TURBO HD
F1T Series Turret Camera
User Manual
UD02669B
User Manual
Thank you for purchasing our product. If there are any
questions, or requests, do not hesitate to contact the
dealer.
This manual applies to the models below:
Type
Type I
Camera
Type II
Camera
This manual may contain several technically incorrect
places or printing errors. The content is subject to
change without notice, and the updates will be added
to the new version of this manual. We will readily
improve or update the products or procedures
described in the manual.
Model
DS-2CE56F1T-IT1
DS-2CE56F1T-IT3
DS-2CE56F1T-ITP
DS-2CE56F1T-ITM
020000106812
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for HIKVISION DS-2CE56F1T-ITP
Summary of Contents for HIKVISION DS-2CE56F1T-ITP
- Page 1 This manual applies to the models below: Type Model DS-2CE56F1T-IT1 Type I DS-2CE56F1T-IT3 Camera DS-2CE56F1T-ITP Type II DS-2CE56F1T-ITM Camera This manual may contain several technically incorrect places or printing errors. The content is subject to change without notice, and the updates will be added to the new version of this manual.
-
Page 2: Regulatory Information
Privacy Notice Surveillance laws vary by jurisdiction. Check all relevant laws in your jurisdiction before using all this product for surveillance purpose to ensure that your use of this product conforms. Regulatory Information FCC Information FCC compliance: This equipment has been tested and found to comply with the limits for a digital device, pursuant to part 15 of the FCC Rules. - Page 3 Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into “Warnings” and “Cautions” Warnings: Serious injury or death may occur if any of the warnings are neglected.
-
Page 4: Product Features
Do not aim the camera at the sun or extra bright places. Blooming or smearing may occur otherwise (which is not a malfunction), and affect the endurance of sensor at the same time. The sensor may be burned out by a laser beam, so when any laser equipment is in using, make sure that the surface of sensor will not be exposed to the laser beam. -
Page 5: Installation
1.1.2 Overview of Type II Camera Clip Plate Mounting Base Trim Ring Enclosure Camera Video Cable DC 12V Power Cord Figure 1-2 Overview of Type II Camera 2 Installation Before you start: Make sure that the device in the package is in good condition and all the assembly parts are included. - Page 6 screw holes and the cable hole in the ceiling according to the drill template. Screw Hole Cable Hole Figure 2-2 Drill Template 4. Fix the mounting base to the ceiling with the screws. Figure 2-3 Fix the Mounting Base and Camera 5.
- Page 7 Clip Plate Notch Figure 2-6 Disassemble the Camera 2. Pry the mounting base to remove the mounting base with the camera body. 3. Attach the drill template (supplied) to the place where you want to fix the camera, and then drill the screw holes and the cable hole in the ceiling according to the drill template.
- Page 8 Pan Position Range [0°to 360°] Tilt Position Range Rotation Position Range [0°to 75°] [0° to 360°] Figure 2-10 3-axis Adjustment 2.2.2 Ceiling Mounting with Junction Box You need to purchase a junction box separately if you adopt celling mounting with junction box. Steps: 1.
-
Page 9: Menu Description
Figure 2-13 Install the Pendent Cap 2. Fix the adapter to the pendent cap with two screws. (Optional) Figure 2-14 Install the Adapter to the Pendent Cap 3. Repeat step 1-8 of 2.2.1 to install the camera to the pendent cap. 3 Menu Description Two methods are available to call the menu. -
Page 10: Exposure Mode
SETUP FORMAT MAIN MENU VIDEO RESET &NIGHT SETTING SAVE CONTRAST &EXIT BRIGHTNESS COLOR SHARPNESS EXPOSURE MODE COLOR GAIN GAIN SMART MIRROR Figure 3-2 Main Menu Overview 3.1 Format Move the cursor to FORMAT, and press the menu button to enter the FORMAT sub menu. You can set the format of camera and confirm. -
Page 11: Video Setting
The noise will be amplified if the GAIN is on. 3.2.3 WB (White Balance) White balance is the white rendition function of the camera to adjust the color temperature according to the environment. It can remove the unrealistic color casts in the image. You can set WB mode as ATW, and MWB. -
Page 12: Save And Exit
VIDEO SET TING CONTRAST SHARPNESS COLOR GAIN DEFAULT MIRROR RETURN Figure 3-6 Video Setting CONTRAST This feature enhances the difference in color and light between parts of an image. You can set the CONTRAST value from 1 to 10. SHARPNESS Sharpness determines the amount of detail an imaging system can reproduce.
