possible reasons for abnormality How to deal with code Discharge 1. The refrigerant of the unit is low. 1. Check for refrigerant leak. temperature is too 3. EEV has malfunctioned. 2.
Page 198 TROUBLESHOOTING Outdoor Unit Diagnostic Codes _Main PCB Fault Fault description Possible reasons for abnormality How to deal with code NOTE 4: Over load in heating mode The refrigerant is excessive. Discharge the refrigerant, and recharge the refrigerant referring to the nameplate and the installation section of this manual.
Page 199: Diagnostic Codes _Driver Faults (18K)
TROUBLESHOOTING Outdoor Unit Diagnostic Codes _Driver Faults (18k) Fault Fault description Possible reasons for abnormality How to deal with code Inverter DC voltage overload fault 1. Power supply input is too high or too low; 1. Check the power supply; 2.
Page 200 TROUBLESHOOTING Outdoor Unit Diagnostic Codes _Driver Faults(18k) Fault Fault description Possible reasons for abnormality How to deal with code Compressor drive 1. System overload, phase current is too high; 1. Check if the system is normal; Q axis current control error 2.
Page 201: Diagnostic Codes _Driver Faults (27K, 36K, 42K)
TROUBLESHOOTING Outdoor Unit Diagnostic Codes _Driver Faults (27k, 36k, 42k) Fault Fault description Possible reasons for abnormality How to deal with code Inverter DC voltage overload fault 1. Power supply input is too high or too low; 1. Check the power supply; 2.
Page 202 TROUBLESHOOTING Outdoor Unit Diagnostic Codes _Driver Faults (27k, 36k, 42k) Fault Fault description Possible reasons for abnormality How to deal with code Inverter software over-current 1. The fan motor system overloads; 1. Change the fan motor; 2. The control board fails; 2.
Page 203 TROUBLESHOOTING Outdoor Unit Diagnostic Codes _Driver Faults Fault Fault description Possible reasons for abnormality How to deal with code Effective value protection of fan phase current 1. Abnormal fan system 1. Check if the outdoor fan is abnormal 2. Abnormal control board 2.
Page 204: Indoor Unit - Wall Mount
TROUBLESHOOTING Indoor Unit - Wall Mount Diagnostic Codes The indoor display board will show the error code automatically when the unit has the following trouble: Refer to the remote controller which the sleep key can set into 4 different combination ways , when using to check the error codes only takes effect for pressing the sleep key 10 times in ten seconds instead of 4 times.
Page 205: Unit Does Not Run
TROUBLESHOOTING Indoor Wall Mount 6.7.Diagnosis and Solution Unit Does Not Run Switch on the power supply Does it receive the Is the remote Does the screen remote controller controller display normally? signal? setting right? Is the fuse (5A/250V) burn? Check the code Is the remote controller in good Replace the batteries...
Page 206: Error Code 39-Dc Fan
TROUBLESHOOTING Indoor control board is fault Replace it. Indoor Wall Mount Error Code 39-DC Fan Error code 39 Indoor fan motor trouble DC Fan Set the air conditioner operate in fan mode Does fan motor Check the connector of stop following the Is indoor fan motor indoor motor connected remote controller...
Page 207 TROUBLESHOOTING Indoor Wallmount Error Code 36 E36 Error Does communica�on wiring meet speciﬁca�ons? Replace wiring 14 gauge stranded wiring rated as required. for 600v Are there any junc�on boxes or Replace wiring splices in the wiring except for as required. code required disconnects? Is Wiring connected to the proper terminals?
Page 208 TROUBLESHOOTING Indoor Wallmount Error Code 36 Figure 509...
Page 209: Blank Display/ Indoor Micro Switch
TROUBLESHOOTING Indoor Wallmount Blank Display/ Indoor Micro Switch If the Display is blank, check to see if the door is properly closed. If the door is properly closed, confirm that you have proper line voltage to the indoor unit. If the indoor unit door is not properly closed, or if the door micro switch has malfunctioned the display may be blank. See Figure 717 When the micro-switch is not engaged, and the power button is depressed, there will be no display and the system will not operate or respond in any way.
Page 210: Blank Display/Indoor Unit Door Micro Switch
TROUBLESHOOTING Indoor Wallmount Blank Display/Indoor Unit Door Micro Switch When the Timer On/Clock button is pressed you will see a temperature on the display, but still no system operation. After a few seconds, the display will drop the temperature leaving just the Wi-Fi and Timer icons. Still no indoor unit operation. See Figure 719. Fig.
Page 211: Indoor Unit Cassette And Ducted
TROUBLESHOOTING Indoor Unit Cassette and Ducted Diagnostic Codes Troubleshooting according to fault codes When the air conditioner failure occurs, the fault code will display on control board, wired controller or display panel. How to check fault codes Indoor unit (1)Error codes indicated by wire remote controller (see figure below) ERROR INDICATOR ERROR CODE When the air conditioner malfunctions,...
Page 212: Fault Code
TROUBLESHOOTING Indoor Unit Cassette and Ducted Diagnostic Codes (2) Fault codes indicated by display panel(36K/48K) Display panel Fault code (3) Fault codes indicated by LED lamps on display panel (9K/12K) Lamp RUN (LED2, Red) and Lamp DEFROST (LED5, Green) flash. Lamp RUN displays fault code represented by 2- digit number, and lamp DEFROST displays fault code represented by single digit number (as shown fig.
Page 213 TROUBLESHOOTING Indoor Unit Cassette and Ducted Diagnostic Codes Fault Fault description Possible reasons for abnormality How to deal with code Humidity sensor failure 1. The cable of the humidity sensor connect loose. 1. Reconnect the cable of the humidity sensor. 2.
Page 214: Components Testing
COMPONENTS TESTING Outdoor Unit Test system flow Cooling mode Test system pressure. The pressure on the Is the low pressure high side. normal at service part ? Recharge refrigerant after air purging with If the pressure is The pressure on the the vacuum close to static low side.
Page 215 COMPONENTS TESTING 4.2 Check Parts Unit Outdoor Unit Key components DC Motor (Outdoor unit) Compressor EEV coil 4-Way valve coil Pressure switch Inductance Fuse 1) DC Motor (Outdoor unit) External drive type Use the multimeter to test resistance between two terminals Test condition Normal test results Deviation Range Model...
Page 216 COMPONENTS TESTING Outdoor Unit Use the multimeter to test resistance between two terminals. Test results: Test condition Model Normal test results Deviation Range (Ambient temperature) U-V: 1.065Ω 68℉(20℃) U-W: 1.065Ω ±7% V-W: 1.065Ω U-V: 0.630Ω 68℉(20℃) U-W: 0.630Ω ±7% V-W: 0.630Ω U-V：0.426Ω...
Page 217 COMPONENTS TESTING Outdoor Unit 4) 4-Way valve coil Use the multimeter to test resistance between two terminals. Test results: Test condition Model Normal test results Deviation Range (Ambient temperature) 18K/27K/36K/42K 77℉(25℃) 2085Ω ±10% 5) Pressure switch Normally closed switch detection: With no pressure in the pipeline, you can turn a multimeter to the ohm range and connect the red and black probes with a pin (lead) respectively to detect whether the switch is in the "ON"...
Page 218: Cassette- Ducted
COMPONENTS TESTING Cassette- Ducted Key components Key components DC Motor (Indoor unit) Water Pump Water Switch Pressure Switch Step motor 1 1 . . D D C C M M o o t t o o r r ( ( I I n n d d o o o o r r u u n n i i t t ) ) a.
Page 219 COMPONENTS TESTING Cassette- Ducted 8. Pressure switch The pressure switch is divided into normally closed and normally open types (under atmospheric pressure), such as YK-4.0/3.4 is normally closed, and YK-2.85/3.6 and YK-0.05/0.15 are normally open. Normally closed switch detection: With no pressure in the pipeline, you can turn a multimeter to the ohm range and connect the red and black probes with a pin (lead) respectively to detect whether the switch is in the "ON"...
Page 220: Indoor Unit Main Pcb Terminal Id (No A2L Sensor Connection)
COMPONENTS TESTING Indoor Unit Main PCB Terminal ID (No A2L Sensor Connection) Evaporator Coil Indoor Ambient Vertical Louver Indoor Fan Door Safety Horizontal Louver Auto Start Switch Temp Sensor Temp Sensor Motor (X842) (X821) Switch (X412) (X823) (SW 101) (X413) (X405) L2 In/Out switch input...
Page 221: Indoor Fan Motor
COMPONENTS TESTING Indoor Fan Motor Power Check: 1. Turn unit on. WARNING 2. Check indoor fan connector on main PCB. There are 5 wires: ELECTRIC SHOCK HAZARD Voltage for Power (Red) to Ground (Black) = 310 VDC Turn off electric power before service or Motor Return Voltage (White) to Ground (Black) = 15 VDC installation.
Page 222: Component Testing
COMPONENT TESTING Reversing Valve A reversing valve is a component of a heat pump that changes the direction of refrigerant flow, allowing the system to function in both heating and cooling WARNING modes. It consists of a pressure-operated, main valve and a pilot valve actuated by ELECTRIC SHOCK HAZARD a solenoid plunger.
Page 223: Outdoor Unit - Main Pcb Id
4.2 Control Board Picture COMPONENTS TESTING Main control board Outdoor Unit - Main PCB ID FPHMR18A3D Description Description Compressor U Electric Heating Belt Base Heater Compressor V Communication Signal to Indoor Compressor W DC Motor AC Power Lin Electronic Expansion Valve A AC Power Nin Electronic Expansion Valve B Earth...
Page 224: Main Control Board
COMPONENTS TESTING Main control board Outdoor Unit - Main PCB ID FPHMR27A3D 15 14 13 12 11 Description Description Gas B/ Liquid B / Gas A/ Liquid A Sensor Reactor L1 Discharge/defrost/coil/suction/outdoor sensor Reactor L2 AC Power Nin Base Heater AC Power Lin Electric Heating Belt 4-way Valve...
Page 225: Fphmr36A3D
COMPONENTS TESTING Main control board Outdoor Unit - Main PCB ID FPHMR36A3D, FPHMR42A3D 14 13 17 16 Description Description Overheat protector Reactor L2 Reactor L1 GasB/LiqB/GasA/LiqA sensor Discharge/defrost/coil/suction/ N-IN outdoor sensor Base heater L-IN SI-(A-D) Electric heating belt 4-way valve H-press EEPROM Electronic expansion value D...
Page 226: R-454B Sealed System Repair
3. Refrigerant Cycle R-454B SEALED SYSTEM REPAIR Refrigerant Cycle 18k List of components Two-rotor compressor 11 Electronic expansion valve Suction temperature sensor 12 Gas tube temperature sensor Discharge temperature sensor 13 Strainer Accumulator 14 Stop valve 4-Way valve 15 Liquid tube temperature sensor Ambient temperature sensor 16 Stop valve(Needle) Outdoor heat exchanger...
Page 227: Refrigerant Cycle 27K
3. REFRIGERANT CYCLE R-454B SEALED SYSTEM REPAIR Refrigerant Cycle 27k List of components Two-rotor compressor 11 Electronic expansion valve Suction temperature sensor 12 Gas tube temperature sensor Discharge temperature sensor 13 Strainer Accumulator 14 Stop valve 4-Way valve 15 Liquid tube temperature sensor Ambient temperature sensor 16 Stop valve(Needle) Outdoor heat exchanger...
Page 228: Refrigerant Cycle 36K
3. REFRIGERANT CYCLE R-454B SEALED SYSTEM REPAIR Refrigerant Cycle 36k List of components Two-rotor compressor 11 Electronic expansion valve Suction temperature sensor 12 Gas tube temperature sensor Discharge temperature sensor 13 Strainer Accumulator 14 Stop valve 4-Way valve 15 Liquid tube temperature sensor Ambient temperature sensor 16 Stop valve(Needle) Outdoor heat exchanger...
Page 229: Refrigerant Cycle 42K
R-454B SEALED SYSTEM REPAIR 3. REFRIGERANT CYCLE Refrigerant Cycle 42k List of components Two-rotor compressor 11 Electronic expansion valve Suction temperature sensor 12 Gas tube temperature sensor Discharge temperature sensor 13 Strainer Accumulator 14 Stop valve 4-Way valve 15 Liquid tube temperature sensor Ambient temperature sensor 16 Stop valve(Needle) Outdoor heat exchanger...
Page 230: General Information
R-454B SEALED SYSTEM REPAIR General Information WARNING: Electrical Shock Hazard Disconnect all power to the unit before starting maintenance. All electrical connections and wiring MUST be installed by a qualiﬁed electrician and conform to all codes which have jurisdiction. Failure to do so can result in property damage, severe electrical shock or death.
Page 231 R-454B SEALED SYSTEM REPAIR General Information Warning: No ignition sources: No person carrying out work in relation to a REFRIGERATING SYSTEM which involves exposing any pipe work shall use any sources of ignition in such a manner that it may lead to the risk of fire or explosion. All possible ignition sources, including cigarette smoking, should be kept sufficiently far away from the site of installation, repairing, removing and disposal, during which refrigerant can possibly be released to the surrounding space.
Page 232: Required Equipment
R-454B SEALED SYSTEM REPAIR Required Equipment • Recovery access tool. • Purge hose fittings Pinch off and opening tools • ABC Fire Extinguisher Recovery Machine Vaccum Pump Nitrogen Guage Manifold Vaccum Guage Nitrogen Regulator Recovery access tool Pinch off and opening tools Purge hose fittings Process tube adapter kit...
Page 233: Refrigerant Removal, Recovery, And Evacuation
R-454B SEALED SYSTEM REPAIR Refrigerant Removal, Recovery, and Evacuation NOTE: When accessing the refrigerant in the system to make repairs or for any other purpose, conventional procedures shall be used. However, for FLAMMABLE REFRIGERANTS (R-454B is classified in the A2L group for mildly flammable refrigerants) it is important that best practice is followed since flammability is a consideration.
Page 234: Component Replacement/Brazing
R-454B SEALED SYSTEM REPAIR Component Replacement/Brazing Warning: • Ensure sufficient ventilation at the repair place. Warning: Presence of fire extinguisher. If any hot work is to be conducted on the refrigerating equipment or any associated parts, have a ABC class fire extinguisher available to hand.
Page 235: Refrigerant Charging
R-454B SEALED SYSTEM REPAIRS Refrigerant Charging WARNING: Electrical Shock Hazard Disconnect all power to the unit before starting maintenance. All electrical connections and wiring MUST be installed by a qualiﬁed electrician and conform to all codes which have jurisdiction. Failure to do so can result in property damage, severe electrical shock or death. WARNING: This Product uses R-32 Refrigerant Do not use means to accelerate the defrosting process or to clean, other than those recommended by the manufacturer.
Page 236 Triple Evacuation Friedrich requires all installations are Leak Checked and Evacuated in accordance to the “triple evacuation” process. This process promotes a dry tight refrigeration system before opening the service valves. It recommended that a single port refrigeration manifold and hoses rated over 31.5 psi be used.
Page 237: Compressor Replacement
R-454B SEALED SYSTEM REPAIRS Compressor Replacement 1. Be certain to perform all necessary electrical and refrigeration tests to be sure the compressor is actually defective before replacing. 2. Recover all refrigerant from the system though the process tubes. Refer to Refrigerant Removal, Recovery, and Evacuation Section of this WARNING...
Page 238: Replace The Reversing Valve
R-454B SEALED SYSTEM REPAIR Replace The Reversing Valve WARNING WARNING HIGH PRESSURE HAZARD EXPLOSION HAZARD Sealed Refrigeration System contains refrigerant The use of nitrogen requires a pressure and oil under high pressure. regulator. Follow all safety procedures and wear protective safety clothing etc. Proper safety procedures must be followed, and PPE must be utilized Failure to follow proper safety procedures...
Page 239: Wiring Diagrams
WIRING DIAGRAMS Indoor Unit Wall Mount FAHFW09A3D, FAHFW12A3D, FAHFW18A3D, FAHFW24A3D (No A2L sensor connection) Figure 801...
Page 240: Fahfw09A3D, Fahfw12A3D, Fahfw18A3D, Fahfw24A3D (With A2L Sensor Connection)
WIRING DIAGRAMS Indoor Unit Wall Mount FAHFW09A3D, FAHFW12A3D, FAHFW18A3D, FAHFW24A3D (With A2L sensor connection) Figure 802...
Page 241: Ducted 9K &12K
4. Wiring Diagram WIRING DIAGRAMS 4.1 Electrical Wiring Diagrams Indoor Unit Indoor unit Ducted 9k &12k Duct type 9K/12K Electric wiring diagram 2416593, A USE COPPER SUPPLY WIRES Remark: Dashed parts are not available in some models. Details see the table below. Wired Fresh ON/OFF...
Page 242: Ducted 18K &24K
WIRING DIAGRAMS 4. WIRING DIAGRAM Indoor Unit Ducted 18k &24k 18K/24K/36K Electric wiring diagram 2414390, A USE COPPER SUPPLY WIRES Remark: Dashed parts are not available in some models. Details see the table below. Wired Fresh ON/OFF Pump Humidity Wifi Nanoe Display remote...
Page 243: Wiring Diagram
WIRING DIAGRAMS 4. WIRING DIAGRAM Indoor Unit Cassette 9k -24k Cassette type 9K~36K Electric wiring diagram 2415798, A Remark: Dashed parts are not available in some models. Details see the table below. Display Display Wire Fresh air Refrigerant WIFI Humdity board board Model...
Page 244: Outdoor Unit, Fphmr18A3D
WIRING DIAGRAMS Figure 806 Outdoor Unit, FPHMR18A3D...
Page 245: Outdoor Unit, Fphmr24A3D
WIRING DIAGRAMS Figure 807 Outdoor Unit, FPHMR27A3D 1(L) 2(N) 4(SI) 1(L) 2(N) 4(SI) 1(L) 2(N) 9 10 9 10 4(SI)
Page 246: Outdoor Unit Fphmr36A3D
WIRING DIAGRAMS Figure 808 Outdoor Unit FPHMR36A3D...
Page 247 WIRING DIAGRAMS Figure 809 Outdoor Unit FPHMR42A3D...
Page 248: Appendix
APPENDIX Interactive Parts Viewer All Friedrich Service Parts can be found on our online interactive parts viewer. Please click on the link below: Interactive Parts Viewer For Further Assistance contact Friedrich customer service at (1-800-541-6645). Limited Warranty Current warranty information can be obtained by referring to...
Page 249: Sensor Parameter
4. CHECKING COMPONENTS APPENDIX 4.3 Sensor Parameter Compressor Discharge Temp Sensor Resistance Values 1. THE PARAMETER OF OUTDOOR COMPRESSOR DISCHARGE TEMPERATURE SENSOR: =187.25K±6.3%；R =3.77K±2.5K；B0/100=3979K±1%）（R T T [ [ ℃ ℃ ] ] R R m m i i n n [ [ K K Ω Ω ] ] R R n n o o m m [ [ K K Ω...
Page 250: Checking Components
APPENDIX 4. CHECKING COMPONENTS Compressor Discharge Temp Sensor Resistance Values T T [ [ ℃ ℃ ] ] R R m m i i n n [ [ K K Ω Ω ] ] R R n n o o m m [ [ K K Ω Ω ] ] R R m m a a x x [ [ K K Ω...
Page 251 APPENDIX 4. CHECKING COMPONENTS Compressor Discharge Temp Sensor Resistance Values R R m m i i n n [ [ K K Ω Ω ] ] R R n n o o m m [ [ K K Ω Ω ] ] R R m m a a x x [ [ K K Ω...
Page 252 APPENDIX 4. CHECKING COMPONENTS Coil and Ambient Temp Sensor Resistance Values 2. THE PARAMETER OF THE OTHER SENSOR： =15K±2%；B0/100=3450K±2%) R R m m i i n n [ [ K K Ω Ω ] ] R R n n o o m m [ [ K K Ω Ω ] ] R R m m a a x x [ [ K K Ω...
Page 253 APPENDIX 4. CHECKING COMPONENTS Coil and Ambient Temp Sensor Resistance Values R R m m i i n n [ [ K K Ω Ω ] ] R R n n o o m m [ [ K K Ω Ω ] ] R R m m a a x x [ [ K K Ω...
Page 254 APPENDIX 4. CHECKING COMPONENTS Coil and Ambient Temp Sensor Resistance Values T T [ [ ℃ ℃ ] ] R R m m i i n n [ [ K K Ω Ω ] ] R R n n o o m m [ [ K K Ω Ω ] ] R R m m a a x x [ [ K K Ω...
Page 255 FPWC1 Optional wired wall controller for Floating Air Select single zone and Floating Air Pro, single and multizone models. ® Does not work with FPHSW36A3B at this time. Please check with your Friedrich representative for options. Cable length = 24 ft (8m) ®...
Page 256: Friedrich Authorized Parts Depots
APPENDIX Friedrich Authorized Parts Depots United Products Distributors Inc. The Gabbert Company Reeve Air Conditioning, Inc. 4030A Benson Ave 2501 South Park Road 6868 Ardmore Hallandale, Florida 33009 Halethorpe, MD 21227 Houston, Texas 77054 888-907-9675 954-962-0252 c.businsky@updinc.com 713-747-4110 800-962-3383 800-458-4110 Shivani Refigeration &...

This manual is also suitable for:

Floating air pro fphmr27a3d Floating air pro fphmr36a3d Floating air pro fphmr42a3d Floating air pro fahmw07a3d Floating air pro fahfw09a3d Floating air pro fahfw12a3d ... Show all

Friedrich Floating Air Pro FPHMR18A3D Service Manual

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Friedrich Floating Air Pro FPHMR18A3D

Summary of Contents for Friedrich Floating Air Pro FPHMR18A3D

This manual is also suitable for:
