Spectrum Digital EVM320LF2407A Technical Reference page 43

Spectrum Digital, Inc
/* equations */
La0 = ( Dac & A0 )
| ( !Dac & La0 );
La1 = ( Dac & A1 )
| ( !Dac & La1 );
RsEn = ( SwReset | TrgReset | HostReset | PowerOnReset);
Rs = 1;
Dac_Cs = Dac;
/* Part assignment */
putpart("g16v8", "504884b",
_, Dac, Xfer, SwReset, TrgReset, A0, A1, HostReset, PowerOnReset, GND,
_, _, La0, La1, _, Dac_Cs, Rs, RsEn, _, VCC );
#ifdef TEST_VEC
/* Test Vectors */
test( Reset, TrgReset, Dac, A1, A0 => La0, La1 )
{
/* Put in known state */
( 1, 1, 0, 0, 0 => 0, 0 );
/* Test Reset */
( 1, 0, 1, 0, 0 => 0, 0 ); /* Onboard Reset
( 0, 1, 1, 0, 0 => 0, 0 ); /* Target Reset
/* Test Latch */
( 1, 1, 1, 0, 0 => 0, 0 ); /* Latch closed
( 1, 1, 1, 1, 1 => 0, 0 ); /* Holding old value
( 1, 1, 0, 1, 1 => 1, 1 ); /* Open Latch
( 1, 1, 1, 1, 1 => 1, 1 ); /* Close latch
( 1, 1, 1, 0, 0 => 1, 1 ); /* Holding old value
}
#endif
}
