Kohler Symbol 18470T-4 Installation Instructions

INSTALLATION INSTRUCTIONS
安装说明书
安装之前
所有的资料是按最新出版的产品资料编写而成。科勒
公司保留任何时候不经通知即可改变产品特性、包装
或产品可供类型的权利。
说明书包括重要的安装、保养及清洁方面的内容，请
把这些资料交给用户阅读。
注意事项：
1.一定要先彻底冲洗供水管以清除管道中的杂质。
2.在说明书所指示的恰当时候，拿掉阀芯保护套。
3.参 照 18470T-4安 装 尺 寸 安 装 阀 体 880T， 参 照
18471T-4安装尺寸安装阀体882T。
安装尺寸
18470T-4
113
1071633-2-A
18470T-4
18471T-4
装修好的墙面
The finished wall
38~55
Single Lever Recessed Trim
入墙式面板
入墙式切换面板
BEFORE YOU BEGIN
All information is based on the latest product
information available at the time of publication. Kohler
Co. reserves the right to make changes in product
characteristics, packaging, or availability at any time
without notice.
Please leave these instructions for the consumer.
They contain important information.
Notes:
1. Flush the water supply pipes thoroughly to remove
debris.
2. Do not remove the plastic guard from the valve
body until instructed to.
3. Install valve 880T according to the rough-in
dimensions of 18470T-4, Install valve 882T according
to the rough-in dimensions of 18471T-4.
ROUGH-IN DIMENSIONS
113
YMBOL
18471T-4
装修好的墙面
The finished wall
38~55
星珀
1
