Friedrich FPHFC36A3B Wi-Fi Service & Parts Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Floating Air Pro Single- Zone
Cassette and Ducted
1
Type
Outdoor
Condensor
Outdoor
Condensor
Outdoor
Condensor
Outdoor
Condensor
Outdoor
Condensor
Indoor
Cassette
Indoor
Cassette
Indoor
Cassette
Indoor
Cassette
Indoor
Cassette
Indoor
Ducted
Indoor
Ducted
Indoor
Ducted
Indoor
Ducted
Indoor
Ducted
Indoor
Accessory
Indoor
Accessory
Indoor
Accessory
9261402_02
Model
Model Revision
FPHFR9A3A
FPHFR12A3A
FPHFR18A3A
FPHFR24A3A
FPHFR36A3A
FPHFC09A3A
FPHFC09A3B Wi-Fi
FPHFC12A3A
FPHFC12A3B Wi-Fi
FPHFC18A3A
FPHFC18A3B Wi-Fi
FPHFC24A3A
FPHFC24A3B Wi-Fi
FPHFC36A3A
FPHFC36A3B Wi-Fi
FPHFD09A3A
FPHFD12A3A
FPHFD18A3A
FPHFD24A3A
FPHFD36A3A
FPCG0912
FPWC1
FPCG182436
