TURBO HD
D8T Series Dome Camera

User Manual

UD05334B
User Manual
Thank you for purchasing our product. If there are any
questions, or requests, do not hesitate to contact the
dealer.
This manual applies to the models below:
Type
Type I Camera
Type II
Camera
Type III
Camera
This manual may contain technical incorrect places or
printing errors, and the content is subject to change
without notice. The updates will be added to the new
version of this manual. We will readily improve or
update the products or procedures described in the
manual.
DS-2CE56D8T-(A)VPIT3Z(E)
DS-2CE56D8T-(A)ITZ(E)
DS-2CE56D8T-VPIT(E)
Model
0100001070415
